2008 JEEP WRANGLER UNLIMITED Owners Manual

DUAL TOP — IF EQUIPPED
If your vehicle is equipped with a Dual Top,you must
remove one of the tops from the vehicle. If the soft top
is removed, the pivot brackets must also be removed
from the sport bar. The soft top was installed at the
factory for shipping purposes only. The soft top and the
hard top are to be used independently. Removal is
mandatory to prevent any possible wear and tear on the
soft top. Your vehicle warranty will not cover damage
resulting from both tops remaining on the vehicle at the
same time for extended periods of time.
Removing The Soft Top
1. Locate and remove the two boxes that contain the
following items:
•Right and left door frames
•Door frame attachment knobs (four for two-door
models, six for four-door models)
•Right and left quarter windows
•Rear window
•Two rear window roll up straps
•Two Sunrider secure straps (If Equipped)
•Two rear swing gate brackets
2. Remove the hard top. Refer to “Freedom Top Three-
Piece Modular Hard Top — Front/Rear Panel Removal”
later in this section.
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3

5. Unzip the zipper on the sport bar cover to expose the
pivot brackets. Remove the brackets using a #T30 Torx
head driver. Recover and re-zip the sports bar cover.
Store pivot brackets and screws in a safe place.
6. Reinstall the hard top. Refer to “Freedom Top Three-
Piece Modular Hard Top — Front/Rear Panel Installa-
tion” later in this section.Installing the Soft Top
NOTE:The following procedures are for first time set
up only. For future soft top procedures, refer to “Soft
Top” in this section.
1. Locate and remove the following items prior to hard
top removal:
•Right and left door frames
•Door frame attachment knobs (four for two-door
models, six for four-door models)
•Right and left quarter windows
•Rear window
2. Remove the hard top. Refer to “Freedom Top Three-
Piece Modular Hard Top — Front/Rear Panel Removal”
later in this section.

3

c. Tap the knuckles on the side with a rubber mallet to
reattach them to the metal pivot brackets.
d. Screw the pivot screws back into place using a #T30
Torxhead driver. Secure them until they are snug
being careful not to cross-thread the screws or over-
tighten.

3

Front Panel(s) Removal
NOTE:Left panel must be removed before removing
right panel.
1. Fold down the sun visor, and move to the side.
2. Turn center L-shaped locks (2) from center of roof
panel. 3. Turn rear L-shaped lock (located above shoulder belt
anchorage).
