EM-2Revision: 2006 November2007 350Z ROCKER COVER ..................................................... 40
Removal and Installation ........................................ 40
REMOVAL ........................................................... 40
INSTALLATION .................................................... 42
FRONT TIMING CHAIN CASE ................................. 44
Removal and Installation ........................................ 44
REMOVAL ........................................................... 44
INSTALLATION .................................................... 47
INSPECTION AFTER INSTALLATION ................ 51
TIMING CHAIN .......................................................... 53
Removal and Installation ........................................ 53
REMOVAL ........................................................... 54
INSPECTION AFTER REMOVAL ........................ 60
INSTALLATION .................................................... 60
INSPECTION AFTER INSTALLATION ................ 71
CAMSHAFT ............................................................... 72
Removal and Installation ........................................ 72
REMOVAL ........................................................... 72
INSPECTION AFTER REMOVAL ........................ 74
INSTALLATION .................................................... 77
INSPECTION AFTER INSTALLATION ................ 79
Valve Clearance ...................................................... 80
INSPECTION ....................................................... 80
ADJUSTMENT .................................................... 84
OIL SEAL .................................................................. 86
Removal and Installation of Valve Oil Seal ............. 86
REMOVAL ........................................................... 86
INSTALLATION .................................................... 86
Removal and Installation of Front Oil Seal ............. 87
REMOVAL ........................................................... 87
INSTALLATION .................................................... 87
Removal and Installation of Rear Oil Seal .............. 87
REMOVAL ........................................................... 87
INSTALLATION .................................................... 88
CYLINDER HEAD ..................................................... 89
On-Vehicle Service ................................................. 89
CHECKING COMPRESSION PRESSURE ......... 89
Removal and Installation ........................................ 90
REMOVAL ........................................................... 90
INSPECTION AFTER REMOVAL ........................ 91
INSTALLATION .................................................... 92
INSPECTION AFTER INSTALLATION ................ 93
Disassembly and Assembly .................................... 94
DISASSEMBLY ................................................... 94
ASSEMBLY ......................................................... 95
Inspection After Disassembly ................................. 96
VALVE DIMENSIONS .......................................... 96
VALVE GUIDE CLEARANCE .............................. 97
VALVE GUIDE REPLACEMENT ......................... 97
VALVE SEAT CONTACT ..................................... 99
VALVE SEAT REPLACEMENT ........................... 99
VALVE SPRING SQUARENESS .......................100
VALVE SPRING DIMENSIONS AND VALVE
SPRING PRESSURE LOAD .............................100
ENGINE ASSEMBLY ..............................................101
Removal and Installation ......................................101
REMOVAL .........................................................102
INSTALLATION ..................................................104
INSPECTION AFTER INSTALLATION ..............106CYLINDER BLOCK .................................................107
Disassembly and Assembly ..................................107
DISASSEMBLY ..................................................108
ASSEMBLY ........................................................ 111
How to Select Piston and Bearing ........................119
DESCRIPTION ..................................................119
HOW TO SELECT PISTON ...............................119
HOW TO SELECT CONNECTING ROD BEAR-
ING .....................................................................120
HOW TO SELECT MAIN BEARING ..................122
Inspection After Disassembly ................................125
CRANKSHAFT END PLAY ................................125
CONNECTING ROD SIDE CLEARANCE .........125
PISTON TO PISTON PIN OIL CLEARANCE .....125
PISTON RING SIDE CLEARANCE ...................126
PISTON RING END GAP ..................................126
CONNECTING ROD BEND AND TORSION .....127
CONNECTING ROD BIG END DIAMETER ......127
CONNECTING ROD BUSHING OIL CLEAR-
ANCE .................................................................127
CYLINDER BLOCK DISTORTION ....................128
MAIN BEARING HOUSING INNER DIAMETER .129
PISTON TO CYLINDER BORE CLEARANCE ..129
CRANKSHAFT MAIN JOURNAL DIAMETER ...130
CRANKSHAFT PIN JOURNAL DIAMETER ......131
CRANKSHAFT OUT-OF-ROUND AND TAPER .131
CRANKSHAFT RUNOUT ..................................131
CONNECTING ROD BEARING OIL CLEAR-
ANCE .................................................................131
MAIN BEARING OIL CLEARANCE ...................132
CRUSH HEIGHT OF MAIN BEARING ..............133
CRUSH HEIGHT OF CONNECTING ROD
BEARING ...........................................................133
LOWER CYLINDER BLOCK BOLT OUTER
DIAMETER ........................................................133
CONNECTING ROD BOLT OUTER DIAMETER .134
FLYWHEEL DEFLECTION (M/T MODELS) ......134
MOVEMENT AMOUNT OF FLYWHEEL (M/T
MODELS) ...........................................................134
DRIVE PLATE (A/T MODELS) ...........................135
OIL JET ..............................................................135
OIL JET RELIEF VALVE ....................................135
SERVICE DATA AND SPECIFICATIONS (SDS) ....136
Standard and Limit ................................................136
GENERAL SPECIFICATIONS ...........................136
INTAKE MANIFOLD COLLECTOR, INTAKE
MANIFOLD AND EXHAUST MANIFOLD ..........136
SPARK PLUG ....................................................137
CAMSHAFT AND CAMSHAFT BEARING .........137
CYLINDER HEAD ..............................................139
CYLINDER BLOCK ............................................142
PISTON, PISTON RING AND PISTON PIN ......143
CONNECTING ROD ..........................................144
CRANKSHAFT ...................................................145
MAIN BEARING .................................................146
CONNECTING ROD BEARING .........................147

EM-4
PRECAUTIONS
Revision: 2006 November2007 350Z

After repairing, start engine and increase engine speed to check engine coolant, fuel, engine oil, and
exhaust gases for leakage.
Parts Requiring Angle TighteningNBS00007

Use angle wrench [SST: KV10112100 (BT8653-A)] for the final tightening of the following engine parts:
–Cylinder head bolts
–Lower cylinder block bolts
–Connecting rod cap bolts

Do not use a torque value for final tightening.

The torque value for these parts are for a preliminary step.

Ensure thread and seat surfaces are clean and coated with engine oil.
Precautions for Liquid GasketNBS00008
REMOVAL OF LIQUID GASKET SEALING

After removing mounting bolts and nuts, separate the mating
surface using seal cutter (SST) and remove old liquid gasket
sealing.
CAUTION:
Be careful not to damage the mating surfaces.

Tap seal cutter to insert it, and then slide it by tapping on the
side as shown in the figure.

In areas where seal cutter (SST) is difficult to use, use plastic
hammer to lightly tap the parts, to remove it.
CAUTION:
If for some unavoidable reason tool such as screwdriver is
used, be careful not to damage the mating surfaces.
LIQUID GASKET APPLICATION PROCEDURE
1. Using scraper, remove old liquid gasket adhering to the gasket
application surface and the mating surface.

Remove liquid gasket completely from the groove of the gas-
ket application surface, mounting bolts, and bolt holes.
2. Wipe the liquid gasket application surface and the mating sur-
face with white gasoline (lighting and heating use) to remove
adhering moisture, grease and foreign materials.
3. Attach liquid gasket tube to tube presser [SST: WS39930000
(—)].
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-45, "
RECOMMENDED CHEMICAL PRODUCTS AND
SEALANTS" .
4. Apply liquid gasket without breaks to the specified location with
the specified dimensions.

If there is a groove for liquid gasket application, apply liquid
gasket to the groove.
PBIC0002E
PBIC0003E
EMA0622D

EM-8
PREPARATION
Revision: 2006 November2007 350Z
(Kent-Moore No.)
Tool nameDescription
Power toolLoosening bolts and nuts
TORX socketRemoving and installing flywheel
Size: T55
(—)
Manual lift table caddyRemoving and installing engine
(J24239-01)
Cylinder head bolt wrenchLoosening and tightening cylinder head bolt,
and used with angle wrench [SST:
KV10112100 (BT8653-A)]
a: 13 (0.51) dia.
b: 12 (0.47)
c: 10 (0.39)
Unit: mm (in)
(—)
1. Compression gauge
2. AdapterChecking compression pressure
(—)
Spark plug wrenchRemoving and installing spark plug
(—)
Valve seat cutter setFinishing valve seat dimensions
PBIC0190E
PBIC1113E
ZZA1210D
NT583
ZZA0008D
PBIC3874E
NT048

EM-96
CYLINDER HEAD
Revision: 2006 November2007 350Z
8. Install valve collet.

Compress valve spring with valve spring compressor, attach-
ment and adapter (SST). Install valve collet with magnet
hand.
CAUTION:
When working, take care not to damage valve lifter holes.

Tap valve stem edge lightly with plastic hammer after installa-
tion to check its installed condition.
9. Install valve lifter.

Install it in the original position.
10. Install spark plug tube.

Press-fit spark plug tube as follows:
a. Remove old liquid gasket adhering to cylinder head mounting hole.
b. Apply liquid gasket to area within approximately 12 mm (0.47 in) from edge of spark plug tube press-fit
side.
Use Genuine High Strength Locking Sealant or equivalent. Refer to GI-45, "
RECOMMENDED
CHEMICAL PRODUCTS AND SEALANTS" .
c. Using drift, press-fit spark plug tube so that its height “H” is as
specified in the figure.
CAUTION:

When press-fitting, take care not to deform spark plug
tube.

After press-fitting, wipe off liquid gasket protruding onto
cylinder-head upper face.
11. Install spark plug with spark plug wrench (commercial service
tool).
Inspection After DisassemblyNBS00011
VALVE DIMENSIONS

Check dimensions of each valve. For dimensions, refer to EM-
139, "Valve Dimensions" .

If dimensions are out of the standard, replace valve and check
valve seat contact. Refer to EM-99, "
VALVE SEAT CONTACT" .
PBIC1803E
Standard press-fit height “H”:
: 37.7 - 38.7 mm (1.484 - 1.524 in)
PBIC2638E
SEM188A

EM-98
CYLINDER HEAD
Revision: 2006 November2007 350Z
3. Using valve guide reamer (commercial service tool), ream cylin-
der head valve guide hole.
4. Heat cylinder head to 110 to 130°C (230 to 266°F) by soaking in
heated oil.
5. Using valve guide drift (commercial service tool), press valve
guide from camshaft side to the dimensions as in the figure.
WARNING:
Cylinder head contains heat. When working, wear protec-
tive equipment to avoid getting burned.
6. Using valve guide reamer (commercial service tool), apply
reamer finish to valve guide.Valve guide hole diameter (for service parts):
Intake and exhaust
: 10.175 - 10.196 mm (0.4006 - 0.4014 in)
SEM932C
SEM008A
Projection “L”
Intake and exhaust
: 12.6 - 12.8 mm (0.496 - 0.504 in)
SEM950E
Standard:
Intake and exhaust
: 6.000 - 6.018 mm (0.2362 - 0.2369 in)
SEM932C

CYLINDER HEAD
EM-99
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 November2007 350Z
VALVE SEAT CONTACT

After confirming that the dimensions of valve guides and valves
are within the specifications, perform this procedure.

Apply prussian blue (or white lead) onto contacting surface of
valve seat to check the condition of the valve contact on the sur-
face.

Check if the contact area band is continuous all around the cir-
cumference.

If not, grind to adjust valve fitting and check again. If the contact-
ing surface still has “NG” conditions even after the re-check,
replace valve seat. Refer to EM-99, "
VALVE SEAT REPLACE-
MENT" .
VALVE SEAT REPLACEMENT
When valve seat is removed, replace with Oversize (Service) [0.5 mm (0.020 in)] valve seat.
1. Bore out old seat until it collapses. Boring should not continue beyond the bottom face of the seat recess
in cylinder head. Set the machine depth stop to ensure this. Refer to EM-141, "
Va l v e S e a t" .
CAUTION:
Prevent to scratch cylinder head by excessive boring.
2. Ream cylinder head recess diameter for service valve seat.

Be sure to ream in circles concentric to valve guide center.
This will enable valve to fit correctly.
3. Heat cylinder head to 110 to 130°C (230 to 266°F) by soaking in
heated oil.
4. Provide valve seats cooled well with dry ice. Force fit valve seat into cylinder head.
WARNING:

Avoid directly touching cold valve seats.

Cylinder head contains heat. When working, wear protective equipment to avoid getting burned.
5. Using valve seat cutter set (commercial service tool) or valve
seat grinder, finish seat to the specified dimensions. Refer to
EM-141, "
Valve Seat" .
CAUTION:
When using valve seat cutter, firmly grip cutter handle with
both hands. Then, press on the contacting surface all
around the circumference to cut in a single drive. Improper
pressure on with cutter or cutting many different times may
result in stage valve seat.
SBIA0322E
Oversize (Service) [0.5 mm (0.020 in)]
Intake : 38.500 - 38.516 mm (1.5157 - 1.5164 in)
Exhaust : 32.100 - 32.116 mm (1.2638 - 1.2644 in)
SEM795A
SEM008A
SEM934C

EM-100
CYLINDER HEAD
Revision: 2006 November2007 350Z
6. Using compound, grind to adjust valve fitting.
7. Check again for normal contact. Refer to EM-99, "
VALVE SEAT CONTACT" .
VALVE SPRING SQUARENESS

Set try square along the side of valve spring and rotate spring.
Measure the maximum clearance between the top face of spring
and try square.

If it exceeds the limit, replace valve spring.
VALVE SPRING DIMENSIONS AND VALVE SPRING PRESSURE LOAD

Check valve spring pressure at specified spring height.

If the installation load or load with valve open is out of the standard, replace valve spring.Limit: : 1.9 mm (0.075 in)
PBIC0080E
Standard:
Intake and exhaust
Free height : 43.85 mm (1.7264 in)
Installation height : 37.0 mm (1.457 in)
Installation load : 166 – 188 N
(16.9 – 19.2 kg, 37 – 42 lb)
Height during valve open : 26.8 mm (1.055 in)
Load with valve open : 502 – 566 N
(51.2 – 57.7 kg, 113 – 127 lb)
SEM113

CYLINDER BLOCK
EM-131
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 November2007 350Z
CRANKSHAFT PIN JOURNAL DIAMETER

Measure the outer diameter of crankshaft pin journal with
micrometer.

If out of the standard, measure the connecting rod bearing oil
clearance. Then use undersize bearing. Refer to EM-131,
"CONNECTING ROD BEARING OIL CLEARANCE" .
CRANKSHAFT OUT-OF-ROUND AND TAPER

Measure the dimensions at four different points as shown in the
figure on each main journal and pin journal with micrometer.

Out-of-round is indicated by the difference in the dimensions
between “X” and “Y” at “A” and “B”.

Taper is indicated by the difference in the dimensions between
“A” and “B” at “X” and “Y”.

If the measured value exceeds the limit, correct or replace crankshaft.

If corrected, measure the bearing oil clearance of the corrected main journal and/or pin journal. Then
select the main bearing and/or connecting rod bearing. Refer to EM-132, "
MAIN BEARING OIL CLEAR-
ANCE" and/or EM-131, "CONNECTING ROD BEARING OIL CLEARANCE" .
CRANKSHAFT RUNOUT

Place V-block on precise flat table, and support the journals on
the both end of crankshaft.

Place dial indicator straight up on the No. 3 journal.

While rotating crankshaft, read the movement of the pointer on
dial indicator. (Total indicator reading)

If it exceeds the limit, replace crankshaft.
CONNECTING ROD BEARING OIL CLEARANCE
Method by Calculation

Install connecting rod bearings to connecting rod and cap, and
tighten connecting rod bolts to the specified torque. Refer to
E M - 111 , "
ASSEMBLY" for the tightening procedure.

Measure the inner diameter of connecting rod bearing with
inside micrometer.
(Bearing oil clearance) = (Connecting rod bearing inner diameter) –
(Crankshaft pin journal diameter)Standard : 53.956 - 53.974 mm (2.1242 - 2.1250 in) dia.
PBIC0127E
Limit:
Out-of-round (Difference between “X” and “Y”)
: 0.0025 mm (0.0001 in)
Taper (Difference between “A” and “B”)
: 0.0025 mm (0.0001 in)
SBIA0535E
Standard : Less than 0.05 mm (0.0020 in)
Limit : 0.10 mm (0.004 in)
SEM346D
Standard : 0.040 - 0.053 mm (0.0016 - 0.0021 in)
(actual clearance)
Limit : 0.070 mm (0.0028 in)
PBIC1642E
