2007 NISSAN 350Z Clutch Workshop Manual

CLUTCH DISC, CLUTCH COVER
CL-17
D
E
F
G
H
I
J
K
L
MA
B
CL
Revision: 2006 November2007 350Z
INSPECTION AND ADJUSTMENT AFTER REMOVAL
Clutch Disc

Measure circumference runout relative to the clutch disc center
spline. If it is outside the specification, replace clutch disc and
clutch cover as a set.

Measure backlash for clutch disc spline and main drive shaft
spline at the circumference of the clutch disc. If it is outside the
specified range, replace clutch disc and clutch cover as a set.

Using calipers, measure the depth to the clutch disc facing rivet
heads. If it exceeds the allowable wear limit, replace clutch disc
and clutch cover as a set.
Clutch Cover
Check diaphragm spring lever claws for unevenness with the lever
still on the vehicle. If they exceed the tolerance, adjust lever height
using the diaphragm adjusting wrench.

Check clutch cover thrust ring for wear or breakage. If wear or
breakage is found, replace clutch disc and clutch cover as a set.
NOTE:

Worn thrust ring will generate a beating noise when tapped at
the rivet with a hammer.

Broken thrust ring will make a clinking sound when cover is shaken up and down.

If a trace of burn or discoloration is found on the clutch cover pressure plate to clutch disc contact surface,
repair the surface with sandpaper. If surface is damaged or distorted, replace clutch disc and clutch cover
as a set.
INSTALLATION
1. Apply recommended grease to clutch disc and main drive gear spline.
CAUTION:
Be sure to apply grease to the points specified. Otherwise, noise, poor disengagement, or damage
to the clutch may result. Excessive grease may cause slip or judder. And if it adheres to seal of
CSC body, it cause clutch fluid leakage. Wipe off excess grease. Wipe off any grease oozing from
the parts.Runout limit/diameter of the area to be measured
: 1.0 mm (0.039 in)/230 mm (9.06 in) dia.
Maximum backlash of spline
: 1.0 mm (0.039 in)
SCL221
Facing wear limit (depth to the rivet head)
: 0.3 mm (0.012 in)
SCL229
Tolerance for diaphragm spring lever unevenness
: 0.8 mm (0.031 in)
Tool number : ST20050240 ( — )
SCIA6796E

CL-18
CLUTCH DISC, CLUTCH COVER
Revision: 2006 November2007 350Z
2. Install clutch disc and clutch cover. Pre-tighten mounting bolts
and install clutch aligning bar.
CAUTION:
If either clutch disk or clutch cover is needed to be
replaced, replace them as a set.
3. Tighten clutch cover mounting bolts evenly in two steps in the
order shown in the figure. Refer to CL-16, "
Removal and Instal-
lation" .
4. Install transmission assembly. Refer to MT-18, "
Removal and
Installation" . Tool number : ST20670000 ( — )
SCIA6797E

SERVICE DATA AND SPECIFICATIONS (SDS)
CL-19
D
E
F
G
H
I
J
K
L
MA
B
CL
Revision: 2006 November2007 350Z
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Clutch Control SystemNCS0000H
Clutch Master CylinderNCS0000I
Unit: mm (in)
Clutch DiscNCS0000K
Unit: mm (in)
Clutch CoverNCS0000L
Clutch PedalNCS0000M
Unit: mm (in) Type of clutch controlHydraulic
Inner diameter17.46 (11/16)
Standard length “L” between clevis and push rod
111 . 0 ± 0.5 (4.37 ± 0.02)
PCIB1944E
Facing size (Outer dia. × inner dia. × thickness) 240 × 160 × 3.8 (9.45 × 6.30 × 0.150)
Wear limit (depth to the rivet head) 0.3 (0.012)
Runout limit/diameter of the area to be measured 1.0 (0.039)/230 (9.06) dia.
Maximum backlash of spline (at outer edge disc) 1.0 (0.039)
Set-load10,300 N (1,050.6 kg, 2,315.4 lb)
Diaphragm spring lever height 44.6 - 46.8 mm (1.756 - 1.843 in)
Uneven limit of diaphragm spring toe height 0.8 mm (0.031 in) or less
Clearance ″C″ between pedal stopper rubber and clutch interlock
switch threaded while clutch pedal is fully depressed.0.1 - 1.0 (0.004 - 0.039)

CL-20
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 November2007 350Z
