43 Audio
Radio
There are 10 presets available for FM, AM
and SatRadio* wavebands.
Storing stations manually
Press n if the display/selection win-
dow is highlighted.
or
Select “Presets” in the radio display.
In both cases, the station memory will
appear. The dotRin front of a preset
indicates that the currently tuned sta-
tion is stored there.
Station memory
To store a station to a selected pre-
set: Press and hold n until a signal
tone sounds.
or
Press and hold a number key, e.g. 4,
until a signal tone sounds.
The station is stored.
Storing via Autostore
i The function automatically assigns receiv-
able stations to the presets, sorted according to
reception quality. The stations which were
stored in the station memory manually are over-
written.
Press n if the display/selection win-
dow is active.
Select “Autostore”.
or
Select “Presets” K “Autostore” in the
radio display.
COMAND searches for receivable sta-
tions. A corresponding message is dis-
played. The available stations are
automatically stored under the presets.
Cancelling Autostore procedure
Select “Cancel”.
WavebandsFrequency
AM (MF)530 - 1700 kHz
FM (VHF)87.7 - 107.9 MHz
WB (Weather Band)Weather channels
Storing stations

49 Audio
Satellite radio*
Press ß on the control unit.
To enter a channel: Press correspond-
ing number buttons on the control unit.
i You can only select numbers that are cur-
rently permissible.
COMAND will tune to the channel en-
tered.
Selecting a channel from the SatRadio
channel list
Select “SatRadio” K “Channel List” in
the SatRadio menu.
The channel list appears.
To select a channel: Rotate ymz or
slide qmr.
To tune to the selected channel:
Press n.
Memory functions
i There are 10 presets available.
You can use the following functions:
Saving channels manually
Selecting a channel from the Satellite
preset memory (

page 50)
Storing channels manually
Press n if the display/selection win-
dow is highlighted.
or
Select “Presets” on the SatRadio sub-
menu bar.
In both cases, the channel memory will
appear. The dotRin front of a preset
indicates that the currently tuned chan-
nel is stored there.
Station memory
To select a preset: Rotate ymz or
slide qmr.
To store a channel to a selected pre-
set: Press and hold n until a signal
tone sounds.
or
Press and hold a number key, e.g. 4,
until a signal tone sounds.
The channel is stored.

66 Audio
CD audio/DVD audio and MP3
It is only possible to set the audio format in
DVD audio mode. The number of available
audio formats is dependent on the DVD.
The content of an audio DVD is called the
‘album’, which can be divided into a maxi-
mum of nine groups. A group may contain,
for example, music of different sound qual-
ities (stereo and multi-channel formats) or
bonus tracks. Each group can include up to
99 tracks. If a DVD audio only comprises
one audio format, the “Group” menu
item(s) cannot be selected.
Switch to DVD audio mode
(

page 60).
Select “DVD-A” K “Group”.
The list of available audio formats ap-
pears. A dotRindicates the format
currently selected.
To change setting: Rotate ymz or
slide qmr.
Press n.
To exit menu: Slide omp.The following options are available:
“Normal Track Sequence”
You will hear the tracks in the normal
sequence (e. g. track 1, 2, 3 etc.).
“Random Tracks”
You will hear the tracks in random or-
der (e. g. track 3, 8, 5 etc.).
“Folder” (only in MP3 mode)
The tracks in the currently active folder
and any subfolders are heard in ran-
dom order.
To select an option: Switch to CD au-
dio, DVD audio or MP3 mode
(

page 60).
Select “CD” or “DVD-A” or “MP3”.
The Options list appears. A dotRindi-
cates the activated option.
Select an option.
The option is activated. A correspond-
ing display will appear in the display/
selection window for all options except
“Normal Track Sequence”.
i The option “Normal Track Sequence” is au-
tomatically activated if you change the medium
which is currently being played or if you select
another medium. An activated option remains
active after COMAND is switched on or off.
Setting audio formatPlayback options

70 Audio
Music Register
To switch to the next folder up: Se-
lect theQsymbol.
The display changes to the next folder
up.
Changing folder/track name
Select “Folder”.
To select a folder/track: Rotate ymz
or slide qmr.
Select “Options” K “Change”.
Enter a name for the folder/track in the
input line.
To save change: Select B.
Deleting folder/track
Select “Folder”.
To select a folder/track: Rotate ymz
or slide qmr.
Select “Options” K “Delete”.
A prompt appears. “No” is highlighted.
Do not delete: Press n.
To delete: Select “Yes” and press n.
A message appears.The following options are available:
“Normal Track Sequence”
You will hear the tracks in the normal
sequence (e. g. track 1, 2, 3 etc.).
“Random Tracks”
The tracks are played in random order.
“Random Folder”
The tracks of the currently active folder
and any subfolders are heard in ran-
dom order.
To select an option: Switch to Music
Register (

page 67).
Select “Music Register” in the sub-
menu.
The Options list appears. A dotRindi-
cates the activated option.
Select an option.
The option is activated. A correspond-
ing display will appear in the display/
selection window for all options except
“Normal Track Sequence”.
i The option “Normal Track Sequence” is au-
tomatically activated if you change the medium
which is currently being played or if you select
another medium. An activated option remains
active after COMAND is switched on or off.Playback options

78 Video
DVD video
Slide and hold omp until the desired
point is reached.
or
Press and hold G or H on the
control unit until the desired point is
reached.
The control menu will appear.
In DVD video mode, if necessary dis-
play the menu system (
page 77).
Select “Changer”.
The media list appears. The dotRindi-
cates the medium currently playing.
Media list
1Symbol for DVD video
2DVD Video currently playing
To select DVD video I: Rotate ymz
or slide qmr.
Press n.
COMAND switches the medium.
i If you select a CD-/DVD-audio or MP3 me-
dium, the system switches to the corresponding
audio mode (
page 60).
Further information on the media list can be
found on (
page 62).
In DVD video mode, if necessary dis-
play the menu system (
page 77).
To interrupt playback: Select h.
The g display changes to T.
To resume playback: Select T.
Playback will then continue at the point
at which it was interrupted. The menu
system is hidden.
To stop playback: Press h again
when playback is stopped.
or
Select h twice in immediate succes-
sion during playback.
The option selector remains at T.
To restart playback: Select T.
Playback will start from the beginning.
The menu system is hidden.
Fast forward/reverse
Selecting DVD media
Stop function

81 Video
DVD video
Stopping film or skipping to the
beginning/end of a scene
Select any menu item from the DVD
menu.
The selection menu appears.
To stop a film: Select the menu item
“Stop”.
To skip to the end of the scene: Se-
lect the menu item r.
To skip to the beginning of the
scene: Select the menu item p.
i Depending on the DVD, it is possible the
menu items p and r either have no func-
tion or no function in certain parts of the DVD
menu. This is indicated by the 7 symbol on the
display.
Switching to the next DVD menu up
Press the í button.
or
Select the corresponding menu item
from the DVD menu.
or
Select any menu item from the DVD
menu.
In the selection menu select the menu
item “Go Up”.
i Depending on the DVD, it is possible the
menu item “Go Up” either has no function or no
function in certain parts of the DVD menu. This is
indicated by the 7 symbol on the display.
Back to movie
Press the í button repeatedly until
the film is shown.
or
Select the corresponding menu item
from the DVD menu.
or
Select any menu item from the DVD
menu.
In the selection menu select the menu
item “Back (to movie)”.
i Depending on the DVD, it is possible the
menu item “Back (to movie)” either has no func-
tion or no function in certain parts of the DVD
menu.
i The function is not available for all DVDs. If
it is available, you can set the DVD menu lan-
guage, the audio language or the audio format.
The number of settings is determined by the DVD
content. The settings may also be possible in the
DVD menu (
page 80).
In DVD video mode, if necessary dis-
play the menu system (
page 77).
Select “DVD-Video” K “DVD Func-
tions”.
Select “Audio Language”.
A selection menu will appear after a
short time. The dotRin front of an en-
try indicates the currently selected lan-
guage.
To change setting: Rotate ymz or
slide qmr until the desired setting is
reached.
To save setting: Press n.
To exit menu without changes: Slide
omp.
Setting language

119 Navigation
Introduction
Displaying/hiding menu system
To hide: Slide qm and when the menu
item “Full Screen” is displayed press
n.
The menu system is hidden. This dis-
plays the map in full screen mode.
To display: In full-screen map mode
press n.
or
Press the function button z.
Setting the map scale
i You can only set the map scale when the
menu system is hidden (map in full-screen
mode).
Rotate ymz until the required map
scale is set.
The map scale 3 is displayed as soon
as you start rotating ymz. Rotating
clockwise makes the map smaller, ro-
tating anticlockwise enlarges it.1Currently set map scale as number,
here 1 mi (1 inch on the map corre-
sponds to 1 mi)
2Indicator on the map scale pointing to
the currently selected map scale
3Map scale
Saving current vehicle location as des-
tination in the last destinations
To display menu system if applica-
ble: Press n.
To save: Select “Position” K “Save Ve-
hicle Position”.
COMAND saves the current vehicle lo-
cation as a destination in the last desti-
nations memory (
page 162). A
window appears containing a corre-
sponding message.
To exit menu: Slide omp or press the
í button.
Scrolling the map
i You can only scroll the map when the menu
system is hidden.
Hide menu system if applicable
(
page 119).
Slide qmr, omp or wmx.
Crosshairs will appear on the map.
1Current vehicle location
2Crosshairs
3Information on crosshairs position
4Set map scale
i The display 3 may for example be a road if
corresponding data is available in the digital map
and “Current Street” is activated. Or it displays
the geo-coordinate position of the crosshairs if
“Geo-coordinates” display is activated.
(
page 124).

120 Navigation
Introduction
Saving crosshairs position as destina-
tion in the last destinations
To display menu system if applica-
ble: Press n.
To save: Select “Position” K “Save
Crosshair Position”.
COMAND saves the crosshairs position
as a destination in the last destinations
memory (
page 162). A window ap-
pears containing a corresponding mes-
sage.
Hiding crosshairs
Press the í button.
The crosshairs disappear and the map
is set to the vehicle location.
or
Set the map to the vehicle location, see
description below.Setting map to vehicle or destination
location
i If you have moved the map, you can quickly
move the map to the vehicle or destination loca-
tion using this function. It is only possible to set
it to the destination location when route guid-
ance is active.
To display menu system if applica-
ble: Press n.
To set map to vehicle location:
Select “Position”
K “Vehicle Position
Map”.
or
Press the í button if the crosshairs
are displayed.
i This hides the crosshairs.
To set to destination location: Select
“Position”
K “Destination Position
Map”.
The crosshairs position is then set to
the destination.
i You can perform the settings listed below
with route guidance inactive or active.
Map display
Map orientation
1Currently set map orientation
The following displays are possible:

9 = orientation to north (the map dis-
play is oriented to the north, north is al-
ways at the top)

8 = Driving direction (the map display
is oriented in the direction of travel, the
direction of travel is always at the top,
the orange tip of the symbol points
northwards)
Basic settings
