Thepositionandaccessibilityofthejointrodschangedependingonthepositionoftheconverti-bletop.Itcanbehelpfultofolduptherearpartoftheconvertibletop.
4.LeverjointrodD(blackfastening)offtheballheadwithbladeofleverB.Astheconnectionisunderspringtension,acorrespondingamountofforceisrequiredtoleverofftheballhead,creatingdangerofcrushingandpinching.
5.WhenleveringoffjointrodDontheothersideofthevehicle,theconvertible-topcompartmentcovermustbeheldsothatitdoesnotfalldowninanuncontrolledmannertoprotectagainstinjuryfromafallencover.
6.Graspconvertible-topcompartmentcoverinthecenterandsetupcompletely(arrow).
7.LeverjointrodE(whitefastening)offtheballheadwithbladeofleverB.Acorrespondingamountofforceisrequiredtoleverofftheballhead,creatingdangerofcrushingandpinching.
8.WhenleveringoffjointrodEontheothersideofthevehicle,theconvertibletopmustbeheldsothatitdoesnotfalldowninanuncontrolledmannertoprotectagainstinjuryfromafallencover.
9.Liftconvertibletopwithbothhands(arrow)andclose.
10.Lockconvertibletop.
11.Carefullylowerconvertible-topcompartmentcover.
Caution!
Dangerofdamageattheconvertibletop.
Afteremergencyoperation,donotoperatetheconvertibletopwiththerockerswitch.
MobileRoofs199

DriveslowlytoanauthorizedPorschedealerinordertohavethefaultremedied.
200MobileRoofs

Windstop
Generalinformationtothewindstop
Makesurethatallwindstoppartsarefastenedsecurely,especiallywhendrivingwiththeconvertibletopopen.
Note
Whentheconvertibletopisclosed,itisagoodideatoremovethecentersectionofthewindstoptopermitgoodventilationoftheinteriororfordemistingtherearwindow.Thisisparticularlythecaseincold,wetweather.
Removingouterwindstopparts
Presswindstoppartstotherearandupoutoftheroll-overbarandtakeitout.
Installingouterwindstopparts
Firstinsertthewindstoppartsintheroll-overbarfromtherear,thenpushitupintothebar.
MakesurethatthethreeplastictonguesAfullyengageintheroll-overbar.
Removingcentralsectionofwindstop
parts
PressreleasebuttonsBandtakeoutthewindstoptowardtherear.
Installingcentersectionofwindstop
FirstinsertthewindstopinreceiverCfromtherear,then,oneaftertheother,pressforwarduntilbothuppermountsBengageaudibly.
MobileRoofs201

Hardtop
Keeping
Sincetheconvertibletopstaysopenforalongtime,itmustbeabsolutelydryandcleanbeforebeingopened.Thispreventsdampstainsandabrasiondamage.
YourautorizedPorschedealerwillbepleasedtoadviseyouaboutcorrecthardtopstorage.
Note
Theinsertsforlockingofthepivotlocksarenotinstalledonvehiclesdeliveredwithoutahardtop.ItisessentialtohavethenecessarypartsretrofittedbyanauthorizedPorschedealerbeforeahardtopisfittedforthefirsttime.
Fittingthehardtop
1.Opendoorsandconvertibletop.
2.Carefullyremovebothplasticcovers(arrow)outofthepivotlocks,usingascrewdriver.Storeplasticcovers.
Note
Theseplasticcoversareincludedwithvehiclesthatarefactory-equippedwithahardtop.
3.PulloffcoverAontheroll-overbar.
202MobileRoofs

4.Removetheconnectoroftheconvertibletopheatedrearwindowandinsertintotherearemptysocket.
5.Removecoverfromfrontlockinglever(arrow).6.Pressredlockingbuttonofthefrontlockinglever(arrowA).Openlatchcompletely(arrowB).
MobileRoofs203

7.Putbothpivotlocksintheopeningpositiononthehardtop.Thehandlesmustpointinwards.8.Withonepersononeachside,grasphardtopandcarefullyliftoverthecar.
9.Inserthardtopfrontintothesocketsonthewindshieldframe.
Warning!
Dangerofpinchingngersorhands.
Evenlylowerthehardtopatbothsides.
10.Lowerhardtopatrear.Thepivotlocksmustbecompletelysunkenintothelocks(arrowA).Ifnecessary,movelatchingleverslightly.
11.Swingbothlatchingleverstotherearuntiltheycanbefelttoengage(arrowB).
204MobileRoofs

12.Swinglockingleveroffrontlatchtotherear(arrowA).Thelockinghookmustengageinthewindshieldframe(arrowB).Whenthehardtopiscorrectlylatched,thewhitemarkingstripeontheredlockingbutton(arrowC)mustbevisible.
Caution!
Riskofdamageduetoinadvertentoperationoftheconvertibletopwhenthehardtopistted.
MakesurethatfrontlockingleverAisalwayscorrectlylocked.Thisdisablestheconvertible-topdrive.
13.Fitcoveronthefrontlockinglever.
14.Inserttheplugofthehardtopheatedrearwindowintothesocket.
Removingthehardtop
1.Makesurethatthehardtopisplacedonaclean,softsurface.
2.Opendoors.
3.Removecoverfromthefrontlockinglever.
4.Openfrontlatch.
5.Openrearpivotlocks(swivelinwards).Unplugplugofthehardtopheatedrearwindow.
6.Withonepersononeachside,graspthehardtop.Lifthardtopatrearandpulloutofthesocketsonthewindshieldframeatfront.
Warning!
Dangerofpinchingngersorhands.
Evenlyliftthehardtopatbothsides.
7.Carefullyliftthehardtopupandoffthevehicletotherear.
8.Closefronthardtoplatch.Fitcoveronthefrontlatch.
9.Closepivotlocksonthevehiclewiththeplasticcovers.
10.Removetheconnectoroftheconvertibletopheatedrearwindowfromtheemptysocketandinsertintothesocket.
MobileRoofs205

11.Swivelthesashguideoftheseatbeltforward.Insertthelowerretaininglugsofthecoverfromaboveandclipintheupperretaininglugsonthebar.
