2008 MERCEDES-BENZ CLS63AMG Owner's Manual

144 Controls in detail
Control system
Menu6Menu7Menu8Menu9
Vehicle status message
memory1
1The vehicle status message memory menu is only displayed if there is a message stored.
SettingsTrip computerTEL*
(page 151)(page 152)(page 164)(page 166)
Commands/submenus
Calling up vehicle malfunction,
warning and system status
messages stored in memoryResetting to factory settingsFuel consumption statistics
since startLoading phone book
Instrument cluster submenuFuel consumption statistics
since the last resetSearching for name in phone
book
Time/Date submenuResetting fuel consumption
statistics
Lighting submenuDistance to empty
Vehicle submenu
Convenience submenu
iThe headings used in the menus table are
designed to facilitate navigation within the sys-
tem and are not necessarily identical to those
shown in the control system displays.
The first function displayed in each menu will au-
tomatically show you which part of the system
you are in.

145 Controls in detail
Control system
Standard display menu
Press buttonk orj repeatedly
to select the functions in the standard
display menu.
The following functions are available:
Display digital speedometer
Press buttonk orj repeatedly
until the digital speedometer appears
in the multifunction display.
AMG menu
The main screen of the AMG menu shows
you the gear currently engaged as well as
the engine oil temperature.
Press buttonè orÿ repeatedly
until the AMG menu appears in the mul-
tifunction display.
1Gear indicator
2Engine oil temperatureUse buttonsk orj to select the
following functions in the AMG menu:
FunctionPage
Calling up digital speedometer145
Calling up maintenance display330
Checking tire inflation pressure303
iThis function is only available in AMG vehi-
cles.
iThe engine oil temperature flashes if the en-
gine oil temperature has not yet reached 80°C.
During this time, avoid driving at full engine
speed.
FunctionPage
Vehicle supply voltage146
RACETIMER146
Overall analysis148
Lap analysis148
iIf the engine reaches the overspeed range in
the manual shift program, the menu will be
shown in red. In addition, you will see
UP next to
gear indicator1 as a reminder to upshift.

146 Controls in detail
Control system
Vehicle supply voltage
Press buttonè orÿ repeatedly
until the AMG menu appears in the mul-
tifunction display.
Press buttonj repeatedly until the
vehicle supply voltage appears in the
multifunction display.
1Gear indicator
2Vehicle supply voltageRACETIMER
The RACETIMER allows you to time and
save driving stretches in hours, minutes
and seconds.
Press button è or ÿ repeatedly
until the AMG menu appears in the mul-
tifunction display.
Press button j repeatedly until the
RACETIMER appears in the multifunc-
tion display.1Gear indicator
2RACETIMER
3Lap
Starting the RACETIMERPress button æ.
The timer starts.
Warning!G
The RACETIMER feature is only for use on
roads and in conditions where high speed
driving is permitted. Racing on public roads
is prohibited under all circumstances and
the driver is and must always remain re-
sponsible for following posted speed limits.
iYou can start the RACETIMER when the
engine is running or the starter switch is in
position2 (
page 38).
iWhile the RACETIMER is being displayed,
you cannot adjust the volume using
buttonsæ or ç.

147 Controls in detail
Control system
Displaying intermediate time
Press button ç while the timer is
running.
The intermediate time is shown for
5 seconds.
Stopping the RACETIMER
Press button æ.
The timer stops.
Saving lap time and starting a new lap
Press button ç while the timer is
running.
The intermediate time will be shown for
5 seconds.
Press button ç within the next
5 seconds.
The intermediate time shown will be
saved as a lap time.
The RACETIMER begins timing the new
lap. The new lap begins to be timed as
soon as the intermediate time is called
up.
1Gear indicator
2RACETIMER
3Best lap time
4Lap numberResetting current lap
Press button æ while the timer is
running.
The timer stops.
Press button ç.
The lap time is reset to “0”.
Deleting all laps
Press button æ while the timer is
running.
The timer stops.
Press the reset button twice
(
page 26).
Press button æ.
The timer starts. The saved laps are de-
leted.
iWhen you stop the vehicle and turn the
Smartkey to position 1 (
page 38) or, in vehi-
cles with KEYLESS-GO*, turn off the engine and
do not open the driver’s door, the RACETIMER
stops timing. Timing is resumed when you
switch the ignition back on (
page 38) or
restart the engine (
page 51) and then press
buttonæ.
iYou can save up to nine laps.
iIt is not possible to delete a single saved lap.
iWhen you switch off the engine, the
RACETIMER will be reset to “0” after
30 seconds. All laps are deleted.

148 Controls in detail
Control system
Overall analysis
Press button è or ÿ repeatedly
until the AMG menu appears in the mul-
tifunction display.
Press button j repeatedly until the
overall analysis appears in the multi-
function display.
1Overall analysis of RACETIMER
2Overall driving time
3Maximum speed
4Overall distance driven
5Average speedLap analysis
Press button è or ÿ repeatedly
until the AMG menu appears in the mul-
tifunction display.
Press button j repeatedly until the
lap analysis appears in the multifunc-
tion display.
1Lap number
2Lap time
3Maximum speed
4Lap length
5Average speed during lap
Press button j or k to see other
lap analyses.
AUDIO menu
The functions in the
AUDIO menu operate
the audio equipment which you currently
have turned on.
If no audio equipment is currently turned
on, the message
AUDIO off is shown in the
multifunction display.
The following functions are available:
iThese functions are only available if you
have saved at least one lap and have stopped the
RACETIMER.iThese functions are only available if you
have saved at least two laps and have stopped
the RACETIMER.
iEach lap is shown in its own submenu. The
fastest lap is indicated by flashing symbol 1.
FunctionPage
Selecting radio station149
Selecting satellite radio station*149
Operating CD player149

149 Controls in detail
Control system
Selecting radio station
Turn on COMAND and select radio.
Refer to separate COMAND operating
instructions.
Press buttonè orÿ repeatedly
until the currently tuned station in the
multifunction display appears.
1Waveband setting
2Station frequency
Press buttonk orj repeatedly
until the desired station is found.Selecting satellite radio station*
(USA only)
The satellite radio is treated as a radio
application.
Select SAT radio with the correspond-
ing softkey in the radio menu.
1SAT mode and preset number
2Setting for station selection using
memory
3Channel name or number
Press buttonk orj repeatedly
until the desired channel is found.Operating CD player
Selecting CD track
Turn on COMAND and select CD or
CD changer. Refer to separate
COMAND operating instructions.
Press buttonè orÿ repeatedly
until the settings for the CD currently
being played appear in the multifunc-
tion display.

iYou can only store new stations using the
corresponding feature on the radio, see separate
operating instructions.
You can also operate the radio in the usual man-
ner.iAdditional optional satellite radio equipment
and a subscription to satellite radio service pro-
vider are required for satellite radio operation.
Contact an authorized Mercedes-Benz Center
for details and availability for your vehicle.
For more information, refer to separate
COMAND operating instructions.
iThe COMAND system and the CD changer
can play audio CDs as well as MP3-CDs.
For more information on operating the
CD changer refer to separate COMAND operat-
ing instructions.


150 Controls in detail
Control system
1Current CD (for CD changer)
2Current track
Press buttonk orj repeatedly
until the desired track is selected.Selecting MP3-CD track
Turn on COMAND and select CD or
CD changer*. Refer to separate
COMAND operating instructions.
Press buttonè orÿ repeatedly
until the settings for the MP3-CD cur-
rently being played appear in the multi-
function display.
1MP3 mode
2Current track
NAV* menu
The
NAV menu contains the functions
needed to operate your navigation system.
Press buttonè orÿ repeatedly
until the message
NAV appears in the
multifunction display.

If COMAND is switched off, the mes-
sage
NAV off is shown in the multi-
function display.

With COMAND switched on but route
guidance not activated, the direction of
travel and, if available, the name of the
street currently traveled on appear in
the multifunction display.

With COMAND switched on and route
guidance activated, the direction of
travel and maneuver instructions ap-
pear in the multifunction display.
Please refer to the COMAND manual for
instructions on how to activate the route
guidance system.
iTo select a CD from the CD changer maga-
zine, press a number on the COMAND system
key pad located in the center console.
iLevel of information displayed will vary de-
pending on the information contained on the
MP3-CD insert in the single CD player of the
COMAND system.
To select a MP3-CD from the CD changer maga-
zine, press a number on the COMAND system
key pad located in the center console.


151 Controls in detail
Control system
Distronic* menu
Use the Distronic menu to display the cur-
rent settings for your Distronic system.
What information is shown in the multi-
function display depends on whether the
Distronic system is active or inactive.
Please refer to the “Driving systems”
section of this manual (
page 217) for
instructions on how to activate Distronic.
Press buttonè orÿ repeatedly
until one of the following two pictures
appears in the multifunction display.Distronic deactivated
When Distronic is deactivated, you will see
the standard display in the multifunction
display.
1Vehicle ahead, if detected
2Actual distance to vehicle ahead
3Preset distance threshold to vehicle
ahead
4Your vehicle
5Symbol for activated distance warning
functionDistronic activated
With Distronic activated, the
Distronic
display is shown in the multifunction dis-
play and one or two segments around the
set speed are illuminated in the speedom-
eter.
1Distronic activated
Vehicle status message memory menu
Use the vehicle status message memory
menu to scan malfunction and warning
messages that may be stored in the sys-
tem. Such messages appear in the multi-
function display and are based on
conditions or system status the vehicle’s
system has recorded.
