2007 TOYOTA CAMRY HYBRID key

’07Camry hybrid_U (L/O 0610)
383
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
12 VOLT BATTERY
Open voltage
∗ at 20C (68 F):
12.6—12.8 V Fully charged
12.2—12.4 V Half charged
11.8—12.0 V Discharged
∗: Voltage that is checked 20 minutes af-
ter the key is removed with all the lights
turned off
Charging rates: 5 A max.
CAUTION
When replacing the battery, only
install a battery designated for your
hybrid vehicle. Using a conventional
battery may cause hydrogen gas to
build up in the vehicle.
TRANSAXLE
Fluid capacity (drain and refill), L (qt.,
Imp. qt.):
3.8 (4.0, 3.3)
Fluid type: Toyota Genuine ATF WS
Change the transmission fluid only as nec-
essary.
Generally, it is necessary to change
transmission fluid only if your vehicle is
driven under one of the Special Operating
Conditions listed in your “Scheduled
Maintenance Guide” or “Owner ’s Manual
Supplement”. When changing the
transmission fluid, use only “Toyota
Genuine ATF WS” (ATF JWS3324 or
NWS9638) to aid in assuring optimum
transaxle performance. Notice: Using transmission fluid other
than “Toyota Genuine ATF WS” may
cause deterioration in shift quality,
locking up of your transmission accom-
panied by vibration, and ultimately dam-
age the transmission of your vehicle.
Please contact your Toyota dealer for fur-
ther details.

’07Camry hybrid_U (L/O 0610)
386
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
ENGINE COMPARTMENT1. AM2 7.5 A: “POWER” switch
2. ABS MAIN No.2 10 A: Electronically
controlled brake system
3. ABS MAIN No.1 10 A: Electronically
controlled brake system
4. ABS MAIN No.3 10 A: Electronically
controlled brake system
5. BATT FAN 10 A: Hybrid battery fan
6. ETCS 10 A: Electronic throttle control
system
7. HAZ 15 A: Turn signal lights
8. IG2 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, starting system, “GAUGE
NO.2”, “IGN” and “INJ” fuses
9. STR LOCK 20 A: Steering lock system
10. DOME 10 A: Gages and meters, vanity
lights, trunk light, “POWER” switch
light, door courtesy lights, interior light,
personal lights, clock, smart key
system
11. ECUB NO.1 10 A: Front passenger
occupant classification system, main
body ECU
12. RADIO NO.1 15 A: Audio system, nav-
igation system 13. DOOR NO.1 25 A:
Main body ECU,
power door lock
14. IGCT 30 A: Hybrid system ECU,
“PWR”, “IGCT No.2” and “INV W/P”
fuses
15. AMP 25 A: Audio system
16. EFI MAIN 30 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, electronic throttle control
system and “EFI NO.3” fuses
17. EFI NO.3 10 A: Fuel tank system, mul-
tiport fuel injection system/sequential
multiport fuel injection system
18. IGCT NO.2 10 A: Hybrid system ECU,
motor generator ECU
19. INV W/P 15 A: Hybrid system ECU,
traction battery, DC/DC converter, mul-
tiport fuel injection system/sequential
multiport fuel injection system
20. SHORN 7.5 A: No circuit
21. A/F 20 A: No circuit
22. MPXB 10 A: Gauges and meters
23. EFI NO.1 10 A: Smart key system
24. HORN 10 A: Horns
25. HLP(RL) 15 A: Right−hand headlight
(low beam)
Fuses

’07Camry hybrid_U (L/O 0610)
388
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
17. ECU IG NO.2 7.5 A: Electronically
controlled brake system, electric power
steering system, shift lock control sys-
tem
18. A/C NO.2 10 A: Air conditioning sys-
tem, rear window defogger
19. WASH 10 A: Windshield wipers and
washer
20. SHTR 20 A: Seat heaters
21. GAUGE NO.1 10 A: Emergency flash-
ers, back− up lights
22. WIP 25 A: Windshield wipers and
washer
23. HLP LVL 7.5 A: No circuit
24. INJ 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
25. IGN 10 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, SRS airbag system, steering
lock system, front passenger occupant
classification system, smart key sys-
tem, electronic throttle control system
26. GAUGE NO.2 7.5 A: Gages and me-
ters, clock 27. ECUACC 7.5 A:
Clock, main body
ECU, shift lock control system, outside
rear view mirrors, smart key system,
push start system
28. CIG 20 A: No circuit
29. PWR OUTLET 20 A: Power outlet
30. RADIO NO.2 7.5 A: Audio system,
navigation system
31. MIR HTR 10 A: Outside rear view mir-
ror defoggers
32. 30 A: Power windows
33. 30 A: Power seats
