2008 MERCEDES-BENZ CLS63AMG Owner's Manual

56 Getting started
Driving
Windshield wipers
The combination switch is located on the
left of the steering column.
Combination switch
1Single wipe
Wiping with washer fluid
2Switching on windshield wipers
Switch on the ignition (page 38).Switching on windshield wipers
Turn the combination switch to the de-
sired position depending on the inten-
sity of the rain.
MWindshield wipers off
USlow intermittent wiping
Rain sensor operation with low
sensitivity.
VFast intermittent wiping
Rain sensor operation with high
sensitivity.
uSlow continuous wiping
tFast continuous wiping
iTo signal minor directional changes such as
changing lanes, press combination switch only
to point of resistance and release. The corre-
sponding turn signals will flash three times.!Do not operate the wipers when the wind-
shield is dry. Dust that accumulates on a wind-
shield might scratch the glass and/or damage
the wiper blades when wiping occurs on a dry
windshield. If it is necessary to operate the wip-
ers in dry weather conditions, always operate
the wipers with washer fluid (
page 57).
!If anything blocks the windshield wipers
(leaves, snow, etc.), switch them off immediate-
ly.

For safety reasons, stop the vehicle in a safe
location

turn off the engine by turning the
SmartKey to position0 and withdraw
SmartKey from starter switch
or

turn off the engine by pressing the
KEYLESS-GO* start/stop button and
open the driver’s door (with the driver’s
door open, starter switch is in
position0, same as with SmartKey re-
moved from starter switch)
before attempting to remove any blockage.

Remove blockage.

Turn the windshield wipers on again.
!If windshield wipers fail to function at all in
combination switch positionU or V,

set the combination switch to the next high-
est wiper speed

have the windshield wipers checked at the
nearest authorized Mercedes-Benz Center


57 Getting started
Driving
Intermittent wiping
Only switch on intermittent wiping under
wet weather conditions or in the presence
of precipitation.Intermittent wiping interval is dependent
on wetness of windshield.
Turn the combination switch to
positionU or V.
After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.Single wipe
Press the combination switch briefly in
direction of arrow1 (
page 56) to
the resistance point.
The windshield wipers wipe one time
without washer fluid.
Wiping with washer fluid
Push the combination switch in direc-
tion of arrow1 (
page 56) past the
resistance point.
The windshield wipers operate with
washer fluid.
For information on filling up the washer
reservoir, see “Washer system and
headlamp cleaning system*”
(
page 292).
!Do not leave windshield wipers in
intermittent setting when the vehicle is taken to
an automatic car wash or during windshield
cleaning. Windshield wipers will operate in the
presence of water sprayed on the windshield,
and windshield wipers may be damaged as a re-
sult.
!If you have set intermittent wiping, dirt on
the surface of the rain sensor or optical effects
may cause the windshield wipers to wipe in an
undesired fashion. This could then damage the
windshield wiper blades or scratch the windows.
You should therefore switch off the windshield
wipers when weather conditions are dry.
iIntermittent wiping is interrupted when the
vehicle is at a standstill and a front door is
opened. This protects persons getting into or out
of the vehicle from being sprayed.
Intermittent wiping will be continued when

all doors are closed
and

the gear selector lever is in positionD orR
or

the wiper setting is changed using the com-
bination switch
iTo prevent smears on the windshield or
noisy/chattering wiper blades, wipe with washer
fluid every now and then even when it is raining.

58 Getting started
Driving
Problems while driving
The engine runs erratically and misfires

An ignition cable may be damaged.

The engine electronics may not be
operating properly.

Unburned gasoline may have entered
the catalytic converter and damaged it.
Give very little gas.
Have the problem repaired by an
authorized Mercedes-Benz Center as
soon as possible.
The coolant temperature is above
248°F (120°C)
The coolant is too hot and is no longer
cooling the engine.
Stop the vehicle in a safe location as
soon as possible and turn off the en-
gine. Allow engine and coolant to cool
off.
Check the coolant level and add cool-
ant if necessary (
page 290).
In case of accident
If the vehicle is leaking fuel:
Do not start the engine under any
circumstances.
Notify local fire and/or police authori-
ties.
If the extent of the damage cannot be
determined:
Contact an authorized Mercedes-Benz
Center or call Roadside Assistance.
If no damage can be determined on the

major assemblies

fuel system

engine mount:
Start the engine in the usual manner.

59 Getting started
Parking and locking
Parking and locking
You have now completed your first drive.
You have properly stopped and parked
your vehicle. End your drive as follows.
Parking brake
Warning!G
With the engine not running, there is no
power assistance for the brake and steering
systems. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the ve-
hicle.
Warning!G
If you have selected the Comfort suspension
tuning (
page 230), the vehicle lowers
slightly when it is locked. You should there-
fore make sure that no one is standing near
the wheel arches or lying underneath the ve-
hicle when it is being locked. Otherwise,
personal injury could result.
Warning!G
Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
To reduce the risk of personal injury, or
damage to the vehicle drivetrain, as a result
of vehicle movement, before turning off the
engine and leaving the vehicle always:

Keep right foot on brake pedal.

Firmly depress parking brake pedal.

Move the gear selector lever to
positionP.

Slowly release brake pedal.

When parked on an incline, turn front
wheel towards the road curb.

Turn the SmartKey in the starter switch
to position0 and remove the SmartKey
from the starter switch, or press
KEYLESS-GO* start/stop button.

Take the SmartKey or the SmartKey with
KEYLESS-GO* with you and lock vehicle
when leaving.
!If you have selected the Comfort suspen-
sion tuning (
page 230), the vehicle lowers
slightly when you lock it within approximately
60 seconds after switching off the engine. When
parking, make sure that your vehicle cannot
come into contact with other objects, such as a
curb, while lowering. Your vehicle could
otherwise be damaged.
Warning!G
Engaging the parking brake while the vehicle
is in motion can cause the rear wheels to
lock up. You could lose control of the vehicle
and cause an accident. In addition, the vehi-
cle’s brake lights do not light up when the
parking brake is engaged.

60 Getting started
Parking and locking
1Release handle
2Parking brake pedal
Step firmly on parking brake pedal2.
When the engine is running, the warn-
ing lamp; (USA only) or3
(Canada only) in the instrument cluster
will be illuminated.
Switching off headlamps
Turn the exterior lamp switch toM
(
page 55).
For more information, see “Lighting”
(
page 126).
Turning off engine
Shift the automatic transmission to
positionP (
page 171).
Apply the parking brake (page 59).
Warning!G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Children could release the
parking brake and/or move the gear selec-
tor lever from positionP, either of which
could result in an accident and/or serious
personal injury.
Warning!G
Getting out of your vehicle with the gear
selector lever not fully engaged in positionP
is dangerous. Also, when parked on an in-
cline, positionP alone may not prevent your
vehicle from moving, possibly hitting people
or objects.
Always set the parking brake in addition to
shifting to positionP.
When parked on an incline, turn front wheels
towards the road curb.
iAlways set the parking brake in addition to
shifting to positionP (
page 171).
On slopes, turn the front wheels towards the
road curb.

61 Getting started
Parking and locking
Turning off with the SmartKey
Turn the SmartKey in the starter switch
(
page 38) to position0.
Remove the SmartKey from the starter
switch.
The immobilizer is activated.
Turning off with KEYLESS-GO*
Press the KEYLESS-GO start/stop
button (
page 39) to turn off the en-
gine.
With the driver’s door closed, the start-
er switch is now in position1. With the
driver’s door opened, the starter switch
is set to position0, same as SmartKey
removed from starter switch
(
page 38).
Releasing seat belts
Press the seat belt release button
(
page 49).
Allow the retractor to completely
rewind the seat belt by guiding the
latch plate.
Locking
Exit the vehicle and close all doors and
the trunk.iIf you hear a warning signal you have tried to
turn off the engine while the gear selector lever
was not inP.
In addition, the message
Gear Selector Le-
ver In P Position
appears in the multifunc-
tion display.
Place the gear selector lever in positionP.
!Make sure the seat belt retracts fully so that
the seat belt and/or latch plate cannot get
caught or pinched in the door or in the seat
mechanism. This can damage the seat belt and
impair the effectiveness of the seat belt, and/or
cause damage to the door and/or door trim pan-
el. Such damage is not covered by the
Mercedes-Benz Limited Warranty.
Damaged seat belts must be replaced. Contact
an authorized Mercedes-Benz Center.
Warning!G
To prevent possible personal injury, always
keep hands and fingers away from the door
openings when closing the doors.
Be especially careful when small children
are around.
Before closing doors, make sure that there
is no possibility of someone getting caught
in a door during closing.
Warning!G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised ac-
cess to a vehicle could result in an accident
and/or serious personal injury.

62 Getting started
Parking and locking
Locking with the SmartKey
After exiting the vehicle, press lock
button‹ on the SmartKey
(
page 36).
With the trunk and all doors closed:

All turn signal lamps flash three
times.

An acoustic signal sounds three
times.
For more information, see “Factory
setting” (
page 106).

The locking knobs in the doors
move down.

The anti-theft alarm system is
armed.
For more information, see “Locking and
unlocking” (
page 100).
Locking with KEYLESS-GO*
1Lock button
After exiting the vehicle, press lock
button1 at the outside door handle or
on the trunk lid.
With the trunk and all doors closed:

All turn signal lamps flash three
times.

An acoustic signal sounds three
times.
For more information, see “Factory
setting” (
page 106).

The locking knobs in the doors
move down.

The anti-theft alarm system is
armed.
For more information, see “Locking and
unlocking” (
page 100).
iIf you hear a warning signal you have forgot-
ten to switch off the low beam headlamps or the
parking lamps before opening the driver’s door.
In addition the message
Switch Off Lights
appears in the multifunction display.
Switch off the low beam headlamps or the park-
ing lamps.
If the message
Switch Off Lights or
Remove Key
appears in the multifunction dis-
play remove the SmartKey from the starter
switch or switch off the automatic headlamp
mode.
!Failure to switch off the exterior lamps when
leaving the vehicle may result in a discharged
battery.

63 Safety and Security
Occupant safety
Panic alarm
Driving safety systems
Anti-theft systems
