Page 25 of 103
27AUDIO EQUIPMENT-
Button
Function
A Radio on/off.
B - Decrease volume.
C + Increase volume.
D RDS RDS function on/off.
Press for more than 2 seconds: regional following mode on/off.
E TA T r a f fi c i n f o r m a t i o n p r i o r i t y o n / o f f .
Press for more than 2 seconds: PTY function on/off.
H
Selection of bass, treble, loudness, sound distribution and
automatic volume correction.
I
Increase setting of functions associated with button
H .
J
Decrease setting of functions associated with button
H .
L
Manual and automatic search of higher frequency.
Selection of next CD track and PTY (radio).
M MAN Manual/automatic operation of buttons L and N .
N
Manual and automatic search of lower frequency.
Selection of previous CD track and PTY (radio).
P CH.CD Selection of the CD changer.
P r e s s f o r m o r e t h a n 2 s e c o n d s : s h u f fl e .
Q CD Selection of the CD.
P r e s s f o r m o r e t h a n 2 s e c o n d s : s h u f fl e .
R Radio Radio Selection of the radio. Selection of FM1, FM2, FMast,
AM wavebands.
Press for more than 2 seconds: automatic storing of stations in the memory (autostore).
S
Ejection of the CD.
1 to 6 1 2 3 4 5 6 Selection of station stored in the memory.
Press for more than 2 seconds: storing of a station in the memory.
1 to 5 1 2 3 4 5 Selection of a CD changer disc.
Page 26 of 103
AUDIO EQUIPMENT
28 -
GENERAL FUNCTIONS AUDIO SETTINGS
Adjusting the loudness
This function automatically empha-
sises bass and treble tones. Press
button I or J to switch the function on
or off.
On/off
With the ignition key
in the accessories or
ignition position, press
button
A to switch the
set on or off.
The set can oper-
ate for 30 minutes
without the vehicle ignition being
switched on.
Anti-theft system
The audio system is coded in such a
way that it can operate only on your
v e h i c l e . I t w o u l d n o t f u n c t i o n i f fi t t e d
to another vehicle.
The anti-theft system is automatic
and requires no action on your
part. ADJUSTING THE VOLUME
Press button C to increase the vol-
ume, or button B to decrease it.
Continuous pressure on buttons C
and B allows a gradual adjustment of
the volume. Adjusting the bass
Adjusting the treble
When
"TREB" is displayed, press
button I or J to vary the setting.
- "TREB -9" for a minimum treble
setting,
- "TREB 0" for a normal setting,
- "TREB +9" for a maximum
treble setting.
Press button
H sev-
eral times in succes-
sion to access the
bass (BASS) , treble
(TREB) , loudness
(LOUD) , fader (FAD) ,
balance (BAL) and
automatic volume cor-
rection settings.
Exit from audio mode is automatic
after a few seconds without pressing
any button, or by pressing button H
a f t e r c o n fi g u r a t i o n o f t h e a u t o m a t i c
volume correction.
Note: bass, treble and loudness set-
t i n g s a r e s p e c i fi c t o e a c h s o u r c e . I t
is possible to set them differently for
radio, cassette (RB3) , CD (RD3) and
CD changer. When
"BASS" is dis-
played, press button
I or J to vary the set-
ting.
- "BASS -9" for a
minimum bass
setting,
- "BASS 0" for a
normal setting,
- "BASS +9" for a maximum bass
setting.
Page 27 of 103
29AUDIO EQUIPMENT-
RADIO Selecting radio mode
Selecting a waveband
Adjusting the front/rear sound
distribution (Fader)
When
"FAD" is displayed, press but-
ton I or J .
Button I increases the volume in the
front.
Button J increases the volume in the
rear.
Adjusting the right/left sound
distribution (Balance)
When "BAL" is displayed, press but-
ton I or J .
Button I increases the volume on the
right-hand side.
Button J increases the volume on the
left-hand side.
Automatic volume correction
This function enables the volume to
be automatically adjusted depending
on the level of noise produced by the
speed of the vehicle.
Press buttons I or J to switch the
function on or off. Press button
R .
Press button R brief-
ly to select the FM1,
FM2 FMast and AM
wavebands.
Notes on radio reception
Your car radio is subject to phenome-
na which do not affect domestic radio
sets. Both AM (MW/LW) and FM re-
ception are subject to various forms
o f i n t e r f e r e n c e . T h i s i s n o r e fl e c t i o n
on the quality of the equipment, but
is due to the nature of the signals and
the way in which they are transmit-
ted.
On MW/LW, interference may be
noticed when passing under high
voltage power lines or bridges, or in
tunnels.
On FM, interference may be the result
of increasing distance from the trans-
m i t t e r , d e fl e c t i o n o f t h e s i g n a l s b y o b -
stacles (mountains, hills, buildings,
etc.), or of being in an area which is
not covered by a transmitter.
Page 28 of 103
29AUDIO EQUIPMENT-
RADIO Selecting radio mode
Selecting a waveband
Adjusting the front/rear sound
distribution (Fader)
When
"FAD" is displayed, press but-
ton I or J .
Button I increases the volume in the
front.
Button J increases the volume in the
rear.
Adjusting the right/left sound
distribution (Balance)
When "BAL" is displayed, press but-
ton I or J .
Button I increases the volume on the
right-hand side.
Button J increases the volume on the
left-hand side.
Automatic volume correction
This function enables the volume to
be automatically adjusted depending
on the level of noise produced by the
speed of the vehicle.
Press buttons I or J to switch the
function on or off. Press button
R .
Press button R brief-
ly to select the FM1,
FM2 FMast and AM
wavebands.
Notes on radio reception
Your car radio is subject to phenome-
na which do not affect domestic radio
sets. Both AM (MW/LW) and FM re-
ception are subject to various forms
o f i n t e r f e r e n c e . T h i s i s n o r e fl e c t i o n
on the quality of the equipment, but
is due to the nature of the signals and
the way in which they are transmit-
ted.
On MW/LW, interference may be
noticed when passing under high
voltage power lines or bridges, or in
tunnels.
On FM, interference may be the result
of increasing distance from the trans-
m i t t e r , d e fl e c t i o n o f t h e s i g n a l s b y o b -
stacles (mountains, hills, buildings,
etc.), or of being in an area which is
not covered by a transmitter.
Page 29 of 103
AUDIO EQUIPMENT
30 -
Manual station search
Press the "MAN" button.
B r i e fl y p r e s s b u t t o n L or N to in-
crease or decrease the frequency
displayed.
By continuing to press the button in
the direction selected, you will obtain
continuous scrolling of the frequency.
The scrolling stops as soon as the
button is released.
Pressing the "MAN" button again
returns you to automatic station
search. Automatic storing of FM stations
in the memory (autostore)
Your radio automatically stores the 6
stations with the strongest signal in
FM . These stations are stored in the
FMast waveband.
I f i t i s n o t p o s s i b l e t o fi n d 6 s t a t i o n s ,
the remaining memories are empty.
Automatic station search
Manual storing of stations in the
memory
Select the station required.
Press one of the buttons "1" to "6"
for more than two seconds.
The sound stops then becomes audi-
b l e a g a i n , c o n fi r m i n g t h a t t h e s t a t i o n
has been stored in the memory. Recalling stations stored in the
memory
F o r e a c h w a v e b a n d , b r i e fl y p r e s s
buttons
"1" to "6" to recall the cor-
responding station.
B r i e fl y p r e s s b u t t o n
L or N to search
for the station immediately above or
below. By continuing to press the
button in the direction selected, you
will obtain continuous scrolling of the
frequency.
T h e s c r o l l i n g s t o p s a t t h e fi r s t s t a -
tion found as soon as the button is
released.
If the TA t r a f fi c p r o g r a m m e i s s e l e c t -
ed, only stations broadcasting this
type of programme are selected.
S e a r c h i n g f o r a s t a t i o n o c c u r s fi r s t i n
"LO" sensitivity (selection of the most
powerful transmitters) during scan-
ning of the waveband, then in "DX"
sensitivity (selection of the weakest
and most distant transmitters).
To make a direct search in "DX" sen-
sitivity, press button L or N twice. Press and hold button
R for more than two
seconds.
Page 30 of 103
31AUDIO EQUIPMENT-
RDS T r a f fi c i n f o r m a t i o n p r o g r a m m e Regional following mode
When they are part of a network, cer-
tain stations broadcast regional pro-
grammes in the various areas they
serve. With regional following mode
you can keep listening to the same
programme.
Press the "RDS" button for more
than two seconds to switch the func-
tion on or off.
RDS station following
The display indicates the name of the
station selected. The radio is contin-
ually searching for the station which
has the best reception and which is
transmitting the same programme. Press the
"TA" button
to switch the function
on or off.
B r i e fl y p r e s s t h e "RDS"
button to switch the
function on or off.
The multifunction display will show:
- "RDS" if the function is selected.
- "(RDS)" if the function is
selected but not available.
Using the RDS (Radio Data
System) function on FM
Radio Data System allows you to
continue listening to the same sta-
tion, whatever frequency it is using
for the region you are going through.
The multifunction display will show:
-
"TA" if the function is selected,
- "(TA)" if the function is selected
but not available.
A n y t r a f fi c i n f o r m a t i o n fl a s h w i l l b e
given priority, whatever source you
are listening to (radio, cassette or CD
changer).
If you wish to interrupt a message,
press the "TA" button; this switches
the function off.
N o t e : t h e v o l u m e o f t r a f fi c i n f o r m a -
tion announcements is independ-
ent of the volume of normal radio
listening. You can adjust it using
the volume button. The setting will
be stored and will be used when
the next messages are broadcast.
Page 31 of 103
AUDIO EQUIPMENT
32 -
EON system
This connects stations which are part
of the same network. It enables the
b r o a d c a s t o f t r a f fi c i n f o r m a t i o n o r a
PTY programme, by a station that is
part of the same network as the sta-
tion to which you are listening.
This service is available when you
have selected the TA t r a f fi c i n f o r m a -
tion programme or the PTY function.
PTY function
This allows you to listen to stations broad-
c a s t i n g a s p e c i fi c t y p e o f p r o g r a m m e
(news, culture, sport, rock, etc.).
To search for a
PTY programme:
With FM selected,
press the "TA" but-
ton for two seconds to
switch this function on
or off. - select the
PTY function,
- b r i e fl y p r e s s b u t t o n L or N to
scroll down the list of the various
types of programmes offered.
- when the programme of your choice is displayed, keep button
L or N pressed for two seconds
to carry out an automatic search
(after an automatic search the
PTY function is switched off).
In PTY mode the different types of
programmes can be stored in the
memory. To do this, press the prese-
lection buttons "1" to "6" for two
s e c o n d s . B r i e fl y p r e s s t h e c o r r e -
sponding button to recall the type of
programme stored in the memory.
Page 32 of 103
33AUDIO EQUIPMENT-
Ejection of a disc Selecting a track
S h u f fl e ( R D M )
When the CD player is selected,
press and hold button Q for two sec-
onds. The tracks will be played in
random sequence. Pressing the but-
ton again for two seconds returns
you to normal play.
S h u f fl e m o d e i s d e - a c t i v a t e d e a c h
time the set is switched off.
After insertion of a
disc, printed face
upwards, the player
starts automatically.
If a disc is already inserted, press
button Q .
COMPACT DISC
Press button L to select the next
track.
Press button N to return to the start
of the current track or to select the
previous track.
The use of copied com-
pact discs may cause
faults.
Insert circular compact
discs only.
Press button
S to
eject the disc from the
player. Accelerated play
Press and hold button
L or N for
forwards or backwards accelerated
play.
Accelerated play stops as soon as
the button is released.
Selecting CD mode
