2007 NISSAN 350Z Rear Final Drive Workshop Manual

REAR FINAL DRIVE ASSEMBLY
RFD-57
C
E
F
G
H
I
J
K
L
MA
B
RFD
Revision: 2006 November2007 350Z
10. Install drive gear on the mounting bolts, and then tighten to the
specified torque. Refer to RFD-39, "
COMPONENTS" .
CAUTION:

Tighten bolts in a crisscross fashion.

After tightening the bolts to the specified torque, tighten
the bolts additionally by turning the bolts 31 to 36
degrees.
11. Press side bearing inner races to differential case, using the drift
and the base.
CAUTION:
Do not reuse side bearing inner race.
12. Install differential case assembly with side bearing outer races
into gear carrier.
13. Measure side bearing preload. If necessary, select the appropri-
ate side bearing adjusting washers. Refer to RFD-49, "
Side
Bearing Preload" .
14. Insert selected left and right side bearing adjusting washers in
place between side bearings and gear carrier.
15. Align matching marks on bearing cap with that on gear carrier.
16. Install bearing caps and tighten bearing cap mounting bolts to
the specified torque. Refer to RFD-39, "
COMPONENTS" .
SDIA0247J
Tool number A: KV38100300 (J-25523)
B: ST33061000 (J-8107-2)
SPD353
SPD919
SPD924
PDIA0069E

RFD-58
REAR FINAL DRIVE ASSEMBLY
Revision: 2006 November2007 350Z
17. Using the drift, drive side oil seals until it becomes flush with the
case end.
CAUTION:

Do not reuse oil seal.

When installing, do not incline oil seal.

Apply multi-purpose grease onto oil seal lips, and gear
oil onto the circumference of oil seal.
18. Check and adjust drive gear runout, tooth contact, drive gear to
drive pinion backlash, and total preload torque. Refer to RFD-
40, "Drive Gear Runout" , RFD-41, "Tooth Contact" , RFD-42,
"Backlash" and RFD-40, "Total Preload Torque" .
Recheck above items. Readjust the above description, if necessary.
19. Apply sealant to mating surface of rear cover.

Use Genuine Silicone RTV or equivalent. Refer to GI-45,
"Recommended Chemical Products and Sealants" .
CAUTION:
Remove old sealant adhering to mounting surfaces. Also
remove any moisture, oil, or foreign material adhering to
application and mounting surfaces.
20. Install rear cover on gear carrier and tighten mounting bolts with
the specified torque. Refer to RFD-39, "
COMPONENTS" .
21. Install side flange with the following procedure.
NOTE:
Install the RH side flange, then install the LH side flange. If LH side flange is installed first, the RH side
flange comes out sometimes from the shock of installing the RH side flange.
a. Attach the protector to side oil seal.
b. After the side flange is inserted and the serrated part of side
gear has engaged the serrated part of flange, remove the pro-
tector.
c. Put a suitable drift on the center of side flange, then drive it until
sound changes.
NOTE:
When installation is completed, driving sound of the side flange
turns into a sound which seems to affect the whole final drive.
d. Confirm that the dimension of the side flange installation (Mea-
surement A) in the figure comes into the following.Tool number : KV38100200 (J-26233)
Tool number : KV38107900 (J-39352)
SPD560
PDIA0961E
SDIA0822E
Measurement A: 326 – 328 mm (12.83 – 12.91 in)
PDIA0644E

SERVICE DATA AND SPECIFICATIONS (SDS)
RFD-59
C
E
F
G
H
I
J
K
L
MA
B
RFD
Revision: 2006 November2007 350Z
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsNDS0000L
Inspection and AdjustmentNDS0000M
DRIVE GEAR RUNOUT
DIFFERENTIAL SIDE GEAR CLEARANCE
PRELOAD TORQUE
BACKLASH
COMPANION FLANGE RUNOUT
Applied modelVQ35DE
M/T A/T
Final drive model R200 R200V (With LSD)
Gear ratio3.538 3.357
Number of teeth (Drive gear/Drive pinion) 46/13 47/14
Oil capacity (Approx.)
(US pt, lmp pt)1.4 (3, 2-1/2)
Number of pinion gears 2 4
Drive pinion adjustment spacer type Collapsible
Item Runout limit
Drive gear back face 0.05 mm (0.0020 in) or less
ItemSpecification
R200 R200V (With LSD)
Side gear backlash
(Clearance between side gear and differential case)0.2 mm (0.008 in) or less
(Each gear should rotate smoothly
without excessive resistance during
differential motion.)0.15 mm (0.0059 in) or less
(Each gear should rotate smoothly
without excessive resistance during
differential motion.)
Item Specification
Pinion bearing (P
1 ) 2.65 – 3.23 N·m (0.27 – 0.32 kg-m, 24 – 28 in-lb)
Side bearing (P
2 ) 0.20 – 0.52 N·m(0.02 – 0.05 kg-m, 2 – 4 in-lb)
Side bearing to pinion bearing (Total preload)
(Total preload = P
1 + P2 )2.85 – 3.75 N·m(0.29 – 0.38 kg-m, 26 – 33 in-lb)
Item Specification
Drive gear to drive pinion gear 0.10 – 0.15 mm (0.0039 – 0.0059 in)
Item Runout limit
Companion flange face 0.08 mm (0.0031 in) or less
Inner side of the companion flange 0.08 mm (0.0031 in) or less

RFD-60
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 November2007 350Z
SELECTIVE PARTS
Side Gear Thrust Washer
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
Pinion Height Adjusting Washer
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
Side Bearing Adjusting Washer
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.R200 R200V
Thickness Part number* Thickness Part number* Thickness Part number*
0.75 (0.0295)
0.78 (0.0307)
0.81 (0.0319)
0.84 (0.0331)
0.87 (0.0343)
0.90 (0.0350)
0.93 (0.0366)38424 EC000
38424 EC001
38424 EC002
38424 EC003
38424 EC004
38424 EC005
38424 EC0060.80 (0.0315)
0.83 (0.0327)
0.86 (0.0339)
0.89 (0.0350)
0.92 (0.0362)
0.95 (0.0374)
0.98 (0.0386)
1.01 (0.0398)
1.04 (0.0409)
1.07 (0.0421)
1.10 (0.0433)
1.13 (0.0445)38424 40F60
38424 40F61
38424 40F62
38424 40F63
38424 40F64
38424 40F65
38424 40F66
38424 40F67
38424 40F68
38424 40F69
38424 40F70
38424 40F711.16 (0.0457)
1.19 (0.0469)
1.22 (0.0480)
1.25 (0.0492)
1.28 (0.0504)
1.31 (0.0516)
1.34 (0.0528)
1.37 (0.0539)
1.40 (0.0551)
1.43 (0.0563)
1.46 (0.0575)
1.49 (0.0587)38424 40F72
38424 40F73
38424 40F74
38424 40F75
38424 40F76
38424 40F77
38424 40F78
38424 40F79
38424 40F80
38424 40F81
38424 40F82
38424 40F83
R200, R200V
Thickness Part number* Thickness Part number*
3.05 (0.1201)
3.08 (0.1213)
3.11 (0.1224)
3.14 (0.1236)
3.17 (0.1248)
3.20 (0.1260)
3.23 (0.1272)
3.26 (0.1283)38154 0C000
38154 0C001
38154 0C002
38154 0C003
38154 0C004
38154 0C005
38154 0C006
38154 0C0073.29 (0.1295)
3.32 (0.1307)
3.35 (0.1319)
3.38 (0.1331)
3.41 (0.1343)
3.44 (0.1354)
3.47 (0.1366)
3.50(0.1378)38154 0C008
38154 0C009
38154 0C010
38154 0C011
38154 0C012
38154 0C013
38154 0C014
38154 0C015
R200, R200V
Thickness Part number* Thickness Part number*
2.00 (0.0787)
2.05 (0.0807)
2.10 (0.0827)
2.15 (0.0846)
2.20 (0.0866)
2.25 (0.0886)
2.30 (0.0906)38453 N3100
38453 N3101
38453 N3102
38453 N3103
38453 N3104
38453 N3105
38453 N31062.35 (0.0925)
2.40 (0.0945)
2.45 (0.0965)
2.50 (0.0984)
2.55 (0.1004)
2.60 (0.1024)
2.65 (0.1043)38453 N3107
38453 N3108
38453 N3109
38453 N3110
38453 N3111
38453 N3112
38453 N3113
