2008 NISSAN 350Z Owners Manual

lines to help reduce the risk of injury to out-of-
position occupants.However, all of the infor-
mation, cautions and warnings in this
manual still apply and must be followed.
The side air bags and curtain air bags are
designed to inflate in higher severity side colli-
sions on the side that the vehicle is impacted,
although they may inflate if the forces in another
type of collision are similar to those of a higher
severity side impact. They are designed to inflate
on the side where the vehicle is impacted. They
may not inflate in certain side collisions.
Vehicle damage (or lack of it) is not always an
indication of proper side air bag and curtain air
bag operation.
When the side air bags and curtain air bags
inflate, a fairly loud noise may be heard, followed
by release of smoke. This smoke is not harmful
and does not indicate a fire. Care should be
taken not to inhale it, as it may cause irritation
and choking. Those with a history of a breathing
condition should get fresh air promptly.
Side air bags, along with the use of seat belts,
help to cushion the impact force on the chest of
the front occupants. Curtain air bags help to
cushion the impact force to the head of occu-
pants. They can help save lives and reduce
serious injuries. However, an inflating side air
bag and curtain air bag may cause abrasions or
other injuries. Side air bags and curtain air bagsdo not provide restraint to the lower body.
The seat belts should be correctly worn and the
driver and passenger seated upright as far as
practical away from the side air bag, and seated
as far away as practical from the door finishers
and side roof rails. The side air bags and curtain
air bags inflate quickly in order to help protect
the front occupants. Because of this, the force of
the side air bags and curtain air bags inflating
can increase the risk of injury if the occupant is
too close to, or is against these air bag modules
during inflation. The side air bags and curtain air
bags will deflate quickly after the collision is
over.
The side air bags and curtain air bags
operate only when the ignition switch is in
the ON or START position.
After turning the ignition key to the ON
position, the supplemental air bag warning
light illuminates. The air bag warning light
will turn off after about 7 seconds if the
systems are operational.
WARNING

Do not place any objects near the
seatback of the front seats. Also, donot place any objects (an umbrella,
bag, etc.) between the front door fin-
isher and the front seat. Such objects
may become dangerous projectiles
and cause injury if a side air bag
inflates.

Right after inflation, several side air
bag and curtain air bag system com-
ponents will be hot. Do not touch
them; you may severely burn your-
self.

No unauthorized changes should be
made to any components or wiring of
the side air bag and curtain air bag
systems. This is to prevent accidental
inflation of the side air bags and
curtain air bags or damage to the
side air bag and curtain air bag sys-
tems.

Do not make unauthorized changes
to your vehicle’s electrical system,
suspension system or side panel.
This could affect proper operation of
the side air bag and curtain air bag
systems.
1-40
Safety — Seats, seat belts and supplemental restraint system


07.7.25/Z33-D/V5.0


Tampering with the side air bag sys-
tem may result in serious personal
injury. For example, do not change
the front seats by placing material
near the seatback or by installing
additional trim material, such as seat
covers, around the side air bag.

Work around and on the side air bag
and curtain air bag systems should
be done by a NISSAN dealer. Instal-
lation of electrical equipment should
also be done by a NISSAN dealer.
The SRS wiring harnesses* should
not be modified or disconnected. Un-
authorized electrical test equipment
and probing devices should not be
used on the side air bag system.
* The SRS wiring harness connectors
are yellow and orange for easy iden-
tification.
When selling your vehicle, we request that you
inform the buyer about the side air bag and
curtain air bag systems and guide the buyer to
the appropriate sections in this Owner’s Manual.
Seat belts with pretensioners
WARNING

The pretensioners cannot be reused
after activation. They must be re-
placed together with the retractor
and buckle as a unit.

If the vehicle becomes involved in a
frontal collision but a pretensioner is
not activated, be sure to have the
pretensioner system checked and, if
necessary, replaced by a NISSAN
dealer.

No unauthorized changes should be
made to any components or wiring of
the pretensioner system.
This is to prevent damage to or acci-
dental activation of the pretension-
ers. Tampering with the pretensioner
system may result in serious per-
sonal injury.

Work around and on the preten-
sioner system should be done by aNISSAN dealer. Installation of elec-
trical equipment should also be done
by a NISSAN dealer. Unauthorized
electrical test equipment and probing
devices should not be used on the
pretensioner system.

If you need to dispose of a pre-
tensioner or scrap the vehicle, con-
tact a NISSAN dealer. Correct pre-
tensioner disposal procedures are
set forth in the appropriate NISSAN
Service Manual. Incorrect disposal
procedures could cause personal
injury.
The pretensioner system activates in conjunction
with the front air bag system. Working with the
seat belt retractor, it helps tighten the seat belt
when the vehicle becomes involved in certain
types of collisions, helping to restrain front seat
occupants.
The pretensioner is encased with the seat belt
retractor. These seat belts are used the same
way as conventional seat belts.
When a pretensioner activates, smoke is re-
leased and a loud noise may be heard. The
smoke is not harmful and does not indicate a fire.
Safety — Seats, seat belts and supplemental restraint system
1-41


07.7.25/Z33-D/V5.0


Care should be taken not to inhale it as it may
cause irritation and choking. Those with a history
of a breathing condition should get fresh air
promptly.
If any abnormality occurs in the pretensioner
system, the supplemental air bag warning light
will not come on, will flash intermittently or
will turn on for 7 seconds and remain on after the
ignition key has been turned to the ON or
START position. In this case, the pretensioner
may not function properly. They must be
checked and repaired. Take your vehicle to a
NISSAN dealer.
When selling your vehicle, we request that you
inform the buyer about the pretensioner and
guide the buyer to the appropriate sections in
this Owner’s Manual.
SUPPLEMENTAL AIR BAG
WARNING LABELSWarning labels about the supplemental front-
impact air bag and front seat-mounted side-
impact supplemental air bag (if so equipped)
systems are placed in the vehicle as shown in
the illustration.
SSS0206
1-42
Safety — Seats, seat belts and supplemental restraint system


07.7.25/Z33-D/V5.0


SUPPLEMENTAL AIR BAG
WARNING LIGHTThe supplemental air bag warning light, display-
ing
in the instrument panel, monitors the
circuits of the supplemental front-impact air bag,
front seat-mounted side-impact supplemental air
bag (if so equipped), roof-mounted curtain side-
impact supplemental air bag (if so equipped for
Coupe models) and seat belt pretensioner sys-
tems. The monitored circuits include the Air bag
Control Unit (ACU), crash zone sensor, satellite
sensors, front air bag modules, side air bag
modules, curtain air bag modules, pretensioners
and all related wiring.After turning the ignition key to the ON position,
the supplemental air bag warning light illumi-
nates. The supplemental air bag warning light
will turn off after about 7 seconds if the system is
operational.
If any of the following conditions occur, the front
air bag, side air bag and curtain air bag, and
pretensioner systems need servicing:

The supplemental air bag warning light re-
mains on after approximately 7 seconds.

The supplemental air bag warning light
flashes intermittently.

The supplemental air bag warning light does
not come on at all.
Under these conditions, the front air bag, side air
bag, curtain air bag and/or pretensioner systems
may not operate properly. They must be checked
and repaired. Take your vehicle to a NISSAN
dealer.
WARNING
If the supplemental air bag warning
light is on, it could mean that the front
air bag, side air bag, curtain air bag,
and/or pretensioner systems will notoperate in an accident. To help avoid
injury to yourself or others, have your
vehicle checked by a NISSAN dealer as
soon as possible.
Repair and replacement procedureThe front air bags, side air bags (if so equipped),
curtain air bags (if so equipped for Coupe
models) and pretensioners are designed to in-
flate on a one-time-only basis. As a reminder,
unless it is damaged, the supplemental air bag
warning light will remain illuminated after inflation
has occurred. Repair and replacement of these
systems should be done only by a NISSAN
dealer.
When maintenance work is required on the
vehicle, the front air bags, side air bags, curtain
air bags, pretensioners and related parts should
be pointed out to the person conducting the
maintenance. The ignition key should always be
in the LOCK position when working under the
hood or inside the vehicle.
WARNING

Once a front air bag, side air bag or
SPA1097
Safety — Seats, seat belts and supplemental restraint system
1-43


07.7.25/Z33-D/V5.0


curtain air bag has inflated, the air
bag module will not function again
and must be replaced. Additionally, if
any of the front air bags inflate, the
activated pretensioners must also be
replaced. The air bag module and
pretensioner system should be re-
placed by a NISSAN dealer. The air
bag module and pretensioner system
cannot be repaired.

The front air bag, side air bag, curtain
air bag and pretensioner systems
should be inspected by a NISSAN
dealer if there is any damage to the
front end or side portion of the ve-
hicle.

If you need to dispose of these
supplemental systems or scrap the
vehicle, contact a NISSAN dealer.
Correct disposal procedures are set
forth in the appropriate NISSAN Ser-
vice Manual. Incorrect disposal pro-
cedures could cause personal injury.
1-44
Safety — Seats, seat belts and supplemental restraint system


07.7.25/Z33-D/V5.0


MEMO
Safety — Seats, seat belts and supplemental restraint system
1-45


07.7.25/Z33-D/V5.0


2 Instruments and controlsInstrument panel ................................................................... 2-2
Meters and gauges .............................................................. 2-3
Speedometer and odometer ........................................ 2-4
Tachometer ....................................................................... 2-5
Engine coolant temperature gauge ............................ 2-5
Fuel gauge ........................................................................ 2-6
Engine oil pressure gauge ........................................... 2-7
Volt meter ......................................................................... 2-8
Trip computer .................................................................. 2-8
Warning/indicator lights and audible reminders ........ 2-11
Checking bulbs ............................................................. 2-11
Warning lights ............................................................... 2-11
Indicator lights ............................................................... 2-15
Audible reminders ........................................................ 2-17
Security systems ................................................................ 2-18
Vehicle security system .............................................. 2-18
NISSAN Vehicle Immobilizer System ...................... 2-19
Windshield wiper and washer switch ........................... 2-21
Rear window wiper and washer switch
(Coupe models) .................................................................. 2-22
Rear window and outside mirror defroster switch .... 2-23
Headlight and turn signal switch ................................... 2-24
Xenon headlights .......................................................... 2-24
Headlight switch ........................................................... 2-24Daytime running light system (Canada only) ........ 2-25
Turn signal switch ........................................................ 2-26
Instrument brightness control ................................... 2-26
Hazard warning flasher switch ....................................... 2-27
Horn ....................................................................................... 2-27
Heated seats (if so equipped) ........................................ 2-28
Vehicle Dynamic Control (VDC) off switch
(if so equipped) .................................................................. 2-29
Traction Control System (TCS) off switch
(if so equipped) .................................................................. 2-29
Clock ..................................................................................... 2-30
Adjusting the time ........................................................ 2-30
Power outlet ........................................................................ 2-31
Storage ................................................................................. 2-32
Instrument pocket (except for navigation system
equipped models) ........................................................ 2-32
Sunglasses holder (Coupe models) ........................ 2-32
Cargo net......................................................................... 2-33
Cup holders ................................................................... 2-33
Console box .................................................................. 2-35
Rear floor box ................................................................ 2-35
Rear parcel box ............................................................ 2-37
Stowing golf bags ......................................................... 2-37
Coat hook (Coupe models) ........................................ 2-38


07.7.25/Z33-D/V5.0


Windows .............................................................................. 2-39
Power windows ............................................................ 2-39
Automatic adjusting function ...................................... 2-40
Interior lights ........................................................................ 2-41
Room light ...................................................................... 2-41
Map lights ...................................................................... 2-41
Vanity mirror light ............................................................... 2-42
Luggage compartment light (Coupe models) ............. 2-42
Trunk light (Roadster models).......................................... 2-42HomeLink
Universal Transceiver (if so equipped) .... 2-43
Programming HomeLink
........................................... 2-43
Programming HomeLinkfor Canadian
customers ....................................................................... 2-45
Operating the HomeLinkUniversal
Transceiver ..................................................................... 2-45
Programming trouble-diagnosis ............................... 2-45
Clearing the programmed information .................... 2-45
Reprogramming a single HomeLink
button ........ 2-45
If your vehicle is stolen ............................................... 2-46


07.7.25/Z33-D/V5.0
