CL-2
PRECAUTIONS
Revision: 2006 November2007 350Z
PRECAUTIONSPFP:00001
Precautions for Battery ServiceNCS00001
Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.
Service Notice or PrecautionsNCS00002
Recommended clutch fluid is brake fluid “DOT 3”. Refer to MA-11, "RECOMMENDED FLUIDS AND
LUBRICANTS" .
Never reuse drained clutch fluid.
Be careful not to splash clutch fluid on painted areas.
When removing clutch tube, use a flare nut wrench.
When installing clutch tube, use a flare nut torque wrench.
Use new clutch fluid to clean or wash all parts of master cylinder.
Never use mineral oils such as gasoline or kerosene. It will ruin
the rubber parts of the hydraulic system.
If transmission assembly is removed from the vehicle, always
replace CSC (Concentric Slave Cylinder) body and CSC tube.
Return CSC body insert to original position to remove transmis-
sion assembly. Dust on clutch disc sliding parts may damage
seal of CSC body and may cause clutch fluid leakage.
Do not disassemble CSC body.
WARNING:
After cleaning clutch disc, wipe it with a dust collector. Do not use compressed air.SBR686C
