2007 SATURN SKY Owners Manual

Hood Release
To open the hood, do the following:
1. Locate the interior
hood release lever.
It is located below
the instrument panel
on the driver’s side
of the vehicle.2. Pull down on the
rear edge of the
lever to release
the hood latch.
3. Go to the side of the vehicle and pull up on
the rear edge of the hood, near the windshield
to open the hood.
Notice:Closing the hood with the doors open
may damage the hood and/or doors. Always
close the doors before closing the hood.
Before closing the hood, be sure all the ller caps
are on properly. Then, pull the hood down and
close it rmly.
241
ProCarManuals.com

Engine Compartment Overview
When you open the hood on the 2.4L L4 engine, this is what you will see:
242
ProCarManuals.com

A. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 267.
B. Coolant Surge Tank and Pressure Cap.
SeeCooling System on page 260.
C. Brake Master Cylinder Reservoir. See
“Brake Fluid” underBrakes on page 268
andHydraulic Clutch on page 254.
D. Engine Oil Dipstick (Out of View). See
“Checking Engine Oil” underEngine Oil
on page 245.
E. Engine Air Cleaner/Filter. SeeEngine
Air Cleaner/Filter on page 252.F. Engine Oil Fill Cap. See “When to Add
Engine Oil” underEngine Oil on page 245.
G. Power Steering Fluid Reservoir. See
Power Steering Fluid on page 266.
H. Remote Negative (−) Ground (Out of View).
SeeJump Starting on page 272.
I. Battery (Out of View). SeeBattery on page 271.
J. Remote Positive (+) Terminal. SeeJump
Starting on page 272.
K. Underhood Fuse Block. SeeUnderhood
Fuse Block on page 328.
243
ProCarManuals.com

When you open the hood on the 2.0L L4 engine, this is what you will see:
244
ProCarManuals.com

A. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 267.
B. Coolant Surge Tank and Pressure Cap.
SeeCooling System on page 260.
C. Brake Master Cylinder Reservoir. See
“Brake Fluid” underBrakes on page 268
andHydraulic Clutch on page 254.
D. Engine Oil Dipstick. See “Checking Engine
Oil” underEngine Oil on page 245.
E. Engine Air Cleaner/Filter. SeeEngine
Air Cleaner/Filter on page 252.
F. Engine Oil Fill Cap. See “When to Add
Engine Oil” underEngine Oil on page 245.
G. Power Steering Fluid Reservoir. See
Power Steering Fluid on page 266.
H. Remote Negative (−) Ground (Out of View).
SeeJump Starting on page 272.
I. Battery (Out of View). SeeBattery on page 271.
J. Remote Positive (+) Terminal. SeeJump
Starting on page 272.
K. Underhood Fuse Block. SeeUnderhood
Fuse Block on page 328.Engine Oil
Checking Engine Oil
It is a good idea to check the engine oil every time
you get fuel. In order to get an accurate reading,
the oil must be warm and the vehicle must be
on level ground.
The engine oil dipstick handle is a yellow loop.
SeeEngine Compartment Overview on page 242
for the location of the engine oil dipstick.
1. Turn off the engine and give the oil several
minutes to drain back into the oil pan. If you
do not do this, the oil dipstick might not
show the actual level.
2. Pull the dipstick and clean it with a paper
towel or cloth, then push it back in all the
way. Remove it again, keeping the tip down
and check the level.
245
ProCarManuals.com

When to Add Engine Oil
If the oil is below the MIN (minimum) mark, you
will need to add at least one quart/liter of oil.
But you must use the right kind. This section
explains what kind of oil to use. For engine
oil crankcase capacity, seeCapacities and
Specications on page 331.
Notice:Do not add too much oil. If the
engine has so much oil that the oil level
gets above the upper mark that shows the
proper operating range, the engine could
be damaged.SeeEngine Compartment Overview on page 242
for the location of the engine oil ll cap.
Be sure to add enough oil to put the level
somewhere in the proper operating range.
Push the dipstick all the way back in when
you are through.
2.4L L4 Engine2.0L L4 Engine
246
ProCarManuals.com

What Kind of Engine Oil to Use
For Vehicles With the 2.0L L4 Engine
Look for two things:
GM4718M
Your vehicle’s engine requires a special oil
meeting GM Standard GM4718M, such as
Mobil 1
®or equivalent. Oils meeting this
standard may be identied as synthetic.However, not all synthetic oils will meet this
GM standard. You should look for and use only
an oil that meets GM Standard GM4718M.
Notice:If you use oils that do not have the
GM4718M Standard designation, you can cause
engine damage not covered by your warranty.
SAE 5W-30
As shown in the viscosity chart, SAE 5W-30
is best for your vehicle.
These numbers on an oil container show
its viscosity, or thickness. Do not use other
viscosity oils such as SAE 20W-50.
Oils meeting these
requirements should
also have the starburst
symbol on the container.
This symbol indicates
that the oil has been
certied by the
American Petroleum
Institute (API).
You should look for this on the oil container, and
use only those oils that are identied as meeting
GM Standard GM4718M and have the starburst
symbol on the front of the oil container.
247
ProCarManuals.com

Your vehicle’s engine is lled at the factory with
a synthetic oil which meets all requirements
for your vehicle.
Substitute Engine Oil: When adding oil to
maintain engine oil level, oil meeting GM
Standard GM4718M may not be available.
You can add substitute oil designated SAE 5W-30
with the starburst symbol at all temperatures.
Substitute oil not meeting GM Standard GM4718M
should not be used for an oil change.For Vehicles With the 2.4L L4 Engine
Look for two things:
GM6094M
Your vehicle’s engine requires oil meeting
GM Standard GM6094M. You should look for
and use only an oil that meets GM Standard
GM6094M.
248
