ROAD WHEELS & TIRES
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for Battery Service ................................ 3
Service Notice or Precautions .................................. 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 5
NVH Troubleshooting Chart ..................................... 5
ROAD WHEEL ............................................................ 6
Inspection ................................................................. 6
ALUMINUM WHEEL ............................................. 6
STEEL WHEEL ..................................................... 6
ROAD WHEEL TIRE ASSEMBLY .............................. 7
Balancing Wheels (Bonding Weight Type) ............... 7
REMOVAL ............................................................. 7
WHEEL BALANCE ADJUSTMENT ...................... 7
Tire Rotation ............................................................. 8
DESCRIPTION ...................................................... 8
TIRE PRESSURE MONITORING SYSTEM ............. 10
System Components .............................................. 10
System Description ................................................ 10
TRANSMITTER ................................................... 10
REMOTE KEYLESS ENTRY RECEIVER ........... 10
BCM (BODY CONTROL MODULE) ..................... 11
LOW TIRE PRESSURE WARNING LAMP .......... 11
Can Communication ............................................... 12
SYSTEM DESCRIPTION .................................... 12
TROUBLE DIAGNOSIS ............................................ 13
How to Perform Trouble Diagnosis ........................ 13
BASIC CONCEPT ............................................... 13
INTRODUCTION ................................................. 13
WORK FLOW ...................................................... 14
Schematic .............................................................. 15
Wiring Diagram — T/WARN — .............................. 16
Trouble Diagnosis Chart for Symptoms ................. 19
Control Unit Input/Output Signal Standard ............. 20ID Registration Procedure ...................................... 21
ID REGISTRATION WITH ACTIVATION TOOL ... 21
ID REGISTRATION WITHOUT ACTIVATION
TOOL ................................................................... 21
Transmitter Wake Up Operation ............................. 22
WITH ACTIVATION TOOL .................................. 22
CONSULT-III Function (BCM) ................................ 22
CONSULT-III MAIN FUNCTION .......................... 22
WORK SUPPORT MODE ................................... 22
SELF-DIAG RESULTS MODE ............................ 23
DATA MONITOR MODE ...................................... 24
ACTIVE TEST MODE ......................................... 25
Diagnosis Procedure with Warning Lamp Function
(Without CONSULT-III) ........................................... 26
DESCRIPTION .................................................... 26
FUNCTION .......................................................... 26
MALFUNCTION CODE CHART .......................... 26
LOW TIRE PRESSURE WARNING LAMP
SYMPTOM CHART ............................................. 27
Preliminary Check .................................................. 29
BASIC INSPECTION ........................................... 29
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ........................................................................ 30
Transmitter or Control Unit (BCM) .......................... 30
MALFUNCTION CODE NO. 21, 22, 23 OR 24 ... 30
Transmitter - 1 ........................................................ 30
MALFUNCTION CODE NO. 31, 32, 33, 34, 41,
42, 43, 44, 45, 46, 47 OR 48 ............................... 30
Transmitter - 2 ........................................................ 31
MALFUNCTION CODE NO. 35, 36, 37 OR 38 ... 31
Vehicle Speed Signal .............................................. 32
MALFUNCTION CODE NO. 52 ........................... 32
TROUBLE DIAGNOSIS FOR SYMPTOMS .............. 33
Warning Lamp Does Not Come On When Ignition
Switch Is Turned On ............................................... 33
DIAGNOSTIC PROCEDURE .............................. 33
Warning Lamp Stays On When Ignition Switch Is
Turned On .............................................................. 33
DIAGNOSTIC PROCEDURE .............................. 33
Warning Lamp Blinks When Ignition Switch Is

WT-2Revision: 2006 November2007 350Z Turned On ............................................................... 35
DIAGNOSTIC PROCEDURE .............................. 35
Turn Signal Lamp Blinks When Ignition Switch Is
Turned On ............................................................... 36
DIAGNOSTIC PROCEDURE .............................. 36
ID Registration Can Not Be Completed .................. 36
DIAGNOSTIC PROCEDURE .............................. 36REMOVAL AND INSTALLATION .............................. 37
Transmitter .............................................................. 37
REMOVAL ............................................................ 37
INSTALLATION .................................................... 37
REMOTE KEYLESS ENTRY RECEIVER ............ 38
BCM (BODY CONTROL MODULE) .................... 38
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 39
Road Wheel ............................................................ 39
Tire .......................................................................... 39
Tightening Torque ................................................... 39

PRECAUTIONS
WT-3
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2006 November2007 350Z
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NES000LO
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Battery ServiceNES000LP
Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.
Service Notice or PrecautionsNES000LQ

Low tire pressure warning lamp flashes 1min., then turns ON when occurring any malfunction except low
tire pressure.
Delete the memory with CONSULT-III, or register the ID to turn low tire pressure warning lamp OFF. Refer
to WT-21, "
ID Registration Procedure" .

ID registration is required when replacing or rotating wheels. replacing transmitter or BCM. Refer to WT-
21, "ID Registration Procedure" .

Replace grommet seal, valve core and cap of the transmitter in TPMS every tire replacement by reaching
wear limit of tire.

WT-4
PREPARATION
Revision: 2006 November2007 350Z
PREPARATIONPFP:00002
Special Service ToolsNES00014
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolsNES00015
Tool number
(Kent-Moore No.)
Tool nameDescription
(J-45295)
Transmitter activation toolID registration
SEIA0462E
Tool nameDescription
Power toolRemoving wheel nuts
PBIC0190E

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
WT-5
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2006 November2007 350Z
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartNES00016
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
×: Applicable Reference page
FAX-4
,FSU-5 WT-6—
—
—
—
—
—
NVH in PR section.
NVH in RFD section.
NVH in FAX and FSU sections.
NVH in RAX and RSU sections.
Refer to TIRES in this chart.
Refer to ROAD WHEEL in this chart.
NVH in RAX section.
NVH in BR section.
NVH in PS section.
Possible cause and SUSPECTED PARTS
Improper installation, looseness
Out-of-round
Imbalance
Incorrect tire pressure
Uneven tire wear
Deformation or damage
Non-uniformity
Incorrect tire size
PROPELLER SHAFT
DIFFERENTIAL
FRONT AXLE AND FRONT SUSPENSION
REAR AXLE AND REAR SUSPENSION
TIRES
ROAD WHEEL
DRIVE SHAFT
BRAKE
STEERING
SymptomTIRESNoise× ×××××× ×××× ××××
Shake× ××××× ×× ×× ××××
Vibration×××××××
Shimmy× ××××××× ×× × ××
Judder× ××××× × ×× × ××
Poor quality ride
or handling× ××××× × ×× ×
ROAD WHEELNoise× ×× × ××××× ×××
Shake× ×× × × ××× ×××
Shimmy, judder× ×× × ××× ××
Poor quality ride
or handling× ×× × ×××

WT-6
ROAD WHEEL
Revision: 2006 November2007 350Z
ROAD WHEELPFP:40300
InspectionNES00017
ALUMINUM WHEEL
1. Check tires for wear and improper inflation.
2. Check wheels for deformation, cracks and other damage. If
deformed, remove wheel and check wheel runout.
a. Remove tire from aluminum wheel and mount on a tire balance
machine.
b. Set dial indicator as shown in the figure.
STEEL WHEEL
1. Check tires for wear and improper inflation.
2. Check wheels for deformation, cracks and other damage. If
deformed, remove wheel and check wheel runout.
a. Remove tire from steel wheel and mount wheel on a tire balance
machine.
b. Set two dial indicators as shown in the figure.
c. Set each dial indicator to 0.
d. Rotate wheel and check dial indicators at several points around
the circumference of the wheel.
e. Calculate runout at each point as shown below.
f. Select maximum positive runout value and the maximum nega-
tive value.
Add the two values to determine total runout.
In case a positive or negative value is not available, use the
maximum value (negative or positive) for total runout.
If the total runout value exceeds the limit, replace steel wheel.Wheel runout (Dial indicator value):
Refer to WT-39, "
SERVICE DATA AND SPECIFICA-
TIONS (SDS)" .SFA975B
Radial runout = (A+B)/2
Lateral runout = (C+D)/2
Wheel runout:
Refer to WT-39, "
SERVICE DATA AND SPECIFICA-
TIONS (SDS)" .
SEIA0558E

ROAD WHEEL TIRE ASSEMBLY
WT-7
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2006 November2007 350Z
ROAD WHEEL TIRE ASSEMBLYPFP:40300
Balancing Wheels (Bonding Weight Type)NES00018
REMOVAL
1. Remove inner and outer balance weights from the road wheel.
CAUTION:
Be careful not to scratch the road wheel during removal.
2. Using releasing agent, remove double-faced adhesive tape from the road wheel.
CAUTION:

Be careful not to scratch the road wheel during removal.

After removing double-faced adhesive tape, wipe clean traces of releasing agent from the road
wheel.
WHEEL BALANCE ADJUSTMENT

If a tire balance machine has adhesion balance weight mode settings and drive-in weight mode setting,
select and adjust a drive-in weight mode suitable for road wheels.
1. Set road wheel on wheel balancer using the center hole as a guide. Start the tire balance machine.
2. When inner and outer unbalance values are shown on the wheel balancer indicator, multiply outer unbal-
ance value by 5/3 to determine balance weight that should be used. Select the outer balance weight with
a value closest to the calculated value above and install it to the designated outer position of, or at the
designated angle in relation to the road wheel.
CAUTION:

Do not install the inner balance weight before installing the outer balance weight.

Before installing the balance weight, be sure to clean the
mating surface of the road wheel.
Indicated unbalance value × 5/3 = balance weight to be installed
Calculation example:
23 g (0.81 oz) × 5/3 = 38.33 g (1.35 oz) = 40 g (1.41 oz) balance
weight (closer to calculated balance weight value)
Note that balance weight value must be closer to the calculated
balance weight value.
Example:
37.4 = 35 g (1.23 oz)
37.5 = 40 g (1.41 oz)
a. Install balance weight in the position shown in the figure.
b. When installing balance weight to road wheels, set it into the
grooved area on the inner wall of the road wheel as shown in the
figure so that the balance weight center is aligned with the tire
balance machine indication position (angle).
CAUTION:

Always use genuine NISSAN adhesion balance weights.

Balance weights are unreusable; always replace with new
ones.

Do not install more than three sheets of balance weight.
SMA054D
SEIA0271E

WT-8
ROAD WHEEL TIRE ASSEMBLY
Revision: 2006 November2007 350Z
c. If calculated balance weight value exceeds 50 g (1.76 oz), install
two balance weight sheets in line with each other (as shown in
the figure).
CAUTION:
Do not install one balance weight sheet on top of another.
3. Start tire balance machine again.
4. Install drive-in balance weight on inner side of road wheel in the
tire balance machine indication position (angle).
CAUTION:
Do not install more than two balance weights.
5. Start tire balance machine. Make sure that inner and outer resid-
ual unbalance values are 5 g (0.17 oz) each or below.

If either residual unbalance value exceeds 5 g (0.17 oz), repeat installation procedures.
Wheel balance (Maximum allowable unbalance):
Tire RotationNES00019
CAUTION:

Do not include the T-type spare tire when rotating the tires.

Use NISSAN genuine wheel nuts for aluminum wheels.
NOTE:
Tire cannot be rotated in vehicle, as front tire are different size from rear tire and the direction of wheel rotation
is fixed in each tire.
DESCRIPTION
Safety Device Preventing from Being Incorrectly Installed
Front brake disc rotor and front wheel

Front and rear wheel size for this model differs, therefore a special pin has been installed on the front
brake disc rotor. To accommodate this pin a hole has been provided on the front wheel (the rear wheel
does not have this hole.) and in some case the rear wheel is being mistakenly installed on the front.
Maximum allowable
unbalanceDynamic (At rim flange) 5 g (0.17 oz) (one side)
Static (At rim flange) 10 g (0.35 oz)
SMA056D
SEIA0316E
