2007 TOYOTA CAMRY HYBRID key

’07Camry hybrid_U (L/O 0610)
302
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
The engine may not start even with the
“READY” light on.
If there is a problem somewhere in the
hybrid system, the message “CHECK
HYBRID SYSTEM” will appear on the
multi−information display. Have your
vehicle checked by your Toyota dealer as
soon as possible.
If the hybrid system will not start...
In the following cases, the hybrid system
will not start.
If a buzzer sounds from the vehicle,
and the message “KEY IS NOT
DETECTED” appears on the multi −infor-
mation display and the master warning
light comes on when pressing the
“POWER” switch, this indicates that the
key is not in the vehicle.
If the key is placed in the trunk, the
hybrid system cannot be started.
There are instances in which the hybrid
system will not start, even if the key
is in the vehicle (e.g. on the floor, in
the cup holder or glove box).
When the push button start function
does not operate properly, the following
may be causes:
The key battery may be discharged if
the electronic key does not work.
You can start the hybrid system by
touching the Toyota logo side of the
electronic key to the “POWER” switch.
For details, see “Smart key system” on
page 32 in Section 1 −2.
Replace the key battery as soon as
possible. (See “—Replacing battery” on
page 30 in Section 1 −2.)
The hybrid system was repeatedly
turned on and off over a short period.
Wait 10 seconds and then start the
hybrid system.

’07Camry hybrid_U (L/O 0610)
303
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
If the green indicator light on the
“POWER” switch flashes, and the mes-
sage “S/T IS NOT UNLOCKED” ap-
pears on the multi−information display
and the master warning light comes on,
the steering wheel is locked.
To free the steering lock, turn the
steering wheel slightly while pressing
the “POWER” switch.
If the amber indicator light on the
“POWER” switch flashes, and the mes-
sage “CHECK S/T LOCK” appears on
the multi −information display and the
master warning light comes on, there is
a problem in the steering lock function.
Contact your Toyota dealer, and have
your vehicle and all keys inspected.
If the amber indicator light on the
“POWER” switch flashes, and no mes-
sage appears on the multi −information
display, there is a problem in the push
button start function.
Contact your Toyota dealer, and have
your vehicle and all keys inspected.
In addition to the above, there are
instances in which the smart key sys-
tem does not operate properly because
of the circumstances of use. For de-
tails, see “Smart key system” on page
32 in Section 1 −2.
In cases other than those described
above, it is possible that a problem has
occurred in an area other than the start
system. See “If your vehicle will not start”
on page 313 in Section 4. If the 12 volt battery is disconnected or
run down...
The “READY” light will not come on and
the hybrid system will not start after you
reconnect, replace or recharge the battery.
In this case, perform the following proce-
dure to restart the hybrid system:
1. Turn the hybrid system off.
2. Open and close the driver ’s door.
3. Press the “POWER” switch briefly and firmly.
If the hybrid system still will not start,
contact your Toyota dealer.CAUTION
Never start the hybrid system from
outside the vehicle, or an accident
may occur. Be sure to sit in the driv-
er seat, then start the system.

’07Camry hybrid_U (L/O 0610)
304
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
NOTICE
If any message appears on the mul-
tiinformation display or service re-
minder indicator light comes on
(see page 140 and page 150 in Sec-
tion 16 for details) or the 12 volt
battery is disconnected, the hybrid
system may not be started. In that
case, push the “POWER” switch
again. If the “READY” light does
not come on, contact your Toyota
dealer.
 When you start the hybrid system
at a lower outside temperature, it
may take longer before the blinking
“READY” light changes to constant
on.
TIPS FOR USING SMART KEY SYSTEM
When using the smart key system, it is
possible to start or stop the hybrid system
as long as the key is on your person.
For this reason, it is possible that a pas-
senger may remove the key from the ve-
hicle without the driver being aware of the
fact. In such a case, it is not possible to
restart the hybrid system after having
turned it off. In addition, it is possible that
one may get out of the vehicle without
being aware that the “POWER” switch has
not been turned off completely.
When driving or getting in or out of the
vehicle, drivers should make sure that
they are carrying the key.
CAUTION
Do not touch the “POWER” switch
while driving.
If you have to make an emergency stop,
press and hold the “POWER” switch for
more than 3 seconds.
Master warning light and multiinforma-
tion display
SYSTEM FUNCTION REMINDERS
Follow the instructions described below if
any of the following warnings occur:
(A) A warning buzzer sounds once from
the instrument cluster when the
“POWER” switch is pushed.
This indicates that the driver has gotten
into the vehicle without the key. The mes-
sage “KEY IS NOT DETECTED” will also
appear on the multi −information display
and the master warning light will come on.
Operate the “POWER” switch only after
taking care that the key is in the vehicle.
Driving and parking using
smart key system

’07Camry hybrid_U (L/O 0610)
305
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
If the warning light is still lit when the key
is in the vehicle, the key battery is dis-
charged. Check that the indicator light on
the key comes on by pushing the lock
button on the key. When the indicator light
does not come on, change the key battery
so that smart key system works properly.
(B) A warning buzzer sounds once fromthe instrument cluster, accompanied
by three warning sounds from the
vehicle when the driver gets out of
the vehicle and closes the door.
This indicates that the driver is attempting
to leave the vehicle carrying the key with
“POWER” switch turned off although the
transmission selector lever has been set
in the “P” position. The message “KEY IS
NOT DETECTED” will also appear on the
multi −information display and the master
warning light will come on.
Get out of the vehicle only after turning
off the hybrid system by pressing the
“POWER” switch and checking that the
indicator light on the “POWER” switch has
gone off. If the driver returns to the ve-
hicle without carrying the key and begins
driving, a warning buzzer will sound once
more. (C) A warning buzzer sounds from the
vehicle for two seconds after locking
the door with the door handle
switch.
This indicates that the driver is attempting
to lock the doors while carrying the key,
neglecting to follow the instructions for
case (B) above.
Lock the doors only after turning off the
hybrid system by pressing the “POWER”
switch and checking that the indicator light
on the “POWER” switch has gone off.
A warning buzzer that sounds even though
the engine has been turned off indicates
that driver is attempting to lock the ve-
hicle with the keys still in the vehicle.
Leave the vehicle only after making sure
that you are carrying the key. (D) A warning buzzer sounds continu-
ously from the instrument cluster
when opening the driver ’s door.
This indicates that the transmission selec-
tor lever is in a position other than “P”
and that the “POWER” switch is not
turned off. The message “SHIFT TO P
RANGE” will also appear on the multi −in-
formation display.
Get out of the vehicle only after setting
the transmission selector lever in the “P”
position, turning off the hybrid system by
pressing the “POWER” switch and
checking that the indicator light on the
“POWER” switch has gone off.

’07Camry hybrid_U (L/O 0610)
306
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
(E) A warning buzzer sounds continu-ously from the instrument cluster
and from the vehicle when closing
the door after getting out of the ve-
hicle.
This indicates that the driver is attempting
to leave the vehicle carrying the key, ne-
glecting to follow the instructions for case
(D) above. The messages, “SHIFT TO P
RANGE” and “KEY IS NOT DETECTED”,
will also appear alternately on the multi −
information display and the master warn-
ing light will come on.
Get out of the vehicle only after setting
the transmission selector lever in the “P”
position, turning off the hybrid system by
pressing the “POWER” switch and
checking that the indicator light on the
“POWER” switch has gone off. (F) A warning buzzer sounds once from
the instrument cluster and three
times from the vehicle when a pas-
senger is getting out of the vehicle.
This indicates that the passenger is
attempting to leave the vehicle carrying
the key, without turning the hybrid system
off. The message “KEY IS NOT
DETECTED” will also appear on the
multi −information display and the master
warning light will come on.
When passengers get out of the vehicle,
care should be taken to leave the key
with the driver. If the driver begins driving
after a passenger gets out of the vehicle
carrying the key, a warning buzzer will
sound once more.
(G) A warning buzzer sounds from the vehicle for two seconds when lock-
ing the vehicle from the outside with
the door handle switch.
This indicates that the driver is attempting
to lock the door with the key still in the
vehicle.
Leave the vehicle only after making sure
that you are carrying the key. (H) A warning buzzer sounds once from
the instrument cluster when the
“POWER” switch is turned off.
This indicates that the key battery is low.
(This warning buzzer sounds only when
the hybrid system has been on or the
“POWER” switch has been set at ON for
20 minutes or more.) The message “LOW
KEY BATTERY” will also appear on the
multi −information display.
Change the key battery ahead of time in
order to ensure that the smart key system
works properly.
(I) A warning buzzer sounds repeatedly from the instrument cluster when
opening the driver ’s door with the
“POWER” switch turned off.
This indicates that the steering wheel is
not locked. Turn the engine off and then
open the door in order to lock the steering
wheel.

’07Camry hybrid_U (L/O 0610)
312
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
IN CASE OF AN EMERGENCY
In case of an emergency
If your vehicle will not start313
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your hybrid system stalls while driving 317
. . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 317
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
If you have a flat tire 318
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
If your vehicle becomes stuck 327
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed 327
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot shift transmission selector lever 329
. . . . . . . . . . . . . . . . . .
If you lose your keys 330
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
SECTION 4

’07Camry hybrid_U (L/O 0610)
313
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
Before making these checks, make sure
you have sufficient fuel and that you have
followed the correct starting procedure giv-
en in “How to start the hybrid system” on
page 301 in Section 3. If your vehicle is
equipped with the engine immobilizer sys-
tem, also check whether the other keys
will start the hybrid system. If they work,
your key may be broken. Have the key
checked at your Toyota dealer. If none of
your keys work, there may be a malfunc-
tion in the immobilizer system. Call your
Toyota dealer. (See “Keys” on page 22 in
Section 1−2.) If the instrument cluster displays with
normal brightness levels with the
“POWER” switch set at ON...
You may try emergency start. See “(b)
Emergency start” for further instructions.
If the instrument cluster dims or the
instrument cluster display turns off
with the “POWER” switch set at ON...
1. Check that the 12 volt battery terminals are tight and clean.
2. If the 12 volt battery terminals are O.K., the 12 volt battery is discharged.
You may try jump starting. See “(c)
Jump starting” that follows for further
instructions.
NOTICE
Hybrid vehicles cannot be push
started.
When the hybrid system cannot be
started, the following procedure can be
used if the hybrid system and “POWER”
switch function normally.
1. Put the transmission in “P”.
2. Set the mode to ACC by pushing the “POWER” switch once.
3. Push and hold the “POWER” switch for about 15 seconds while depressing the
brake pedal firmly.
Even if the hybrid system can be started
using the above procedure, the system
may be malfunctioning. Have the vehicle
checked by your Toyota dealer.
If the hybrid system cannot be started
using the above procedure, immediately
contact your Toyota dealer.
CAUTION
Do not place any objects close to the
“POWER” switch. If the object pushes
on the switch, the hybrid system may
be started unexpectedly.
If your vehicle will not start—
(a) Simple checks ( b ) Emerg en cy st art

’07Camry hybrid_U (L/O 0610)
330
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
You can purchase a new electronic key
at your Toyota dealer if you can give
them the key number and master key.
If you lose any of your keys, contact your
Toyota dealer to have new keys made.
Lost keys increase the danger of vehicle
theft. Bring all of the remaining vehicle
keys when you visit your Toyota dealer.
See the suggestion given in “Keys” on
page 22 in Section 1−2.
You can use the wireless remote control
function and smart entry and start function
by new key. Contact your Toyota dealer
for detailed information.
If your keys are locked in the vehicle and
you cannot get a duplicate, many Toyota
dealers can still open the door for you,
using their special tools. If you must
break a window to get in, we suggest
breaking the smallest side window be-
cause it is the least expensive to replace.
Be extremely cautious to avoid cuts from
the glass.
If you lose your keys
