SEC-24
< FUNCTION DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
ACTIVE TEST
CLUCH SWNOTE:
This item is displayed, but cannot be monitored.
BRAKE SW 1 Indicates [ON/OFF] condition of brake switch.
DETE/CANCL SW Indicates [ON/OFF] condition of the P position.
SFT PN/N SW Indicates [ON/OFF] condition of the P or N position.
S/L -LOCK Indicates [ON/OFF] condition of steering lock unit (LOCK).
S/L -UNLOCK Indicates [ON/OFF] condition of steering lock unit (UNLOCK).
S/L RELAY -F/B Indicates [ON/OFF] condition of steering lock relay.
UNLK SEN -DR Indicates [ON/OFF] condition of driver door UNLOCK status.
PUSH SW -IPDM Indicates [ON/OFF] condition of push-button ignition switch.
IGN RLY1 -F/B Indicates [ON/OFF] condition of ignition relay 1.
DETE SW -IPDM Indicates [ON/OFF] condition of the P position.
SFT PN -IPDM Indicates [ON/OFF] condition of the P or N position.
SFT P -MET Indicates [ON/OFF] condition of the P position.
SFT N -MET Indicates [ON/OFF] condition of the N position.
ENGINE STATE Indicates [STOP/STALL/CRANK/RUN] condition of engine states.
S/L LOCK-IPDM Indicates [ON/OFF] condition of steering lock unit (LOCK).
S/L UNLK-IPDM Indicates [ON/OFF] condition of steering lock unit (UNLOCK).
S/L RELAY-REQ Indicates [ON/OFF] condition of steering lock relay.
VEH SPEED 1 Displays the vehicle speed signal received from combination meter by numerical value [Km/h].
VEH SPEED 2 Displays the vehicle speed signal received from ABS, VDC or CVT by numerical value [Km/h].
DOOR STAT-DR Indicates [LOCK/READY/UNLK] condition of driver side door status.
DOOR STAT-AS Indicates [LOCK/READY/UNLK] condition of passenger side door status.
ID OK FLAG Indicates [SET/RESET] condition of key ID.
PRMT ENG STRT Indicates [SET/RESET] condition of engine start possibility.
PRMT RKE STRTNOTE:
This item is displayed, but cannot be monitored.
KEY SW -SLOT Indicates [ON/OFF] condition of key slot.
TRNK/HAT MNTR Indicates [ON/OFF] condition of trunk lid.
RKE-LOCK Indicates [ON/OFF] condition of LOCK signal from Intelligent Key.
RKE-UNLOCK Indicates [ON/OFF] condition of UNLOCK signal from Intelligent Key.
RKE-TR/BD Indicates [ON/OFF] condition of TRUNK OPEN signal from Intelligent Key.
RKE-PANICNOTE:
This item is displayed, but cannot be monitored.
RKE-P/W OPENNOTE:
This item is displayed, but cannot be monitored.
RKE-MODE CHG Indicates [ON/OFF] condition of MODE CHANGE signal from Intelligent Key.
RKE OPE COUN1When remote keyless entry receiver receives the signal transmitted while operating on Intelligent Key, the
numerical values start changing.
RKE OPE COUN2NOTE:
This item is displayed, but cannot be monitored. Monitor Item Condition

B2560 STARTER CONTROL RELAY
SEC-55
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2560 STARTER CONTROL RELAY
DescriptionINFOID:0000000003814971
Starter control relay, integrated in IPDM E/R, permits the starter relay operation when in the N or P position
and the steering is locked or unlocked. It is installed in parallel with the starter relay.
DTC LogicINFOID:0000000003814972
DTC DETECTION LOGIC
NOTE:
 If DTC B2560 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic"
 If DTC B2560 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions and wait for at least 2 seconds.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-55, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814973
1.CHECK DTC WITH IPDM E/R
Check “Self diagnostic result” with CONSULT-III. Refer to SEC-191, "
DTCIndex".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace IPDM E/R. Refer to PCS-34, "
Removal and Installation".
2.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident"
>> INSPECTION END
DTC Self-diagnosis name DTC detecting condition Possible causes
B2560 STARTER CONTROL RELAYBCM detects a mismatch between the OFF re-
quest of starter control relay to IPDM E/R and the
feedback. (The feedback is ON instead of OFF.)IPDM E/R

B2606 STEERING LOCK RELAY
SEC-69
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2606 STEERING LOCK RELAY
DescriptionINFOID:0000000003814990
The steering lock relay ON signal is transmitted to IPDM E/R by BCM via CAN communication.
IPDM E/R turns the steering lock relay ON and transmits the release of the steering to BCM.
DTC LogicINFOID:0000000003814991
DTC DETECTION LOGIC
NOTE:
 If DTC B2606 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
 If DTC B2606 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Turn ignition switch OFF.
3. Press driver side door switch and wait for at least 1 second.
4. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-69, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814992
1.CHECK DTC WITH IPDM E/R
Check “Self diagnostic result” with CONSULT-III. Refer to SEC-191, "
DTCIndex".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace IPDM E/R. Refer to PCS-34, "
Removal and Installation".
2.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2606STEERING LOCK
RELAYBCM detects that there is a mismatch between the
following statuses.
 Steering lock unit ON signal transmitted by
IPDM E/R
 The steering lock unit status feedback Steering lock relay (Built into IPDM E/R)

SEC-70
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2607 STEERING LOCK RELAY
B2607 STEERING LOCK RELAY
DescriptionINFOID:0000000003814993
BCM requests to IPDM E/R to supply power to steering lock unit. After receiving the power, the steering lock
unit transmits an ON signal to BCM.
DTC LogicINFOID:0000000003814994
DTC DETECTION LOGIC
NOTE:
 If DTC B2607 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
 If DTC B2607 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Turn ignition switch OFF.
3. Press driver side door switch and wait for at least 1 second.
4. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-70, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814995
1.CHECK DTC WITH IPDM E/R
Check “Self diagnostic result” with CONSULT-III. Refer to SEC-191, "
DTCIndex".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK STEERING LOCK UNIT POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect steering lock unit connector.
3. Check voltage between steering lock unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2607STEERING LOCK
RELAYBCM detects that there is a difference between the
following statuses.
 Steering lock unit ON signal transmitted by IPDM
E/R
 The steering lock unit status feedback  Harness or connectors (Steering
lock unit power supply circuit is
open or shorted)
 Steering lock relay (Built into IPDM
E/R)
(+)
(–) ConditionVoltage (V)
(Approx.) Steering lock unit
Connector Terminal
M12 1 GroundPress push-button ignition switch when
steering lock is in lock condition.Battery voltage

B2607 STEERING LOCK RELAY
SEC-71
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
3.CHECK STEERING LOCK UNIT CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between steering lock unit harness connector and IPDM E/R harness connector.
4. Check continuity between steering lock unit harness connector and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-34, "Removal and Installation".
NO >> Repair or replace harness.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
Steering lock unit IPDM E/R
Continuity
Connector Terminal Connector Terminal
M12 1 E10 11 Existed
Steering lock unit
GroundContinuity
Connector Terminal
M12 1 Not existed

SEC-72
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2608 STARTER RELAY
B2608 STARTER RELAY
DescriptionINFOID:0000000003814996
Located in IPDM E/R, the starter relay runs the starter motor. The starter relay is turned ON by the BCM when
the ignition switch is in the START position. IPDM E/R transmits the starter relay ON signal to BCM via CAN
communication.
DTC LogicINFOID:0000000003814997
DTC DETECTION LOGIC
NOTE:
 If DTC B2608 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
 If DTC B2608 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
 If DTC B2608 is displayed with DTC B210D for IPDM E/R, first perform the trouble diagnosis for DTC
B210D. Refer to SEC-104, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-72, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814998
1.CHECK BCM POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK STARTER RELAY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector and IPDM E/R connector.
3. Check continuity between IPDM E/R harness connector and BCM harness connector.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2608 STARTER RELAYBCM receives starter relay ON signal (CAN) from
IPDM E/R even if BCM turns the starter relay OFF. Harness or connectors
(Starter relay circuit is open or
shorted.)
 IPDM E/R
(+)
(–) ConditionVoltage (V)
(Approx.) BCM
Connector Terminal
M121 52 Ground Selector leverN or P position Battery voltage
Other than above 0

B2608 STARTER RELAY
SEC-73
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
4. Check continuity between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-34, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
IPDM E/R BCM
Continuity
Connector Terminal Connector Terminal
E11 46M12152Existed
IPDM E/R
GroundContinuity
Connector Terminal
E11 46 Not existed

B2617 STARTER RELAY CIRCUIT
SEC-89
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2617 STARTER RELAY CIRCUIT
DescriptionINFOID:0000000003815026
Located in IPDM E/R, it runs the starter motor. The starter relay is turned ON by the BCM when the ignition
switch is in the START position. IPDM E/R transmits the starter relay ON signal to BCM via CAN communica-
tion.
DTC LogicINFOID:0000000003815027
DTC DETECTION LOGIC
NOTE:
 If DTC B2617 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
 If DTC B2617 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
 If DTC B2617 is displayed with DTC B2611, first perform the trouble diagnosis for DTC B2611. Refer to
SEC-89, "
DTC Logic".
 If DTC B2617 is displayed with DTC B210E for IPDM E/R, first perform the trouble diagnosis for DTC
B210E. Refer to SEC-105, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions and wait for at least 1 second.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-89, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003815028
1.CHECK STARTER RELAY
1. Turn ignition switch ON.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK STARTER RELAY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector and IPDM E/R connector.
3. Check continuity between IPDM E/R harness connector and BCM harness connector.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2617STARTER RELAY
CIRCUITAn immediate operation of starter relay is request-
ed by BCM, but there is no response for more than
1 second Harness or connectors
(Starter relay circuit is open or short-
ed)
IPDM E/R
(+)
(–) ConditionVoltage (V)
(Approx.) BCM
Connector Terminal
M121 52 Ground Selector leverN or P position Battery voltage
Other than above 0
