UNIFIED METER AND A/C AMP
DI-47
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
CONSULT-III Function (METER A/C AMP)NKS00071
CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.
SELF-DIAGNOSTIC RESULTS
Display Item List
NOTE:
“TIME” means the following.
0: Means detected malfunction at present.
1-63: Means detected malfunction in past. (Displays number of ignition switch OFF → ON after detecting
malfunction. “Self-diagnosis result” is erased when exceeding “63”.)
DATA MONITOR
Display Item List
System Diagnosis mode Description
METER A/C AMPSELF-DIAG RESULTSUnified meter and A/C amp. check the conditions and displays memo-
rized erro.
DATA MONOTOR Displays unified meter and A/C amp. input data in real time.
Display item [Code] Malfunction is detected when...Reference
page
CAN COMM CIRC [U1000]When unifield meter and A/C amp. is not transmitting or receiving CAN communica-
tion signal for 2 seconds or less.DI-50
T/METER COMM CIRC [B2201]Malfunction is detected in communication of between triple meter and unified meter
and A/C amp.DI-50
METER COMM CIRC [B2202]Malfunction is detected in communication of between combination meter and unified
meter and A/C amp.DI-52
VEHICLE SPEED CIRC [B2205]When an erroneous signal is input.
CAUTION:
Even when there is no malfunction on speed signal system, malfunction may be
misinterpreted when battery has low voltage (when maintaining 7 - 8 V for about
2 seconds). DI-55
Monitor item [Unit] MAIN SIGNALSSELECTION
FROM MENUContents
SPEED METER [km/h] or [mph] X XThis is the angle correction value after the speed signal
from the VDC/TCS/ABS control unit [with VDC system] or
ABS actuator and electric unit (control unit) [without VDC
system] is converted into the vehicle speed.
SPEED OUTPUT [km/h] or [mph] X XThis is the angle correction value before the speed signal
from the VDC/TCS/ABS control unit [with VDC system] or
ABS actuator and electric unit (control unit) [without VDC
system] is converted into the vehicle speed.
TACHO METER [rpm] X XThis is the converted value for the engine speed signal
from the ECM.
W TEMP METER [°C] or [°F] X XThis is the converted value for the engine coolant tempera-
ture signal from the ECM.
FUEL METER [lit.] X XThis is the processed value for the signal (resistance
value) from the fuel gauge.
DISTANCE [km] or [mile] X XThis is the calculated value for the speed signal from the
VDC/TCS/ABS control unit [with VDC system] or ABS
actuator and electric unit (control unit) [without VDC sys-
tem] and the signal (resistance signal) from the fuel gauge.
FUEL W/L [ON/OFF] X X Indicates [ON/OFF] condition of low-fuel warning lamp.
MIL [ON/OFF] XIndicates [ON/OFF] condition of malfunction indicator
lamp.
WARNING CHIME
DI-83
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
CONSULT-III Function (METER A/C AMP)NKS0007O
Refer to DI-47, "CONSULT-III Function (METER A/C AMP)" in “UNIFIED METER AND A/C AMP”.
CONSULT-III Function (BCM)NKS0007P
CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.
DIAGNOSTIC ITEMS DESCRIPTION
DATA MONITOR
Display Item List
ACTIVE TEST
Display Item List
SELF-DIAGNOSTIC RESULTS
Display Item List
NOTE:
If “CAN communication [U1000]” is indicated, after printing the monitor item, go to “CAN system”. Refer to
LAN-48, "
CAN System Specification Chart" .
Trouble DiagnosisNKS00267
HOW TO PERFORM TROUBLE DIAGNOSIS
1. Confirm the symptom and customer complaint.
2. Understand the outline of system. Refer to DI-71, "
System Description" .
3. Perform the preliminary inspection. Refer to DI-84, "
PRELIMINARY INSPECTION" .
4. Referring to trouble diagnosis chart, make sure the cause of the malfunction and repair or replace applica-
ble parts. Refer to DI-84, "
Symptom Chart" .
5. Does warning chime system operate normally? If yes, GO TO 6. If no, GO TO 4.
6. INSPECTION END
System Test item Diagnosis mode Description
BCMBCMSELF-DIAG
RESULTBCM performs self-diagnosis of CAN communication.
BUZZERDATA MONITOR The input data to the BCM control unit is displayed in real time.
ACTIVE TESTOperation of electrical loads can be checked by sending driving signal
to them.
Monitor item [Unit] ALL SIGNALSSELECTION
FROM MENUContents
IGN ON SW [ON/OFF] X X Indicates [ON/OFF] condition of ignition switch.
KEY ON SW [ON/OFF] X X Indicates [ON/OFF] condition of key switch.
DOOR SW-DR [ON/OFF] X X Indicates [ON/OFF] condition of driver side door switch.
LIGHT SW 1ST [ON/OFF] X X Indicates [ON/OFF] condition of lighting switch.
BUCKLE SW [ON/OFF] X X Indicates [ON/OFF] condition of seat belt switch.
Test item Malfunction is detected when···
LIGHT WARN ALM This test is able to check light warning chime operation.
IGN KEY WARN ALM This test is able to check ignition key warning chime operation.
SEAT BELT WARN ALM This test is able to check seat belt warning chime operation.
Display item [Code] Malfunction is detected when···
CAN communication [U1000] Malfunction is detected in CAN communication.
