Page 161 of 528
7. Close both cross locks at the center of the strap
system to secure tightly.
Panels 3, 2, 1 Loaded
2-79
Page 162 of 528
Reinstalling the Cargo Cover Panels
To reinstall a cargo panel do the following.
1. You can either leave the strap system attached
to the side of the cargo area while it is not in
use, or you can store it inside the top box storage
compartment. SeeTop-Box Storage on page 2-89
for more information.
2. Starting with cargo panel 1, place the latches in the
unlocked position. Place cargo panel 1 on the cargo
area rails while holding the back of the cargo
panel up.Push the panel forward until it is snug against the
midgate and then let the back of the panel down
being sure that the pegs align with the receivers.
Left Side Shown, Right Side Similar
2-80
Page 163 of 528
3. Push both left latches away from you to lock the
latches. Remember that there are four latches
total for panel 1. You should hear a click when
each latch locks. Lock the remaining two right
latches on panel 1.
For any cargo cover panel you must lock the left
latch in place before you can lock the right latch.
If you do not follow this exactly, the cargo cover
panels may not lock in place correctly.4. Install cargo cover 2 next. Place the latches in the
unlocked position. Place the cargo cover panel
on the cargo area rails while holding the back
of the cargo panel up.
Push the panel forward until it is snug against the
other panel and then let the back of the panel down
being sure that the pegs align with the receivers.Left Side Shown, Right Side Similar
2-81
Page 164 of 528
5. Push the latches away from you, starting with the
left latch, to lock the panel in place. You should
hear a click when each latch locks correctly.
6. Install cargo cover 3 next. Place the latches in the
unlocked position. Place the cargo cover panel on
the cargo area rails while holding the back of
the cargo panel up.Push the panel forward until it is snug against the
other panel and then let the back of the panel down
being sure that the pegs align with the receivers.
Left Side Shown, Right Side Similar
2-82
Page 165 of 528
7. Push the latches away from you, starting with the
left latch, to lock the panel in place. You should
hear a click when each latch locks.
Folding and Storage of Straps
To store the folding straps inside the top box storage
compartment, do the following:
1. Extend the six strap ends on a at surface.
2-83
Page 166 of 528
2. Fold the four primary strap ends towards the center
as shown.
3. Take the short strap and surround the folded
webbing, forming a package.4. Take the secondary strap and wrap it around the
package. Finally, attach the hooks to the webbing
and place inside the top box storage compartment.
Cargo Tie Downs
Cargo tie downs are located in the rear cargo area that
can be used to secure cargo.
The tie downs can also be used to secure the cargo
cover panel strap system or the tonneau cover storage
bag, if equipped. For more information see “Cargo
Cover Panels” earlier in this section andTonneau
Cover on page 2-90.
2-84
