2008 JEEP WRANGLER UNLIMITED Owners Manual

1 — Zipper Start
2 — Zipper Finish
3 — Swing Gate Bar
4 — Swing Gate Brackets
5 — Sail Panels
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3

3. Unclip and move the sun visors to the side.
4. Release the header latches and leave the hooks in the
loops on the windshield.5. Open the swing gate.
6. Before unzipping the rear window, release the first 3 in
(7.6 cm) of both sail panels from the channel. Remove the
swing gate bar by pulling it straight rearward out of the
swing gate brackets.

3

10. Finish releasing the sail panel retainers from the body
side channel at the rear corners of the vehicle.
NOTE:When releasing the sail panel retainers, it is
helpful to pull down on the rear roof bow. 11. As you begin to lower the top, fold the sail panels so
that they rest on top of the soft top.

3

14. Make sure the plastic sleeves are slid forward over
the Sunrider link (Sunrider Models Only).15. Unlatch the side bows from both door rails (Sunrider
Models Only).

3
