2007 NISSAN 350Z Road Wheels And Tires Workshop Manual

TROUBLE DIAGNOSIS
WT-25
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2006 November2007 350Z
ACTIVE TEST MODE
NOTE:
Before performing the self-diagnosis, be sure to register the ID, or else the actual malfunction location may be
different from that displayed on CONSULT-III.
TEST ITEM LIST
Test item Content
FLASHER This test is able to check to make sure that each turn signal lamp turns on.
HORN This test is able to check to make sure that the horn sounds.
WARNING LAMP This test is able to check to make sure that the warning lamp turns on.
ID REGIST WARNING This test is able to check to make sure that the buzzer sounds or the warning lamp turns on.
FLAT TIRE WARNING This test is able to check to make sure that the buzzer sounds or the warning lamp turns on.

WT-26
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
Diagnosis Procedure with Warning Lamp Function (Without CONSULT-III)NES000A4
DESCRIPTION
During driving, the low tire pressure warning system receives the signal transmitted from the transmitter
installed in each wheel. The control unit (BCM) of this system has pressure judgement and trouble diagnosis
functions.
FUNCTION
When the low tire pressure warning system detects low inflation pressure or another unusual symptom, the
warning lamps in the combination meter comes on. To start the self-diagnostic results mode, ground terminal
of the tire pressure warning check connector. The malfunction location is indicated by the warning lamp flash-
ing. Refer to PG-41, "
HARNESS" .
MALFUNCTION CODE CHART
Code (warning lamp blinks) Diagnosis item Reference
15
Front-left tire pressure drops to 190 kPa (1.90 kg/cm
2 , 28 psi) or less.
— 16
Front-right tire pressure drops to 190 kPa (1.90 kg/cm
2 , 28 psi) or less.
17
Rear-right tire pressure drops to 190 kPa (1.90 kg/cm
2 , 28 psi) or less.
18
Rear-left tire pressure drops to 190 kPa (1.90 kg/cm
2 , 28 psi) or less.
21 Transmitter no data (front - left)
WT-30
22 Transmitter no data (front - right)
23 Transmitter no data (rear - right)
24 Transmitter no data (rear - left)
31 Transmitter checksum error (front - left)
WT-30
32 Transmitter checksum error (front - right)
33 Transmitter checksum error (rear - right)
34 Transmitter checksum error (rear - left)
35 Transmitter pressure data error (front - left)
WT-31
36 Transmitter pressure data error (front - right)
37 Transmitter pressure data error (rear - right)
38 Transmitter pressure data error (rear - left)
41 Transmitter function code error (front - left)
WT-30
42 Transmitter function code error (front - right)
43 Transmitter function code error (rear - right)
44 Transmitter function code error (rear - left)
45 Transmitter battery voltage low (front - left)
WT-30
46 Transmitter battery voltage low (front - right)
47 Transmitter battery voltage low (rear - right)
48 Transmitter battery voltage low (rear - left)
52 Vehicle speed signalWT-32

TROUBLE DIAGNOSIS
WT-27
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2006 November2007 350Z
LOW TIRE PRESSURE WARNING LAMP SYMPTOM CHART
Diagnosis
ItemSymptom
(Ignition switch ON)Low tire pressure warning lamp Cause Action
Low tire pres-
sure warning
lampWarning light comes
on immediately and
turns off after 1 sec-
ond.All wheel transmit-
ters are “activated”
(working).None (system OK)
Warning light blinks
on for 2 seconds,
then turns off for 0.2
seconds-repeats.All wheel transmit-
ters are not acti-
vated.Activate all wheel transmit-
ters. Refer to WT-22,
"Transmitter Wake Up Oper-
ation" .
Warning light blinks 1
time.Front LH wheel
transmitter is not
activated.Activate front LH wheel
transmitter. Refer to WT-22,
"Transmitter Wake Up Oper-
ation" .
Warning light blinks 2
times.Front RH wheel
transmitter is not
activated.Activate front RH wheel
transmitter. Refer to WT-22,
"Transmitter Wake Up Oper-
ation" .
Warning light blinks 3
times.Rear RH wheel
transmitter is not
activated.Activate rear RH wheel
transmitter. Refer to WT-22,
"Transmitter Wake Up Oper-
ation" .
SEIA0592E
SEIA0593E
PEIA0073E
SEIA0595E
SEIA0596E

WT-28
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
NOTE:
If more than one wheel transmitter is NOT activated, the warning light blinking patterns for those wheels will combine. (Example: one
blink/OFF/three blinks = Rear LH and Rear RH transmitters are not activated.)Low tire pres-
sure warning
lampWarning light blinks 4
times.Rear LH wheel trans-
mitter is not acti-
vated.Activate rear LH wheel
transmitter. Refer to WT-22,
"Transmitter Wake Up Oper-
ation" .
Warning light comes
on and does not turn
off.Tire pressure is low.Check tire pressure with
CONSULT-III. Refer to WT-
24, "DATA MONITOR
MODE" .
The fuse for combi-
nation meter from
battery is pulled out.Check the fuse for combina-
tion meter from battery.
Install or replace (if needed).
BCM connector
pulled out.Check BCM connector. Re-
connect if needed.
Low tire pressure or
tire pressure moni-
toring system mal-
function.

Perform CONSULT-III
Self- Diagnosis. Refer to
WT-23, "
SELF-DIAG
RESULTS MODE" .
–Perform ID Registration if
needed. Refer to WT-21,
"ID Registration Proce-
dure" .
Turn signal
lampTurn signal lamp
does not flash 2
times or horn does
not sound after trans-
mitter activation.—1. Tool J-45295 (spe-
cial service tool)
battery low.
2. Ignition OFF dur-
ing activation.
3. Tool J-45295 (spe-
cial service tool)
not positioned cor-
rectly.
4. Transmitters
already activated.1. Install new battery.
2. Make sure ignition is ON
during activation.
3. Position tool correctly dur-
ing activation.
4. None Diagnosis
ItemSymptom
(Ignition switch ON)Low tire pressure warning lamp Cause Action
SEIA0597E
SEIA0598E

TROUBLE DIAGNOSIS
WT-29
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2006 November2007 350Z
Preliminary CheckNES0001K
BASIC INSPECTION
1. CHECK ALL TIRE PRESSURES

Check all tire pressures. Refer to WT-39, "SERVICE DATA AND SPECIFICATIONS (SDS)" .
OK or NG
OK >> GO TO 2.
NG >> Adjust tire pressure to specified value.
2. CHECK LOW TIRE PRESSURE WARNING LAMP ACTIVATION

Check low tire pressure warning lamp activation.
Dose low tire pressure warning lamp activate for 1 second when ignition switch is turned
“ON”?
YES >> GO TO 3.
NO >> Check fuse and combination meter.
3. CHECK CONNECTOR
1. Disconnect BCM harness connectors M90 and M91.
2. Check terminals for damage or loose connection.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4. CHECK ACTIVATION TOOL

Check activation tool battery.
OK or NG
OK >> Perform self-diagnosis.
NG >> Replace activation tool battery.

WT-30
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2006 November2007 350Z
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSPFP:00000
Transmitter or Control Unit (BCM)NES0001M
MALFUNCTION CODE NO. 21, 22, 23 OR 24
1. CHECK CONTROL UNIT

Drive for several minutes. Check all tire pressures with CONSULT-III “DATA MONITOR”.
Are all tire pressures displayed 0 kPa?
YES >> GO TO 2.
NO >> GO TO 3.
2. CHECK REMOTE KEYLESS ENTRY RECEIVER CONNECTOR
1. Disconnect remote keyless entry receiver harness connector M78.
2. Check terminals for damage or loose connection.
3. Reconnect harness connector.
OK or NG
OK >> Replace BCM refer to BCS-17, "Removal and Installation of BCM" , then GO TO 3.
NG >> Repair or replace remote keyless entry receiver harness connector.
3. ID REGISTRATION

Perform ID registration of all transmitters.
Is there any tire that ID cannot be registered to?
YES >> Replace transmitter of the tire, then GO TO 5.
NO >> GO TO 4.
4. VEHICLE DRIVING

Drive at a speed of 40 km/h (25 MPH) or more for several minutes without stopping.
Check all tire pressures with CONSULT-III “DATA MONITOR” within 15 minutes after vehicle speed
becomes 17 km/h (11 MPH).
Does
“DATA MONITOR” display tire pressure as normal without any warning lamp?
YES >> INSPECTION END
NO >> GO TO 5.
5. ID REGISTRATION AND VEHICLE DRIVING
1. Perform ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for
10 minutes. Then check all tire pressures with CONSULT-III “DATA MONITOR” within 5 minutes.
Does
“DATA MONITOR” display tire pressure as normal without any warning lamp?
YES >> INSPECTION END
NO >> GO TO the inspection applicable to DTC.
Transmitter - 1NES0001N
MALFUNCTION CODE NO. 31, 32, 33, 34, 41, 42, 43, 44, 45, 46, 47 OR 48
1. ID REGISTRATION (CORRECTION OF TRANSMITTER LOCATION)
1. Perform ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for
10 minutes.
>> GO TO 2.

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
WT-31
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2006 November2007 350Z
2. REPLACE TRANSMITTER
1. Check low tire pressure warning condition again, and replace malfunctioning transmitter.
2. Perform ID registration of all transmitters.
Can ID registration of all transmitters be completed?
YES >> GO TO 3.
NO >> GO TO the inspection 1. Refer to WT-30, "
Transmitter or Control Unit (BCM)" .
3. VEHICLE DRIVING

Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for
10 minutes. Then check all tire pressures with CONSULT-III “DATA MONITOR” within 5 minutes.
Does
“DATA MONITOR” display tire pressure as normal without any warning lamp?
YES >> INSPECTION END
NO >> Replace malfunctioning transmitter, and perform “Step 3” again.
Transmitter - 2NES0001O
MALFUNCTION CODE NO. 35, 36, 37 OR 38
1. CHECK ALL TIRE PRESSURE

Check all tire pressures. Refer to WT-39, "SERVICE DATA AND SPECIFICATIONS (SDS)" .
Are there any tires whose pressure is
“64 psi” or more?
YES >> Adjust tire pressure to specified value.
NO >> GO TO 2.
2. VEHICLE DRIVING
1. Perform ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for several minutes without stopping.
Check all tire pressures with CONSULT-III “DATA MONITOR” within 15 minutes after vehicle speed
becomes 17 km/h (11 MPH).
>> Replace transmitter with new one if “DATA MONITOR” displays 64 psi or more. Then GO TO 3.
3. ID REGISTRATION AND VEHICLE DRIVING
1. Perform ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for
10 minutes. Then check all tire pressures with CONSULT-III “DATA MONITOR” within 5 minutes.
Does
“DATA MONITOR” display tire pressure as normal without any warning lamp?
YES >> INSPECTION END
NO >> GO TO the inspection applicable to DTC.

WT-32
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2006 November2007 350Z
Vehicle Speed SignalNES0001P
MALFUNCTION CODE NO. 52
1. CHECK SELF-DIAGNOSTIC RESULTS
1. Perform “CONSULT-III Start procedure”.
2. Touch “BCM” on “SELECT SYSTEM” screen.
3. Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE” screen.
4. Check display contents in self-diagnostic results.
Is the
“CAN COMM CIRCUIT” displayed in the self-diagnosis display?
YES >> Perform trouble diagnosis for CAN communication system.
NO >> Check combination meter. Refer to DI-47, "
SELF-DIAGNOSTIC RESULTS" .
