2007 NISSAN 350Z display

TROUBLE DIAGNOSIS
AT-85
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
I/C SOLENOIDInput clutch disengaged. Refer to AT- 1 9 . 0.6 – 0.8 A
Input clutch engaged. Refer to AT- 1 9
. 0 – 0.05 A
FR/B SOLENOIDFront brake engaged. Refer to AT- 1 9
. 0.6 – 0.8 A
Front brake disengaged. Refer to AT- 1 9
. 0 – 0.05 A
D/C SOLENOIDDirect clutch disengaged. Refer to AT- 1 9
. 0.6 – 0.8 A
Direct clutch engaged. Refer to AT- 1 9
. 0 – 0.05 A
HLR/C SOLHigh and low reverse clutch disengaged. Refer to AT- 1 9
. 0.6 – 0.8 A
High and low reverse clutch engaged. Refer to AT- 1 9
. 0 – 0.05 A
ON OFF SOLLow coast brake engaged. Refer to AT- 1 9
.ON
Low coast brake disengaged. Refer to AT- 1 9
.OFF
MANU MODE SWManual shift gate position (neutral) ON
Other than the above OFF
NON M-MODE SWManual shift gate position OFF
Other than the above ON
UP SW LEVERSelector lever: + side ON
Other than the above OFF
DOWN SW LEVERSelector lever: - side ON
Other than the above OFF
STARTER RELAYSelector lever in “N” and “P” positions. ON
Selector lever in other positions. OFF
ACCELE POSIReleased accelerator pedal. 0.0/8
Fully depressed accelerator pedal. 8.0/8
CLSD THL POSReleased accelerator pedal. ON
Fully depressed accelerator pedal. OFF
W/O THL POSFully depressed accelerator pedal. ON
Released accelerator pedal. OFF
BRAKE SWDepressed brake pedal. ON
Released brake pedal. OFF
GEAR During driving 1, 2, 3, 4, 5 Item name Condition Display value (Approx.)

AT-86
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
SELF-DIAGNOSTIC RESULT MODE
After performing self-diagnosis, place check marks for results on the AT- 4 4 , "DIAGNOSTIC WORKSHEET" .
Reference pages are provided following the items.
Display Items List
X: Applicable, —: Not applicable
Items (CONSULT-III
screen terms)Malfunction is detected when...TCM self-
diagnosisOBD-II (DTC)
Reference
page “TRANS-
MISSION”
with CON-
SULT-IIIMIL
*1 ,
“ENGINE” with
CONSULT-III
or GST
CAN COMM CIRCUITWhen TCM is not transmitting or receiving CAN communica-
tion signal for 2 seconds or more.U1000 U1000AT- 9 4
STARTER RELAY/
CIRCIf this signal is ON other than in “P” or “N” position, this is
judged to be a malfunction.
(And if it is OFF in “P” or “N” position, this too is judged to be
a malfunction.)P0615 —AT- 9 7
TCM TCM is malfunctioning P0700 P0700AT- 1 0 1
PNP SW/CIRC

PNP switch 1–4 signals input with impossible pattern.

“P” position is detected from “N” position without any other
position being detected in between.P0705 P0705AT- 1 0 2
TURBINE REV S/CIRC

TCM does not receive the proper voltage signal from the
sensor.

TCM detects an irregularity only at position of 4th gear for
turbine revolution sensor 2.P0717 P0717AT- 1 0 6
VEH SPD SEN/CIR AT

Signal from vehicle speed sensor A/T (Revolution sensor)
not input due to cut line or the like.

Unexpected signal input during running.

After ignition switch is turned ON, unexpected signal input
from vehicle speed sensor MTR before the vehicle starts
moving.P0720 P0720AT- 1 0 8
ENGINE SPEED SIGTCM does not receive the CAN communication signal from
the ECM.P0725 P0725AT- 11 3
A/T 1ST GR FNCTN A/T cannot shift to 1st gear P0731 P0731AT- 11 5
A/T 2ND GR FNCTN A/T cannot shift to 2nd gear P0732 P0732AT- 11 7
A/T 3RD GR FNCTN A/T cannot shift to 3rd gear P0733 P0733AT- 11 9
A/T 4TH GR FNCTN A/T cannot shift to 4th gear P0734 P0734AT- 1 2 1
A/T 5TH GR FNCTN A/T cannot shift to 5th gear P0735 P0735AT- 1 2 3
TCC SOLENOID/CIRCNormal voltage not applied to solenoid due to cut line, short,
or the like.P0740 P0740AT- 1 2 5
A/T TCC S/V FNCTN

A/T cannot perform lock-up even if electrical circuit is
good.

TCM detects as irregular by comparing difference value
with slip rotation.P0744
P0744*2AT- 1 2 7
L/PRESS SOL/CIRC

Normal voltage not applied to solenoid due to cut line,
short, or the like.

TCM detects as irregular by comparing target value with
monitor value.P0745 P0745AT- 1 2 9
TP SEN/CIRC A/TTCM does not receive the proper accelerator pedal position
signals (input by CAN communication) from ECM.P1705 P1705AT- 1 3 1
ATF TEMP SEN/CIRC During running, the A/T fluid temperature sensor signal volt-
age is excessively high or low.P1710 P0710AT- 1 3 4

TROUBLE DIAGNOSIS
AT-87
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z

*1: Refer to AT- 3 9 , "Malfunction Indicator Lamp (MIL)" .

*2: These malfunctions cannot be displayed MIL if another malfunction is assigned to MIL. VEH SPD SE/CIR-MTR

Signal (CAN communication) from vehicle speed sensor
MTR not input due to cut line or the like.

Unexpected signal input during running.P1721 —AT-139
A/T INTERLOCKExcept during shift change, the gear position and ATF pres-
sure switch states are monitored and comparative judgment
made.P1730 P1730AT-141
A/T 1ST E/BRAKINGEach ATF pressure switch and solenoid current is monitored
and if a pattern is detected having engine braking 1st gear
other than in the M
1 position, a malfunction is detected.P1731 —AT-143
I/C SOLENOID/CIRC

Normal voltage not applied to solenoid due to functional
malfunction, cut line, short, or the like.

TCM detects as irregular by comparing target value with
monitor value.P1752 P1752AT-145
FR/B SOLENOID/CIRC

Normal voltage not applied to solenoid due to functional
malfunction, cut line, short, or the like.

TCM detects as irregular by comparing target value with
monitor value.P1757 P1757AT-147
D/C SOLENOID/CIRC

Normal voltage not applied to solenoid due to cut line,
short, or the like.

TCM detects as irregular by comparing target value with
monitor value.P1762 P1762AT-149
HLR/C SOL/CIRC

Normal voltage not applied to solenoid due to functional
malfunction, cut line, short, or the like.

TCM detects as irregular by comparing target value with
monitor value.P1767 P1767AT-151
LC/B SOLENOID/CIRCNormal voltage not applied to solenoid due to functional mal-
function, cut line, short, or the like.P1772 P1772AT-153
LC/B SOLENOID FNCT

TCM detects an improper voltage drop when it tries to
operate the solenoid valve.

Condition of ATF pressure switch 2 is different from moni-
tor value, and relation between gear position and actual
gear ratio is irregular.P1774
P1774*2AT-155
MANU MODE SW/
CIRCWhen an impossible pattern of switch signals is detected, a
malfunction is detected.P1815 —AT-157
NO DTC IS DETECTED
FURTHER TESTING
MAY BE REQUIREDNo NG item has been detected. X X — Items (CONSULT-III
screen terms)Malfunction is detected when...TCM self-
diagnosisOBD-II (DTC)
Reference
page “TRANS-
MISSION”
with CON-
SULT-IIIMIL
*1 ,
“ENGINE” with
CONSULT-III
or GST

AT-88
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
DATA MONITOR MODE
Display Items List
X: Standard, —: Not applicable, : Option
Monitored item (Unit)Monitor Item Selection
Remarks
ECU INPUT
SIGNALSMAIN SIG-
NALSSELEC-
TION FROM
MENU
VHCL/S SE-A/T (km/h) X X Revolution sensor
VHCL/S SE-MTR (km/h) X —
ACCELE POSI (0.0/8) X — Accelerator pedal position signal
THROTTLE POSI (0.0/8) X XDegree of opening for accelerator recognized by
the TCM.
For fail-safe operation, the specific value used for
control is displayed.
CLSD THL POS (ON/OFF) X —
Signal input with CAN communications.
W/O THL POS (ON/OFF) X —
BRAKE SW (ON/OFF) X — Stop lamp switch
GEAR — XGear position recognized by the TCM updated
after gear-shifting.
ENGINE SPEED (rpm) X X
TURBINE REV (rpm) X X
OUTPUT REV (rpm) X X
GEAR RATIO — X
TC SLIP SPEED (rpm) — XDifference between engine speed and torque
converter input shaft speed.
F SUN GR REV (rpm) — —
F CARR GR REV (rpm) — —
ATF TEMP SE 1 (V) X —
ATF TEMP SE 2 (V) X —
ATF TEMP 1 (°C) — X
ATF TEMP 2 (°C) — X
BATTERY VOLT (V) X —
ATF PRES SW 1 (ON/OFF) X X (for FR/B solenoid)
ATF PRES SW 2 (ON/OFF) X X (for LC/B solenoid)
ATF PRES SW 3 (ON/OFF) X X (for I/C solenoid)
ATF PRES SW 5 (ON/OFF) X X (for D/C solenoid)
ATF PRES SW 6 (ON/OFF) X X (for HLR/C solenoid)
PNP SW 1 (ON/OFF) X —
PNP SW 2 (ON/OFF) X —
PNP SW 3 (ON/OFF) X —
PNP SW 4 (ON/OFF) X —
1 POSITION SW (ON/OFF) X —

TROUBLE DIAGNOSIS
AT-89
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
SLCT LVR POSI — XSelector lever position is recognized by the TCM.
For fail-safe operation, the specific value used for
control is displayed.
OD CONT SW (ON/OFF) X —
Not mounted but displayed. POWERSHIFT SW (ON/OFF) X —
HOLD SW (ON/OFF) X —
MANU MODE SW (ON/OFF) X —
NON M-MODE SW (ON/OFF) X —
UP SW LEVER (ON/OFF) X —
DOWN SW LEVER (ON/OFF) X —
SFT UP ST SW (ON/OFF) — —
Not mounted but displayed.
SFT DWN ST SW (ON/OFF) — —
ASCD-OD CUT (ON/OFF) — —
ASCD-CRUISE (ON/OFF) — —
ABS SIGNAL (ON/OFF) — —
ACC OD CUT (ON/OFF) — —
Not mounted but displayed
ACC SIGNAL (ON/OFF) — —
TCS GR/P KEEP (ON/OFF) — —
TCS SIGNAL 2 (ON/OFF) — —
TCS SIGNAL 1 (ON/OFF) — —
TCC SOLENOID (A) — X
LINE PRES SOL (A) — X
I/C SOLENOID (A) — X
FR/B SOLENOID (A) — X
D/C SOLENOID (A) — X
HLR/C SOL (A) — X
ON OFF SOL (ON/OFF) — — LC/B solenoid
TCC SOL MON (A) — —
L/P SOL MON (A) — —
I/C SL MON (A) — —
FR/B SOL MON (A) — —
D/C SOL MON (A) — —
HLR/C SOL MON (A) — —
ON OFF SOL MON (ON/OFF) — — LC/B solenoid
P POSI IND (ON/OFF) — —
R POSI IND (ON/OFF) — —Monitored item (Unit)Monitor Item Selection
Remarks
ECU INPUT
SIGNALSMAIN SIG-
NALSSELEC-
TION FROM
MENU

AT-90
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
N POSI IND (ON/OFF) — —
D POSI IND (ON/OFF) — —
4TH POSI IND (ON/OFF) — —
3RD POSI IND (ON/OFF) — —
2ND POSI IND (ON/OFF) — —
1ST POSI IND (ON/OFF) — —
MANU MODE IND (ON/OFF) — —
POWER M LAMP (ON/OFF) — —
F-SAFE IND/L (ON/OFF) — —
ATF WARN LAMP (ON/OFF) — — Not mounted but displayed.
BACK-UP LAMP (ON/OFF) — —
STARTER RELAY (ON/OFF) — —
PNP SW3 MON (ON/OFF) — —
C/V CLB ID1 — —
C/V CLB ID2 — —
C/V CLB ID3 — —
UNIT CLB ID1 — —
UNIT CLB ID2 — —
UNIT CLB ID3 — —
TRGT GR RATIO — —
TRGT PRES TCC (kPa) — —
TRGT PRES L/P (kPa) — —
TRGT PRES I/C (kPa) — —
TRGT PRE FR/B (kPa) — —
TRGT PRES D/C (kPa) — —
TRG PRE HLR/C (kPa) — —
SHIFT PATTERN — —
DRV CST JUDGE — —
START RLY MON — —
NEXT GR POSI — —
SHIFT MODE — —
MANU GR POSI — —
VEHICLE SPEED (km/h) — X Vehicle speed recognized by the TCM.
Voltage (V) — —Displays the value measured by the voltage
probe. Monitored item (Unit)Monitor Item Selection
Remarks
ECU INPUT
SIGNALSMAIN SIG-
NALSSELEC-
TION FROM
MENU

TROUBLE DIAGNOSIS
AT-91
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
DTC WORK SUPPORT MODE
Display Items List
Frequency (Hz) — —
The value measured by the pulse probe is dis-
played. DUTY-HI (high) (%) — —
DUTY-LOW (low) (%) — —
PLS WIDTH-HI (ms) — —
PLS WIDTH-LOW (ms) — —Monitored item (Unit)Monitor Item Selection
Remarks
ECU INPUT
SIGNALSMAIN SIG-
NALSSELEC-
TION FROM
MENU
DTC work support item Description Check item
1ST GR FUNCTN P0731Following items for “1st gear function” can be confirmed.

Self-diagnosis status (whether the diagnosis is being performed or not)

Self-diagnostic results (OK or NG)

Input clutch solenoid
valve

Front brake solenoid
valve

Direct clutch solenoid
valve

High and low reverse
clutch solenoid valve

Each clutch

Hydraulic control circuit 2ND GR FUNCTN P0732Following items for “2nd gear function” can be confirmed.

Self-diagnosis status (whether the diagnosis is being performed or not)

Self-diagnostic results (OK or NG)
3RD GR FUNCTN P0733Following items for “3rd gear function” can be confirmed.

Self-diagnosis status (whether the diagnosis is being performed or not)

Self-diagnostic results (OK or NG)
4TH GR FUNCTN P0734Following items for “4th gear function” can be confirmed.

Self-diagnosis status (whether the diagnosis is being performed or not)

Self-diagnostic results (OK or NG)
5TH GR FUNCTN P0735Following items for “5th gear function” can be confirmed.

Self-diagnosis status (whether the diagnosis is being performed or not)

Self-diagnostic results (OK or NG)

AT-92
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
Diagnostic Procedure Without CONSULT-IIINCS0002F
OBD-II SELF-DIAGNOSTIC PROCEDURE (WITH GST)
Refer to EC-125, "Generic Scan Tool (GST) Function" .
OBD-II SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)
Refer to EC-62, "Malfunction Indicator Lamp (MIL)" .
TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)
Description
When the ignition switch is turned ON, the indicator lamp lights up 2 seconds. As a method for locating the
suspect circuit, when the self-diagnostics start signal is input, the memory for the malfunction location is output
and A/T CHECK indicator lamp flashes to display the corresponding DTC.
Diagnostic Procedure
1. CHECK A/T CHECK INDICATOR LAMP
1. Start the engine with selector lever in “P” position. Warm engine to normal operating temperature.
2. Turn ignition switch ON and OFF at least twice, then leave it in the OFF position.
3. Wait 10 seconds.
4. Turn ignition switch ON. (Do not start engine.)
Does A/T CHECK indicator lamp come on for about 2 seconds?
YES >> GO TO 2.
NO >> Go to AT- 1 7 2 , "
A/T Check Indicator Lamp Does Not Come On" .
2. JUDGMENT PROCEDURE
1. Turn ignition switch OFF.
2. Keep pressing shift lock release button.
3. Move selector lever from “P” to “D” position.
4. Release accelerator pedal. (Set the closed throttle position signal ON.)
5. Depress brake pedal. (Stop lamp switch signal ON.)
6. Turn ignition switch ON. (Do not start engine.)
7. Wait 3 seconds.
8. Move the selector lever to the manual shift gate side. (Manual mode switch ON.)
9. Release brake pedal. (Stop lamp switch signal OFF.)
10. Move the selector lever to “D” position. (Manual mode switch OFF.)
11. Depress brake pedal. (Stop lamp switch signal ON.)
12. Release brake pedal. (Stop lamp switch signal OFF.)
13. Depress accelerator pedal fully and release it.
>> GO TO 3.
3. CHECK SELF-DIAGNOSIS CODE
Check A/T CHECK indicator lamp. Refer to AT- 9 3 , "
Judgment Self-diagnosis Code" .
If the system does not go into self-diagnostics. Refer to AT- 1 0 2 , "
DTC P0705 PARK/NEUTRAL POSITION
SWITCH" , AT- 1 5 7 , "DTC P1815 MANUAL MODE SWITCH" , AT- 1 6 6 , "CLOSED THROTTLE POSITION AND
WIDE OPEN THROTTLE POSITION CIRCUIT" , AT- 1 6 7 , "BRAKE SIGNAL CIRCUIT" .
>>DIAGNOSIS END
