2007 MERCEDES-BENZ CLS63AMG Owner's Manual

448 Technical dataMain dimensions and weightsMain dimensionsWeightsModel
CLS 550
CLS 63 AMG
Overall vehicle length
193.3 in (4 910 mm)
193.5 in (4 915 mm)
Overall vehicle width (exterior rear view
mirrors folded out)
81.1 in (2 059 )
81.1 in (2 059 mm)
Overall vehicle height
55.7 in (1 414 mm)
54.5 in (1 389 mm)
Wheelbase
112.4 in (2 854 mm)
112.4 in (2 854 mm)
Track, front
62.5 in (1 587 mm)
63 in (1 599 mm)
Track, rear
61.8 in (1 570 mm)
62.3 in (1 583 mm)
Roof load max.
220 lb (100 kg)
Trunk load max.
220 lb (100 kg)

449 Technical data
Fuels, coolants, lubricants etc.
Fuels, coolants, lubricants etc.
Capacities
Vehicle components and their respective
lubricants must match. Therefore only use
products tested and approved by
Mercedes-Benz.
Please refer to the Factory Approved
Service Products pamphlet (USA only), or
inquire at an authorized Mercedes-Benz
Center.
Warning!
G
Comply with all valid regulations with re-
spect to handling, storing and disposing of
service fluids. Otherwise you could endan-
ger persons or the environment.
Keep service fluids out of the reach of chil-
dren.
For health reasons, you should prevent ser-
vice fluids from coming into direct contact
with your skin or clothing.
If a service fluid is swallowed, contact a phy-
sician immediately.
Model
Capacity
Fuels, coolants, lubricants etc.
Engine with oil filter
CLS 550
9.0 US qt (8.5 l)
Approved engine oils
Engine with oil filter including
oil cooler
CLS 63 AMG
9.3 US qt (8.8 l)
Approved engine oils
Automatic transmission
CLS 550
9.7 US qt (9.2 l)
MB Automatic Transmission Fluid
CLS 63 AMG
9.0 US qt (8.5 l)
Rear axle
CLS 550
1.37 US qt (1.3 l)
Hypoid gear oil SAE 85 W 90
CLS 63 AMG
1.27 US qt (1.2 l)

450 Technical dataFuels, coolants, lubricants etc.
Model
Capacity
Fuels, coolants, lubricants etc.
Power steering
CLS 550
approx. 1.0 US qt (0.9 l)
MB Power Steering Fluid (Pentosin CHF 11S
or, depending on vehicle production date,
Chevron Texaco PSF 9109)
1
1For detailed information, please refer to the Factory Approved Service Products pamphlet (USA only) or contact an authorized Mercedes-Benz Center.
CLS 63 AMG
approx. 1.3 US qt (1.2 l)
Front wheel hubs
CLS 550
approx. 3.0 oz (85 g) each
High temperature roller bearing grease
CLS 63 AMG
approx. 3.2 oz (90 g) each
Brake system
All models
0.63 US qt (0.6 l)
MB Brake Fluid (DOT 4+)
Cooling system
CLS 550
11.9 US qt (11.3 l)
MB 325.0 Anticorrosion/Antifreeze
CLS 63 AMG
12.5 US qt (11.8 l)
Fuel tank
All models
21.12 US gal (80.0 l)
Premium unleaded gasoline
Minimum Posted Octane 91
(Avg. of 96 RON/86 MON)
including a reserve of
CLS 550
2.38 US gal (9.0 l)
CLS 63 AMG
3.7 US gal (14.0 l)
Air conditioning system
All models
R-134a refrigerant and special PAG lubricant
oil (never R-12)
Windshield washer system
All models
4.8 US qt (4.5 l)
MB Windshield Washer Concentrate
2
2Use MB Windshield Washer Concentrate “MB SummerFit” and water for temperatures above freezing or MB Windshield Washer Concentrate “MB SummerFit” and
commercially available premixed windshield washer solvent/antifreeze for temperatures below freezing point. Follow suggested mixing ratios (page 456).Windshield washer and head-
lamp cleaning* system
All models
6.9 US qt (6.5 l)

451 Technical data
Fuels, coolants, lubricants etc.
Engine oils
Engine oils are specifically tested for their
suitability in our engines and durability for
our service intervals. Therefore, only use
approved engine oils and oil filters re-
quired for vehicles with Maintenance Sys-
tem (U.S. vehicles) or FSS PLUS (Canada
vehicles). For a listing of approved engine
oils and oil filters, refer to the Factory Ap-
proved Service Products pamphlet (USA
only), or contact an authorized
Mercedes-Benz Center.
Engine oil additivesAir conditioning refrigerant
R-134a (HFC) refrigerant and special PAG
lubricating oil are used in the air condition-
ing system.
Brake fluid
Only brake fluid approved by
Mercedes-Benz is recommended. Your
authorized Mercedes-Benz Center will pro-
vide you with additional information.
!
Using engine oils and oil filters of specifica-
tion other than those expressly required for the
Maintenance System (U.S. vehicles) or
FSS PLUS (Canada vehicles), or changing of oil
and oil filter at change intervals longer than
those called for by the Maintenance System
(U.S. vehicles) or FSS PLUS (Canada vehicles)
will result in engine or emission control system
damage not covered by the Mercedes-Benz Lim-
ited Warranty.Please follow Maintenance System (U.S. vehi-
cles) or FSS PLUS (Canada vehicles) recommen-
dations for scheduled oil changes. Failure to do
so could result in engine or emission control sys-
tem damage not covered by the Mercedes-Benz
Limited Warranty.
!
Do not blend oil additives with engine oil.
They may damage the engine.
Damage or malfunctions resulting from blending
oil additives are not covered by the
Mercedes-Benz Limited Warranty.
!
Never use R-12 (CFC) or mineral-based lu-
bricating oil. Otherwise damage to the system
will occur.
Warning!
G
During vehicle operation, the boiling point of
the brake fluid is continuously reduced
through the absorption of moisture from the
atmosphere. Under extremely strenuous op-
erating conditions, this moisture content
can lead to the formation of bubbles in the
system, thus reducing the system’s efficien-
cy.
Therefore, the brake fluid must be replaced
regularly. Refer to your vehicle’s Mainte-
nance Booklet for replacement interval.

452 Technical dataFuels, coolants, lubricants etc.Premium unleaded gasoline
Fuel requirements
Only use premium unleaded fuel:
The octane number (posted at the pump)
m u s t b e 9 1 m i n . I t i s a n a v e r a g e o f b o t h t h e
Research Octane Number (RON) and the
Motor Octane Number (MON):
(RON+MON)/2. This is also known as the
ANTI-KNOCK INDEX.
Unleaded gasoline containing oxygenates
such as ethanol, IPA, IBA and TBA can be
used provided the ratio of any one of these
oxygenates to gasoline does not exceed
10%; MTBE must not exceed 15%.
The ratio of methanol to gasoline must not
exceed 3% plus additional cosolvents.
Using mixtures of ethanol and methanol is
not allowed. Gasohol, which contains 10%
ethanol and 90% unleaded gasoline, can be
used.
These blends must also meet all other fuel
requirements, such as resistance to spark
knock, boiling range, vapor pressure, etc.
Warning!
G
Gasoline is highly flammable and poisonous.
It burns violently and can cause serious per-
sonal injury.
Never allow sparks, flame or smoking mate-
rials near gasoline!
Turn off the engine before refueling.
Whenever you are around gasoline, avoid in-
haling fumes and skin or clothing contact,
extinguish all smoking materials.
Direct skin contact with fuels and the inha-
lation of fuel vapors can damage your
health.
!
To maintain the engine’s durability and per-
formance, premium unleaded gasoline must be
used. If premium unleaded gasoline is not avail-
able and low octane fuel is used, follow these
precautions:


Have the fuel tank only partially filled with
unleaded regular gasoline and fill up with
premium unleaded gasoline as soon as pos-
sible.


Avoid full throttle driving and abrupt acceler-
ation


Do not exceed an engine speed of 3000 rpm
if the vehicle is loaded with a light load such
as two persons and no luggage.


Do not exceed
2/3 of maximum accelerator
pedal position if the vehicle is fully loaded or
operating in mountainous terrain.

453 Technical data
Fuels, coolants, lubricants etc.
Gasoline additives
A major concern among engine manufac-
turers is carbon build-up caused by gaso-
line. Mercedes-Benz recommends only the
use of quality gasoline containing additives
that prevent the build-up of carbon depos-
its.
After an extended period of using fuels
without such additives, carbon deposits
can build up especially on the intake valves
and in the combustion area, leading to
engine performance problems such as:

Warm-up hesitation


Unstable idle


Knocking/pinging


Misfire


Power lossIn areas where carbon deposits may be
encountered due to lack of availability of
gasolines which contain these additives,
Mercedes-Benz recommends the use of
additives approved by us for use on
Mercedes-Benz vehicles. Refer to Factory
Approved Service Products Pamphlet (USA
only) or contact an authorized
Mercedes-Benz Center for a listing of ap-
proved product(s). Follow directions on
product label.
Do not blend other fuel additives with fuel.
This only results in unnecessary costs and
may be harmful to the engine operation.
Coolants
The engine coolant is a mixture of water
and anticorrosion/antifreeze, which pro-
vides:

Corrosion protection


Freeze protection


Boiling protection (by increasing the
boiling point)
The cooling system was filled at the factory
with a coolant providing freeze protection
to approximately -22°F (-30°C) and corro-
sion protection.
!
Damage or malfunction resulting from poor
fuel quality or from blending additional fuel addi-
tives other than those tested and approved by us
for use on Mercedes-Benz vehicles listed in the
Factory Approved Service Products pamphlet
are not covered by the Mercedes-Benz Limited
Warranty.
For a listing of approved products, refer to the
Factory Approved Service Products pamphlet
(USA only) or contact an authorized
Mercedes-Benz Center.
!
Add premixed coolant solution only. Adding
water and MB 325.0 Anticorrosion/Antifreeze
separately from each other, could cause engine
damage not covered by the Mercedes-Benz Lim-
ited Warranty.

454 Technical dataFuels, coolants, lubricants etc.If the antifreeze mixture is effective to
-22°F (-30°C), the boiling point of the cool-
ant in the pressurized cooling system is
reached at approximately 266°F (130°C).
The coolant solution must be used year
round to provide the necessary corrosion
protection and increase boil-over protec-
tion. Refer to Maintenance Booklet for re-
placement interval.
Coolant system design and coolant used
determine the replacement interval. The
replacement interval published in the
Maintenance Booklet is only applicable if
MB 325.0 Anticorrosion/Antifreeze solu-
tion or other Mercedes-Benz approved
products of equal specification (see
Factory Approved Service Products pam-
phlet) are used to renew the coolant con-
centration or bring it back up to the proper
level.For information on other Mercedes-Benz
approved products of equal specification,
refer to the Factory Approved Service
Products pamphlet (USA only) or contact
an authorized Mercedes-Benz Center.
To provide important corrosion protection,
the solution must be at least 50% anticor-
rosion/antifreeze (equivalent to freeze
protection to approximately -35°F
[-30°C]). If you use a solution that is more
than 55% anticorrosion/antifreeze (freeze
protection to approximately -49°F
[-45°C]), the engine temperature will in-
crease due to the lower heat transfer capa-
bility of the solution. Therefore, do not use
more than this amount of anticorro-
sion/antifreeze.If the coolant level is low, water and
MB 325.0 Anticorrosion/Antifreeze
should be used to bring it up to the proper
level (have cooling system checked for
signs of leakage). Please make sure the
mixture is in accordance with label instruc-
tions.
The water in the cooling system must meet
minimum requirements, which are usually
satisfied by normal drinking water. If you
are not sure about the water quality, con-
sult an authorized Mercedes-Benz Center.

455 Technical data
Fuels, coolants, lubricants etc.
Anticorrosion/antifreeze
Your vehicle contains a number of alumi-
num parts. The use of aluminum compo-
nents in motor vehicle engines
necessitates that anticorrosion/antifreeze
coolant used in such engines be specifical-
ly formulated to protect the aluminum parts. Failure to use such anticorro-
sion/antifreeze coolant will result in a sig-
nificantly shortened service life.
Therefore, the following product is strongly
recommended for use in your vehicle:
MB 325.0 Anticorrosion/Antifreeze agent.Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to your authorized Mercedes-Benz
Center for service.
Anticorrosion/antifreeze quantityModel
Approx. freeze protection-35°F (-37°C)
-49°F (-45°C)
CLS 550
6.0 US qt (5.7 l)
6.6 US qt (6.2 l)
CLS 63 AMG
6.2 US qt (5.9 l)
6.9 US qt (6.5 l)
