TROUBLE DIAGNOSISBRC-25
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
ACTUATOR RLY Actuator relay operation status Actuator (solenoid) is active
(“ACTIVE TEST” with CONSULT-III)
ON
When actuator relay is inactive
(in fail-safe mode) OFF
OFF LAMP VDC OFF indicator lamp status
(Note 3) When VDC OFF indicator lamp is ON ON
When VDC OFF indicator lamp is OFF OFF
SLIP LAMP SLIP indicator lamp status
(Note 4) When SLIP indicator lamp is ON ON
When SLIP indicator lamp is OFF OFF
FR LH IN SOL
FR LH OUT SOL
FR RH IN SOL
FR RH OUT SOL
RR RH IN SOL
RR RH OUT SOL
RR LH IN SOL
RR LH OUT SOL Solenoid valve operation Actuator (solenoid) is active (“ACTIVE
TEST” with CONSULT-III) and actuator re-
lay is active (ignition switch ON)
ON
When actuator (solenoid) is not active or
actuator relay is inactive (in fail-safe
mode) OFF
CV1
CV2
SV1
SV2 VDC/TCS switch-over valve status When actuator (switch-over valve) is ac-
tive (“ACTIVE TEST” with CONSULT-III)
and actuator relay is active (ignition switch
ON)
ON
When actuator (switch-over valve) is not
active or actuator relay is inactive (in fail-
safe mode) OFF
DECEL G-SEN Longitudinal acceleration detected by decel
G sensor (Note 5) Vehicle stopped Approx. 0 G
Vehicle running -1.7 to +1.7 G
FLUID LEV SW ON/OFF status of brake fluid level switch When brake fluid level switch ON ON
When brake fluid level switch OFF OFF
VDC FAIL SIG
TCS FAIL SIG
ABS FAIL SIG
EBD FAIL SIG Fail signal status VDC fail
TCS fail
ABS fail
EBD fail
ON
VDC normal
TCS normal
ABS normal
EBD normal OFF
EBD WARN LAMP Brake warning lamp on condition
(Note 6) Brake warning lamp ON ON
Brake warning lamp OFF OFF
EBD SIGNAL EBD operation EBD active ON
EBD not active OFF
ABS SIGNAL ABS operation ABS active ON
ABS not active OFF
TCS SIGNAL TCS operation TCS active ON
TCS not active OFF
VDC SIGNAL VDC operation VDC active ON
VDC not active OFF
CRANKING SIG CRANKING status Cranking ON
Not cranking OFF
4WD FAIL REQ ETS fail status (Note 5) ETS fail ON
ETS normal OFF
Monitor item Display content
Data monitor
Condition Reference value in
normal operation
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BRC-26
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Note 1: Confirm tire pressure is normal.
Note 2: ON/OFF timing of ABS warning lamp
ON: Approx. Within 2 seconds after ignition switch is turned ON, or when a malfunction is detected.
OFF: Approx. 2 seconds after ignition switch is turned ON (when sy
stem is in normal operation) and VDC/TCS function is not activated.
Note 3: ON/OFF timing of VDC OFF indicator lamp
ON: Approx. Within 2 seconds after ignition switch is turned ON, or when a malfunction is detected and VDC OFF switch is ON.
OFF: Approx. 2 seconds after ignition switch is turned ON (when system is in normal operation.) And when VDC OFF switch is OFF.
Note 4: ON/OFF timing of SLIP indicator lamp
ON: Approx. Within 2 seconds after ignition switch is turned ON, or when a malfunction is detected and VDC/TCS function is activa ted
while driving.
OFF: Approx. 2 seconds after ignition switch is turned ON (when sy stem is in normal operation) and VDC/TCS function is not activated.
Flashing: VDC/TCS function is active during driving
Note 5: Only AWD models.
Note 6: Serves as EBD warning lamp.
CONSULT-III Functions (ABS)INFOID:0000000001327671
CONSULT-III MAIN FUNCTION
CONSULT-III can display each diagnostic item us ing the diagnostic test modes shown following.
Self-DiagnosisINFOID:0000000001327672
OPERATION PROCEDURE
Before performing the self-diagnosis, start engine and driv e vehicle at 30 km/h (19 MPH) or more for approxi-
mately 1 minute.
ERASE MEMORY
After erasing DTC memory, start engine and drive vehicle at 30 km/h (19 MPH) or more for approximately 1
minute as the final inspection, and make sure that the ABS warning lamp, VDC OFF indicator lamp, SLIP indi-
cator lamp and brake warning lamp turn OFF.
CAUTION:
If memory cannot be erased, perform applicably diagnosis.
NOTE:
 When the wheel sensor malfunctions, after inspecting the wheel sensor system, the ABS warning lamp,
VDC OFF indicator lamp, SLIP indicator lamp and br ake waning lamp will not turn OFF even when the sys-
tem is normal unless the vehicle is driving at approxim ately 30 km/h (19 MPH) or more for approximately 1
minute.
 Brake warning lamp will turn ON in case of parki ng brake operation (when switch is ON) or of brake fluid
level switch should not stay “ON” position.
 VDC OFF switch should not stay “ON” position.
2WD/4WD Drive axle 2WD model 2WD
AWD model AWD
Monitor item Display content
Data monitor
Condition Reference value in
normal operation
Diagnostic test mode Function
WORK SUPPORT This mode enables a technician to adjust some devices faster and more accurately by following the
indications on CONSULT-III.
SELF-DIAG RESULTS Self-diagnostic results can be read and erased quickly.
DATA MONITOR Input/Output data in the ABS actuator and electric unit (control unit) can be read.
CAN DIAG SUPPORT MNTR The results of transmit/receive diagnosis of communication can be read.
ACTIVE TEST Diagnostic Test Mode in which CONSULT-III drives
some actuators apart from the ABS actuator and
electric unit (control unit) and also shifts some parameters in a specified range.
FUNCTION TEST Performed by CONSULT-III inst ead of a technician to determine whether each system is “OK” or “NG”.
ECU PART NUMBER ABS actuator and electric unit (control unit) part number can be read.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BRC-28
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Note 1: After completing repairs of shorted sensor circuit, when turning ignition switch ON, ABS warning lamp turned on. Make t
hat ABS
warning lamp turned off while driving vehicle at approximately 30 km/h (19 MPH) or more for approximately 1 minute according to self-
diagnosis procedure. In addition, if whee l sensor 2 is displayed for wheels, check wheel sensor circuit and also check ABS actu ator and
electric unit (control unit) power voltage.
Note 2: If multiple malfunctions are detected including CAN communication line [U1000], perform diagnosis for CAN communication line
first.
Note 3: “ACTUATOR RLY” on the CONSULT-III self-diagnostic results indicates the malfunction of actuator relay or circuit. Actua tor relay
is imbedded in ABS actuator and electric unit (control unit).
Note 4:Only AWD models.
Data MonitorINFOID:0000000001327673
DISPLAY ITEM LIST
ENGINE SIGNAL 2
[C1131] Based on the signal from ECM, ABS ac
tuator and electric unit (control
unit) judges that engine ETC system is malfunctioning. BRC-42, "DTC C1131 ENGINE
SIGNAL 2"
ENGINE SIGNAL 3
[C1132]Based on the signal from ECM, ABS ac
tuator and electric unit (control
unit) judges that engine CAN system is malfunctioning. BRC-42, "DTC C1132 ENGINE
SIGNAL 3"
ENGINE SIGNAL 4
[C1133]Based on the signal from ECM, ABS ac
tuator and electric unit (control
unit) judges that engine torque down system is malfunctioning. BRC-42, "DTC C1133 ENGINE
SIGNAL 4"
ENGINE SIGNAL 6
[C1136]
Based on the signal from ECM, ABS ac
tuator and electric unit (control
unit) judges that engine control system is malfunctioning. BRC-42, "DTC C1136 ENGINE
SIGNAL 6"
ACTUATOR RLY
[C1140] (Note 3) Actuator solenoid valve relay is ON, even if control unit sends off sig-
nal.
 Actuator solenoid valve relay is OFF, even if control unit sends on sig- nal. BRC-43, "DTC C1140 ACTUA-
TOR RLY"
PRESS SEN CIRCUIT
[C1142]
Pressure sensor signal line is open or shorted, or sensor power voltage
is unusual, or pressure sensor is malfunctioning. BRC-43, "DTC C1142 PRESS
SEN CIRCUIT"
ST ANG SEN CIRCUIT
[C1143]Neutral position of steering angle sensor is dislocated, or steering angle
sensor is malfunctioning. BRC-44, "DTC C1143 ST ANG
SEN CIRCUIT"
ST ANG SEN SIGNAL
[C1144]
Neutral position correction of steering angle sensor is not finished. BRC-45, "DTC C1144 ST ANG
SEN SIGNAL"
YAW RATE SENSOR
[C1145]Yaw rate sensor has generated an error, or yaw rate sensor signal line
is open or shorted. BRC-46, "DTC C1145 YAW
RATE SENSOR"
SIDE G-SEN CIRCUIT
[C1146]Side G sensor is malfunctioning, or signal line of side G sensor is open
or shorted. BRC-46, "DTC C1146 SIDE G-
SEN CIRCUIT"
BR FLUID LEVEL LOW
[C1155]
Brake fluid level drops or
circuit between ABS actuat or and electric unit
(control unit) and brake fluid level switch is open or shorted. BRC-46, "DTC C1155 BR FLU-
ID LEVEL LOW"
ST ANG SEN COM CIR
[C1156]CAN communication line or steering angle sensor has generated an er-
ror. BRC-47, "DTC C1156 ST ANG
SEN COM CIR"
DECEL G SEN SET
[C1160] (Note 4)
Neutral position correction of decel G sensor is not finished.
BRC-47, "DTC C1160 DECEL G
SEN SET"
CV 1
[C1164]Primary side VDC switch-over solenoid valve 1 (cut valve 1) is open or
shorted, or control line is open or shorted to power supply or ground.
BRC-47, "DTC C1164 CV 1"
CV 2
[C1165]Secondary side VDC switch-over solenoid valve 2 (cut valve 2) is open
or shorted, or control line is open or shorted to power supply or ground.
BRC-47, "DTC C1165 CV 2"
SV 1
[C1166]Primary side VDC switch-over solenoid valve 1 (suction valve 1) is open
or shorted, or control line is open or shorted to power supply or ground.
BRC-47, "DTC C1166 SV 1"
SV 2
[C1167]Secondary side VDC switch-over solenoid valve 2 (suction valve 2) is
open or shorted, or control line is open or shorted to power supply or
ground.
BRC-47, "DTC C1167 SV 2"
VARIANT CODING
[C1170]
V coding is not functioning. BRC-48, "DTC C1170 VARIANT
CODING"
CAN COMM CIRCUIT
[U1000] (Note 2)When a ABS actuator and electric unit (control unit) is not transmitting
or receiving CAN communication signal for 2 seconds or more. BRC-48, "DTC U1000 CAN
COMM CIRCUIT"
Self-diagnostic item Malfunction detecting condition Check system
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BRC-32
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Basic Inspection
INFOID:0000000001327676
BRAKE FLUID AMOUNT, LEAKS, AND BRAKE PADS INSPECTION
1. Check fluid level in the brake reservoir tank. If fluid level is low, refill brake fluid.
2. Check brake piping and around ABS actuator and electric uni t (control unit) for leaks. If there is leaking or
oozing fluid, check the following items.
 If ABS actuator and electric unit (control unit) connec tion is loose, tighten piping to the specified torque
and re-perform the leak inspection to make sure there are no leaks.
 If there is damage to the connection flare nut or AB S actuator and electric unit (control unit) screw,
replace the damaged part and re-perform the leak inspection to make sure there are no leaks.
 When there is fluid leaking or oozing from a part other than ABS actuator and electric unit (control unit)
connection, if fluid is just oozing out, use a clean cl oth to wipe off the oozing fluid and re-check for leaks.
If fluid is still oozing out, replace the damaged part.
 When there is fluid leaking or oozing at ABS actuator and electric unit (control unit), if fluid is just oozing
out, use a clean cloth to wipe off oozing fluid and re-che ck for leaks. If fluid is still oozing out, replace
ABS actuator and electric unit (control unit) body.
CAUTION:
ABS actuator and electric unit (contr ol unit) body can not be disassembled.
3. Check brake pad degree of wear. Refer to BR-18, "
On-Vehicle Inspection" in “Front Disc Brake” and BR-
24, "On-Vehicle Inspection" in “Rear Disc Brake”
POWER SYSTEM TERMINAL LOOSENESS AND BATTERY INSPECTION
Make sure battery positive cable, negative cabl e and ground connection are not loose. If looseness is
detected, tighten the cables. In additi on, check the battery voltage to make sure it has not dropped and alter-
nator is normal.
ABS WARNING LAMP, VDC OFF INDICATOR LAMP, SLIP INDICATOR LAMP AND BRAKE WARN-
ING LAMP INSPECTION
Symptom Symptom description Result
Motor operation noise This is noise of motor in
side ABS actuator and electr ic unit (control unit).
Slight noise may occur during VDC, TCS, and ABS operation.
Normal
When the vehicle speed goes over 20 km/h (12.5 MPH), motor and valves
operating noise may be heard. It happens only once after ignition switch is
ON. This is a normal status of the system operation check.
System operation check noise When engine starts, slight “click” noise may be heard from engine room.
This is normal and is part of system operation check. Normal
VDC/TCS operation
(SLIP indicator lamp blinking) TCS may activate momentarily if wheel speed changes when driving over
location where friction coefficient varies, when up/downshifting, or when ful-
ly depressing accelerator pedal.
Normal
Cancel the VDC/TCS
function for the inspec-
tion on a chassis dyna-
mometer.
For inspection of speedometer or other instruments, press VDC OFF switch
to turn VDC/TCS function off.
When accelerator pedal is depressed on a chassis dynamometer (fixed
front-wheel type), vehicle speed will not increase. This is not normal. It is re-
sult of TCS being activated by stationary front wheels. Warning lamp may
also illuminate to indicate “sensor system error”. This is also normal, and is
the result of the stationary front wheels being detected. To be certain, restart
engine, and drive vehicle at 30 km/h (19 MPH) or more. Make sure warning
lamp does not illuminate.
ABS operation
(Longer stopping distance) On roads with low friction coefficients, such as snowy roads or gravel roads,
vehicles with ABS may require a longer stopping distance. Therefore, when
driving on such roads, avoid overconfidence and keep speed sufficiently
low.
Normal
Insufficient feeling of accelera-
tion Depending on road conditions, driver may feel that feeling of acceleration is
insufficient. This is because traction control, which controls engine and
brakes to achieve optimal traction, has the highest priority (for safety). As a
result, there may be times when acceleration is slightly less than usual for
the same accelerator pedal operation.
Normal
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISBRC-33
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
× : ON –: OFF
Note 1:Brake warning lamp will turn on in case of operating parking brake (switch turned on) or of actuating brake fluid level switch
(brake fluid is insufficient).
Note 2:After starting engine, turn OFF.
1. Make sure ABS warning lamp, VDC OFF indicator lamp (when VDC OFF switch is OFF), and SLIP indica- tor lamp turn on approximately 2 second, and brake warning lamp turns on when ignition switch is turned
ON. If they do not, check VDC OFF indicator lamp and then VDC OFF switch. Refer to BRC-48, "
Compo-
nent Inspection". Check CAN communications. Refer to “CAN Communication Inspection”. If there are no
errors with VDC OFF switch and CAN communication system, check combination meter. Refer to DI-5
.
2. Make sure ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp turn off approximately 2 sec- ond after turn ignition switch ON, and brake warning lamp turns off after engine starts. If lamps do not turn
off, perform self-diagnosis.
3. With engine running, make sure VDC OFF indicator lamp turns on and off when VDC OFF switch is turned ON and OFF. If indicator lamp status does not correspond to switch operation, check the VDC OFF
switch system. Refer to BRC-48, "
Component Inspection".
4. Make sure ABS warning lamp, VDC OFF indicator lamp, and SLIP indicator lamp turn off 2 seconds after engine is started. If ABS warning lamp, VDC OFF indicator lamp, and SLIP indicator lamp have not turned
off 10 seconds after engine has been started, perform self-diagnosis of ABS actuator and electric unit
(control unit).
5. After performing the self-diagnosis, be sure to erase the error memory. Refer to BRC-26, "
Self-Diagnosis".
NOTE:
Brake warning lamp will turn ON in case of parking brake operation (when switch is ON) or of brake fluid level
switch should not stay “ON” position.
Condition ABS warning
lamp VDC OFF in-
dicator lamp SLIP indicator
lamp Brake warning
lamp (Note 1) Remarks
Ignition switch OFF. – – – — —
Approx. 2 seconds after ignition
switch is turned ON. ×× ××
(Note 2) —
Approx. 2 seconds later after ig-
nition switch ON. –– –
× (Note 2) Go out 2 seconds after igni-
tion switch is turned ON.
VDC OFF switch is turned ON.
(VDC/TCS function is OFF.) –
× –— —
VDC/TCS/ABS error. ×× × —There is an ABS actuator
and electric unit (control unit)
error. (Power, ground or sys-
tem malfunction)
When VDC/TCS is not function-
ing normally. –
×× ——
EBD error. ×× × × —
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSIS FOR SYSTEMBRC-35
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
1. Turn ignition switch OFF and disconnect malfunctioning wheel sensor connector E46 (FR-LH), E33 (FR-RH) or B69 (RR) and
ABS actuator and electric unit (control unit) connector E56.
2. Check continuity between terminals. (Also check the continuity when steering wheel is turned right and left and when sensor
harness inside wheel well is moved.)
OK or NG
OK >> GO TO 6.
NG >> Repair or replace harness and connector that have malfunction.
6.CHECK WHEEL SENSOR POWER SUPPLY CIRCUIT
1. Disconnect malfunctioning wheel sensor connector.
2. Turn ignition switch ON and check voltage between wheel sen- sor harness connector power supply terminal and ground.
OK or NG?
OK >> Replace wheel sensor.
NG >> Replace ABS actuator and electric unit (control unit).
DTC C1102 RR LH SENSOR-1INFOID:0000000001569691
Refer to BRC-34, "DTC C1101 RR RH SENSOR-1".
DTC C1103 FR RH SENSOR-1INFOID:0000000001569692
Refer to BRC-34, "DTC C1101 RR RH SENSOR-1".
DTC C1104 FR LH SENSOR-1INFOID:0000000001569693
Refer to BRC-34, "DTC C1101 RR RH SENSOR-1".
SFIA1186E
Power supply circuit Signal circuit Ground circuit
Wheel ABS actuator
and electric unit (control unit) Wheel sensor ABS actuator
and electric unit (control unit) Wheel sensorABS actuator and elec-
tric unit (control unit) (signal) ABS actuator and elec-
tric unit (control unit) (ground)
Front RH 34 1 33 2 33, 34
16, 47
Front LH 45 1 46 2 45, 46
Rear RH 43 1 42 2 43, 42
Rear LH 36 3 37 4 36, 37
Power supply circuit : Continuity should exist.
Signal circuit : Continuity should exist.
Ground circuit : Continuity should not exist.
Wheel Wheel sensor Ground Voltage
Front RH 1
—8 V or more
Front LH 1
Rear RH 1
Rear LH 3
SFIA3364E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BRC-36
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SYSTEM
DTC C1105 RR RH SENSOR-2
INFOID:0000000001569694
Refer to BRC-34, "DTC C1101 RR RH SENSOR-1".
DTC C1106 RR LH SENSOR-2INFOID:0000000001569695
Refer to BRC-34, "DTC C1101 RR RH SENSOR-1".
DTC C1107 FR RH SENSOR-2INFOID:0000000001569696
Refer to BRC-34, "DTC C1101 RR RH SENSOR-1".
DTC C1108 FR LH SENSOR-2INFOID:0000000001569697
Refer to BRC-34, "DTC C1101 RR RH SENSOR-1".
DTC C1109 BATTERY VOLTAGE [ABNORMAL]INFOID:0000000001327685
INSPECTION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULTS (1)
Check the self-diagnostic results.
Does
“BATTERY VOLTAGE” appear in self-diagnostic results display?
YES >> GO TO 2.
NO >> INSPECTION END
2.CHECK SELF-DIAGNOSTIC RESULTS (2)
1. Disconnect ABS actuator and electric unit (contro l unit) connector. Then reconnect it securely.
2. Perform self-diagnosis.
Do any self-diagnosis item appear?
YES >> GO TO 3.
NO >> Poor connection. Repair or replace connector.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY CIRCUIT (1)
1. Disconnect ABS actuator and electric unit (control unit) connector E56.
2. Turn ignition switch OFF. Check voltage between ABS actuator and electric unit (control unit) harness connector and ground.
3. Turn ignition switch ON (but do not start engine). Check voltage between ABS actuator and electr ic unit (control unit) harness
connector and ground.
OK or NG
OK >> GO TO 4.
NG >> GO TO 5.
4.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Self-diagnostic results
BATTERY VOLTAGE [ABNORMAL]
ABS actuator and electric unit (control unit) Ground Voltage
32 — Battery voltage
(Approx. 12 V)
ABS actuator and electric unit (control unit) Ground Voltage 4— Battery voltage
(Approx. 12 V)
SFIA1200E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSIS FOR SYSTEMBRC-37
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Check ABS actuator and electric unit (control unit) ground circuit.
OK or NG
OK >> Perform ABS actuator and elec tric unit (control unit) self-
diagnosis again.
NG >> Repair or replace harness or connectors.
5.CHECK ABS ACTUATOR AND ELECTRIC UNIT (C ONTROL UNIT) POWER SUPPLY CIRCUIT (2)
1. Check fuse 10 A (terminal 4) and 30 A (terminal 32).
2. Turn ignition switch OFF and check continuity between battery positive terminal and ABS actuator and electric unit (control unit)
harness connector E56.
OK or NG
OK >> Check for non-standard conditions in battery (terminal looseness, low voltage, etc.) and alternator.
NG >>  Replace fuse 10 A or 30 A.
 Open or short in harness.
DTC C1110 CONTROLLER FAILUREINFOID:0000000001327679
INSPECTION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULTS
Check the self-diagnostic results.
Is the above displayed in the self-diagnosis display items?
YES >> Replace ABS actuator and electric unit (c ontrol unit). Perform the self-diagnosis again.
NO >> INSPECTION END
D T C C 1111 P U M P M O T O RINFOID:0000000001327684
INSPECTION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULTS (1)
Check the self-diagnostic results.
Is the above displayed in the self-diagnostic display items?
YES >> GO TO 2.
NO >> Inspection is completed.
2.CHECK SELF-DIAGNOSTIC RESULTS (2)
ABS actuator and electric unit (control unit) Ground Continuity
16 — Yes
SFIA1434E
ABS actuator and electric unit
(control unit) Battery positive terminal Continuity
4, 32 — Yes
SFIA1435E
Self-diagnostic results
CONTROLLER FAILURE VARIANT CODING
Self-diagnostic results PUMP MOTOR
ACTUATOR RLY
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
