128 Controls in detail
Lighting
Daytime running lamp mode
Turn exterior lamp switch to
positionM orU.
When the engine is running, the low
beam headlamps are switched on.
In low ambient light conditions, the fol-
lowing lamps will switch on additional-
ly:

Tail and parking lamps

License plate lamps

Side marker lamps
Canada only
The daytime running lamp mode is manda-
tory and therefore in a constant mode.When the engine is running, and you shift
from a driving position to positionN orP,
the low beam headlamps will switch off
with a 3-minute delay.
When the engine is running, and you
turn the exterior lamp switch to
positionC, the parking lamps and
the side marker lamps switch on addi-
tionally.

turn the exterior lamp switch to
positionB, the manual headlamp
mode has priority over the daytime run-
ning lamp mode.
The corresponding exterior lamps
switch on (
page 126).USA only
By default, the daytime running lamp mode
is deactivated. Activate the daytime run-
ning lamp mode using the control system,
see “Setting daytime running lamp mode
(USA only)” (
page 159).
When the engine is running, and you turn
the exterior lamp switch to position C
orB, the manual headlamp mode has
priority over the daytime running lamp
mode.
The corresponding exterior lamps switch
on (
page 126).
iWith the daytime running lamp mode activat-
ed and the engine running, the low beam head-
lamps cannot be switched off manually.
iWith the exterior lamp switch in position
M or U, you cannot switch on the high
beam headlamps.
The high beam flasher is available at all times.
For nighttime driving you should turn the exterior
lamp switch to positionB to permit activa-
tion of the high beam headlamps.
iWith the daytime running lamp mode
activated and the exterior lamp switch in
position M, you cannot switch on the high
beam headlamps.
The high beam flasher is available at all times.
For nighttime driving you should turn the exterior
lamp switch to positionB or U to permit
activation of the high beam headlamps.

129 Controls in detail
Lighting
Locator lighting and night security
illumination
Locator lighting and night security illumi-
nation are described in the “Control sys-
tem” section, see “Setting locator lighting”
(
page 160) and “Setting night security il-
lumination (Headlamps delayed shut-off)”
(
page 161).
Fog lamps
Front fog lamps
Switch on the low beam
headlampsB (
page 55).
Pull out exterior lamp switch to first
stop.
The front fog lamps switch on.
The green indicator lamp‡ in the
exterior lamp switch comes on
(
page 126).
Push in the exterior lamp switch.
The front fog lamps are switched off.
The green indicator lamp‡ in the
exterior lamp switch goes out.
Rear fog lamp (driver’s side only)
Switch on the low beam
headlampsB (
page 55).
Pull out exterior lamp switch to second
stop.
The front fog lamps and the rear fog
lamp switch on.
The yellow indicator lamp† in the
exterior lamp switch comes on
(
page 126).
Push in the exterior lamp switch to first
stop.
The rear fog lamp is switched off.
The yellow indicator lamp† in the
exterior lamp switch goes out.
The front fog lamps remain lit.
Warning!G
In low ambient lighting or foggy conditions,
only switch from positionU to B with
the vehicle at a standstill in a safe location.
Switching fromU to B will briefly
switch off the headlamps. Doing so while
driving in low ambient lighting conditions
may result in an accident.
iFog lamps will operate with the parking
lamps and/or the low beam headlamps on. Fog
lamps should only be used in conjunction with
low beam headlamps. Consult your State or
Province Motor Vehicle Regulations regarding
permissible lamp operation.
iFog lamps cannot be switched on with the
exterior lamp switch in positionU. To switch
on the fog lamps, turn the exterior lamp switch
to positionB first.

130 Controls in detail
Lighting
Combination switch
Combination switch
1High beam
2High beam flasherHigh beam
Turn the exterior lamp switch to
positionB (
page 126).
Push the combination switch in direc-
tion of arrow1 to switch on the high
beam.
The high beam headlamp indicator
lampA in the instrument cluster
comes on (
page 26).
Pull the combination switch in direction
of arrow2 to its original position to
switch off the high beam.
The high beam headlamp indicator
lampA in the instrument cluster
goes out.
High beam flasher
Pull the combination switch briefly in
direction of arrow2.Corner-illuminating front fog lamps*
(CLS 550 with Bi-Xenon* headlamps
only)
The corner-illuminating front fog lamps im-
prove illumination of the area in the direc-
tion into which you are turning.
Corner-illuminating front fog lamps will op-
erate with the engine running and with

the exterior lamp switch in
positionB (
page 126)
or

the exterior lamp switch in
positionU (
page 126)
or

the daytime running lamp mode
activated (
page 128)
iWith the automatic headlamp mode activat-
ed: The corner-illuminating front fog lamps will
only come on in low ambient lighting conditions.

131 Controls in detail
Lighting
Driving forward
Switching on corner-illuminating front
fog lamps
Switch on the left or right turn signal
(
page 55), depending on whether
you are turning left or right.
The respective front fog lamp comes on
and illuminates the area in the direc-
tion into which you are turning.
or
Turn steering wheel in desired direc-
tion.
The front fog lamp on the side of your
steering direction comes on.Switching off corner-illuminating front
fog lamps
The combination switch for the turn signal
resets automatically after major steering
wheel movements. This will switch off the
corner-illuminating front fog lamps if they
where activated by switching on the left or
right turn signal.
If the turn signal should stay on after mak-
ing the turn, the turn signal and corner-illu-
minating front fog lamps can be switched
off by returning the combination switch to
its original position.
iIf you are driving faster than 25 mph
(40 km/h) or have the front fog lamps switched
on, the corner-illuminating function is not avail-
able.iIf you have switched on the turn signal for
one side but turn the steering wheel in the other
direction, the corner-illuminating lamp lights up
on the side of the turn signal.
The corner-illuminating front fog lamp remains lit
for a maximum of three minutes. Afterward, it
goes out even if the turn signal is still switched
on.
iThe corner-illuminating front fog lamps tem-
porarily come on on both sides of the vehicle if
you turn the steering wheel in one direction and
then in the other direction shortly thereafter.
iThe corner-illuminating front fog lamps will
come on automatically depending on the steer-
ing angle, even if you did not switch on either
turn signal. If the corner-illuminating front fog
lamps came on automatically, they will also go
out automatically depending on the steering
angle.
iThere may be a brief delay before the cor-
ner-illuminating front fog lamps switch off.

132 Controls in detail
Lighting
Driving in reverse
Switching on corner-illuminating front
fog lamps
Place the gear selector lever in
positionR.
The front fog lamp opposite to your
steering direction comes on.
Switching off corner-illuminating front
fog lamps
Place the gear selector lever out of
positionR.
The respective front fog lamp goes out.
Hazard warning flasher
The hazard warning flasher can be
switched on at all times, even with the
SmartKey removed from the starter switch
or with the SmartKey with KEYLESS-GO*
removed from the vehicle.
The hazard warning flasher switches on
automatically when an air bag deploys.
The hazard warning flasher switch is locat-
ed on the center console.
1Hazard warning flasher switchSwitching on hazard warning flasher
Press the hazard warning flasher
switch1.
All turn signals are flashing.
Switching off hazard warning flasher
Press hazard warning flasher switch1
again.
iWith the hazard warning flasher activated
and the combination switch set for either left or
right turn, only the respective left or right turn
signals will operate when the ignition is switched
on.
iIf the hazard warning flasher has been acti-
vated automatically, press hazard warning flash-
er switch1 once to switch off.

133 Controls in detail
Lighting
Interior lighting in the front
The controls are located in the overhead
control panel.1Left front reading lamp on/off
2Rear interior lighting on/off
3Automatic control on/off
4Front interior lighting on/off
5Right front reading lamp on/off
6Interior lighting
7Ambient lighting
8Front reading lamps
Deactivating automatic control
Press switch3.
The interior lighting remains switched
off in darkness, even when you:

unlock the vehicle

remove the SmartKey from the
starter switch

open a door

open the trunk
Activating automatic control
Press switch3.
The interior lighting switches on in
darkness, when you:

unlock the vehicle

remove the SmartKey from the
starter switch

open a door

open the trunk
The interior lighting switches off after a
preset time (
page 162).
!An interior lamp switched on manually does
not go out automatically.
Leaving an interior lamp switch in the ON posi-
tion for extended periods of time with the engine
turned off could result in a discharged battery.
iThe interior lighting is factory-set to auto-
matic mode.
iIf a door remains open, the interior lamps
switch off automatically after approximately
5minutes.

134 Controls in detail
Lighting
Manual control
Switching front/rear interior lighting on
and off
Press front/rear interior lighting
switch4 or2 to switch on the
desired interior light.
Press front/rear interior lighting
switch4 or2 again to switch off the
respective interior light.
Switching front reading lamps on and off
The front reading lamps are located in the
interior rear view mirror.
Press front reading lamp
switch1or5 to switch on the
desired front reading lamp.
Press front reading lamp
switch1or5 again to switch off the
respective front reading lamp.Ambient lighting
You can switch the ambient lighting7
(
page 133) on and off, using the “Control
system” (
page 161).
Interior lighting in the rear
The overhead control panel is located
above the rear seat bench.
1Left reading lamp on/off
2Left reading lamp
3Right reading lamp
4Right reading lamp on/off
5Rear interior lamp

135 Controls in detail
Lighting
Rear reading lamps
Press rear reading lamp switch1
or4 to switch on the respective rear
reading lamp.
Press rear reading lamp switch1
or4 again to switch off the respective
rear reading lamp.
Door entry lamps
For better orientation in the dark, the cor-
responding door entry lamps will switch on
in darkness when you open a door and the
automatic control is activated.
The door entry lamps will switch off when
the corresponding door is closed.Trunk lamp
The trunk lamp switches on if the trunk is
opened.
If the trunk remains open, the trunk light-
ing switches off automatically after ap-
proximately 10 minutes.
iIf you turn the SmartKey in the starter
switch to position0 and switch off the head-
lamps, the door entry lamps will remain lit for ap-
proximately 5 minutes.
