2008 Peugeot 206 S Dag Owner's Manual

FAMILIARISATION4 -

5FAMILIARISATION-

1. Driver's air bag
Horn

2. Lights and direction indicators
stalk

3. Passenger air bag disarming
switch

4. Rear electric windows disarming
switch

5. Lighting rheostat for instrument
panel

6. Windscreen wiper/windscreen
wash stalk

7. Audio equipment remote control

8. Hazard warning lights switch/
central locking button

9. Multifunction display

10. Windscreen demisting vents

11. Side window demisting vents
12. Adjustable side vent

13. Passenger air bag

14. Adjustable centre vents

15. Glove box

16. Audio equipment

17. Control for heating, ventilation,
air conditioning and heated rear
screen and mirrors

18. Front ashtray

19. Gear lever

20. Lighter

21. Electric mirror controls

22. Rear electric window controls

23. Front electric window controls
24. Handbrake

25. Bonnet release

26. Steering lock

27. Fuse box

28. Storage compartment

29. Steering wheel height
adjustment control

30. Headlamp height adjustment

FAMILIARISATION6 -
KEYS
The keys allow you to independently
operate the locks on the front doors,
the boot, the passenger air bag dis-
arming switch, the fuel fi ller cap, and
the steering lock and to switch on the
ignition.
STARTING

The 4 positions of the key in the
ignition:

1. STOP position:
the ignition is off.

2.

1st notch, Accessories position:
the ignition is off but the acces-
sories can be used.

3. 2nd notch, Running position:
the ignition is on.

4. Starting position:
operates the starter.
Remote control
Pressing button
A remotely locks the
vehicle.
This is confi rmed by fi xed lighting of
the direction indicators for approxi-
mately two seconds.
Pressing button B remotely unlocks
the vehicle.
This is confi rmed by rapid fl ashing of
the direction indicators for approxi-
mately two seconds.

 55
Central locking and unlocking
From the driver's door, you can lock
and unlock the doors and the boot. If
one of the doors or the boot is open,
the central locking does not work. Leaving the ignition key in
If you leave the key in the ignition,
a buzzer reminds you of this when
opening the driver's door.
Locating the vehicle
To locate your vehicle, when you
have left it locked in a car park:

 press button A , the courtesy
lights will come on and the
indicator lights fl ash for a few
seconds. Steering lock
Before starting, unlock the steering
if necessary, by gently turning the
steering wheel at the same time as
you turn the key.
It is advisable to press the clutch
pedal while operating the starter, to
make starting easier.

7FAMILIARISATION-
Precautions regarding the
passenger air bag
For a vehicle fi tted with a disarming
switch:
Starting a petrol engine
Do not press the accelerator.
Operate the starter, without releasing
the key, until the engine turns.
Never race a cold engine.
Never run the engine in a
confi ned space.
Do not make any modifi ca-
tions to the steering lock.
With the ignition on (2nd notch),
illumination of this warning
light, accompanied by a mes-
sage on the multifunction dis-
play, indicates that the passenger air
bag is disarmed (switch in the "OFF"
position).
The warning light remains on through-
out the period of disarming.
FRONT AIR BAGS
For a vehicle not fi tted with a disarm-
ing switch:
- do not install a rear-facing child seat on
the front passenger
seat.
In no circumstances should you
place your feet or any other object on
the fascia.

 72
- disarm the air
bag if you install
a rear-facing
child seat,
- arm the air bag for an adult
passenger.
Disarming the passenger air bag
Insert the ignition key in the switch
1
and turn it to:
- the ''ON'' position, the passen-
ger air bag is armed,
- the ''OFF'' position, the passen-
ger air bag is disarmed.
Operating check

FAMILIARISATION8 -
DOORS
Front doors
 57
LOCKING/UNLOCKING THE TAILGATE

With central locking:
The tailgate is locked and unlocked
at the same time as the doors.
"Tailgate open" warning

When the engine is running , if the
tailgate has not been closed correctly
you are warned by an audible signal.

 59

When the vehicle is moving , if the
tailgate has not been closed correctly
the courtesy light fl ashes if its button
is in this position.

The lighting comes on when the
tailgate is opened.

9FAMILIARISATION-
ELECTRIC WINDOWS
3. Rear left electric window
ELECTRIC MIRRORS
Turn knob 5 to the right or to the left
to select the corresponding mirror.
Move knob 5 in all four directions to
adjust.

 64
1. Driver's electric window

Manual operation : press or pull the
switch gently. The window stops as
soon as the switch is released.
2. Passenger's electric window 4. Rear right electric window

 63

Automatic operation : press or pull
the switch fi rmly. One touch com-
pletely opens or closes the window.
Automatic opening and closing only
operate when the engine is running.

FAMILIARISATION10 -
STEERING WHEEL CONTROLS
Rear fog lamp (ring B) Windscreen wipers

2 Fast wipe

1 Normal wipe

I Intermittent wipe

0 Off

 Single wipe
Windscreen wash: pull the stalk to-
wards you.
Lights off
Side lights
Dipped/main beam
headlamps Front fog lamps/Rear fog lamp
(ring C)
Rear fog lamp (rotation of
the ring forwards) Front fog lamps (1st rotation
of the ring forwards)
Front fog lamps and
rear fog lamp (2nd
rotation of the ring for-
wards)

 61
 62
Lights
Front and rear lights (ring A)

11FAMILIARISATION-
Never travel with the head
restraints removed.

3. Driver's seat height adjustment.

4. Seat back angle adjustment.
FRONT SEATS

 44

1. Forwards/backwards adjustment.

2. Head restraint height and angle
adjustment.
