2007 MERCEDES-BENZ CLS63AMG Owner's Manual

104 Controls in detailLocking and unlockingGlobal unlocking
Press buttonŒ.

All turn signal lamps flash once.


An acoustic signal sounds once.


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.
The vehicle will lock again automatically
and rearm the anti-theft alarm system
within approximately 40 seconds of un-
locking if:


neither door nor trunk is opened


the SmartKey is not inserted in the
starter switch


the central locking switch is not
activatedGlobal locking

Press button‹.
With the trunk and all doors closed:

All turn signal lamps flash three
times.


An acoustic signal sounds three
times.


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.
Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey so that press-
ing buttonŒ only unlocks the driver’s
door, the storage compartment under the
armrest, the glove box, and the fuel filler
flap.

Press and hold buttonsŒand‹
simultaneously for about 5 seconds un-
til battery check lamp5 flashes twice.The SmartKey will then function as
follows:
Unlocking driver’s door and fuel filler
flap

Press buttonΠonce.

All turn signal lamps flash once.


An acoustic signal sounds once.


The locking knob on the driver’s
door move up.


The anti-theft alarm system is dis-
armed.
Global unlocking

Press buttonΠtwice.

All turn signal lamps flash once.


An acoustic signal sounds once.


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.

105 Controls in detail
Locking and unlocking
Global locking
Press button‹.
With the trunk and all doors closed:

All turn signal lamps flash three
times.


An acoustic signal sounds three
times.


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.
Restoring to factory setting

Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 flashes twice.
SmartKey with KEYLESS-GO*
Vehicles equipped with KEYLESS-GO come
with two SmartKeys with KEYLESS-GO,
each with remote control and a removable
mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys with
KEYLESS-GO are a different color to help
distinguish each SmartKey with
KEYLESS-GO unit.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked every time you pull an outside
door handle.
If the SmartKey with KEYLESS-GO is valid,
your vehicle unlocks

the doors


the trunk


the fuel filler flap
SmartKey with KEYLESS-GO 1‹ Lock button
2Š Opening button for trunk
(
page 112)
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 90)
!
To prevent possible malfunction, avoid ex-
posing the SmartKey with KEYLESS-GO to high
levels of electromagnetic radiation.

106 Controls in detailLocking and unlockingWarning!
G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. It is possible for children
to open a locked door from the inside, which
could result in an accident and/or serious
personal injury.i
When you open a door, the side window on
that side lowers slightly. Once you close the
door, the window moves up again.
!
The side windows will not open or close if
the battery is discharged or the windows are cov-
ered with ice. As a result, you may no longer be
able to properly close the door. Do not attempt
to force the door shut. Doing so may damage the
door or the side window. Correct the condition
that prevents the windows from operating before
attempting to close the door.
i
USA only:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
Canada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
You can also open and close the windows
and tilt/sliding sunroof or tilt/sliding panel* us-
ing the SmartKey with KEYLESS-GO
(
page 210).
!
If you can no longer lock or unlock the vehi-
cle with the SmartKey with KEYLESS-GO, then
the batteries in the SmartKey are discharged,
the SmartKey with KEYLESS-GO is malfunction-
ing or the vehicle battery is drained.


Check the batteries in the SmartKey with
KEYLESS-GO (
page 105) and replace
them if necessary (page 402).


Use the mechanical key to unlock the driv-
er’s door (
page 396) and the trunk
(
page 397).


Have the vehicle battery checked by an au-
thorized Mercedes-Benz Center.
If the SmartKey with KEYLESS-GO is malfunc-
tioning, contact an authorized Mercedes-Benz
Center.

107 Controls in detail
Locking and unlocking
Important notes on using KEYLESS-GO

You can also use the SmartKey with
KEYLESS-GO like a normal SmartKey
(page 102).


You can combine KEYLESS-GO func-
tions with normal SmartKey functions
(e.g. unlocking with KEYLESS-GO and
locking with button ‹).


Always carry the SmartKey with
KEYLESS-GO with you.


Never store the SmartKey with
KEYLESS-GO together with:

Electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO


Metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.


To lock or unlock the vehicle, the
SmartKey with KEYLESS-GO must be
located outside the vehicle within ap-
proximately 3 ft (1 m) of a door or the
trunk lid.


In order to start the engine with the
SmartKey with KEYLESS-GO:

The SmartKey with KEYLESS-GO
must be located in the vehicle.


The brake pedal must be firmly de-
pressed. Do not depress the accel-
erator.


If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle, the system may no longer recog-
nize the SmartKey with KEYLESS-GO.
The vehicle cannot be locked or the
engine started via the KEYLESS-GO
system.


If the SmartKey with KEYLESS-GO is re-
moved from the vehicle (e.g. if passen-
ger exits the vehicle with the SmartKey
with KEYLESS-GO)


when pressing the KEYLESS-GO
start/stop button or trying to lock
the vehicle with the outside door
handle the message
Key not rec-
ognized
appears in the multifunc-
tion display


with the engine running, the mes-
sage
Key not recognized
appears
in the multifunction display while
driving off.
Find the SmartKey with KEYLESS-GO or
change its present location immediate-
ly (e.g. place it on the front passenger
seat or insert it in shirt pocket).


If you have started the engine with the
KEYLESS-GO start/stop button, you
can turn it off again with:

the KEYLESS-GO start/stop button


the SmartKey with KEYLESS-GO in-
serted in the starter switch, when
the automatic transmission is in
positionP

108 Controls in detailLocking and unlocking

Remember that the engine can be
started by anyone with a SmartKey
with KEYLESS-GO that is left inside the
vehicle.
Possibility 1: (One SmartKey with
KEYLESS-GO in the vehicle, one
SmartKey with KEYLESS-GO outside
the vehicle):
If you leave the SmartKey with
KEYLESS-GO behind when exiting and
locking the vehicle, no message
appears in the multifunction display.
Possibility 2: (One SmartKey with
KEYLESS-GO in the vehicle, no
SmartKey with KEYLESS-GO outside
the vehicle):
When exiting and trying to lock the ve-
hicle, the message
Key still in ve-
hicle
appears in the multifunction
display. The vehicle will not be locked.Factory setting
Global unlocking

Pull an outside door handle.

All turn signal lamps flash once.


An acoustic signal sounds once.


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.
The vehicle will lock again automatically
and rearm the anti-theft alarm system
within approximately 40 seconds if:


neither a door nor the trunk is opened


the central locking switch is not acti-
vatedGlobal locking

Press lock button on an outside door
handle (
page 62).
With the trunk and all doors closed:


All turn signal lamps flash three
times.


An acoustic signal sounds three
times.


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.
i
When unlocking or locking the vehicle with
the SmartKey or with the KEYLESS-GO function
an acoustic signal sounds. The acoustic signal is
activated at the factory. If you wish to deactivate
the feature, or adjust its signal volume, contact
an authorized Mercedes-Benz Center.

109 Controls in detail
Locking and unlocking
Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey with
KEYLESS-GO so when you pull the driver’s
outside door handle, only the driver’s door
and the fuel filler flap unlocks.
Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 105)
flashes twice.
The SmartKey with KEYLESS-GO will
then function as follows:
Unlocking driver’s door and fuel filler
flap

Pull the driver’s outside door handle.

All turn signal lamps flash once.


An acoustic signal sounds once.


The locking knob in the driver’s
door moves up.


The anti-theft alarm system is dis-
armed.Global unlocking

Pull any outside door handle other than
the driver’s outside door handle.

All turn signal lamps flash once.


An acoustic signal sounds once.


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.
Global locking

Press lock button on an outside door
handle (
page 62).
With the trunk and all doors closed:


All turn signal lamps flash three
times.


An acoustic signal sounds three
times.


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.Restoring to factory setting

Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 105)
flashes twice.
Global locking using the KEYLESS-GO*
lock button on the trunk lid*
Depending on production date, your vehi-
cle may be equipped with the KEYLESS-GO
lock button on trunk lid.
1Lock button on trunk lid

110 Controls in detailLocking and unlocking
Press lock button1 on the trunk lid.
With the trunk and all doors closed:

All turn signal lamps flash three
times.


An acoustic signal sounds three
times.


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.Checking batteries in the SmartKey or
SmartKey with KEYLESS-GO*
Press button‹ orŒ.
The battery check lamp (
page 102)
or (
page 105) comes on briefly to in-
dicate that the SmartKey or SmartKey
with KEYLESS-GO batteries are in or-
der.L o s s o f t h e S m a r t K e y o r S m a r t K e y w i t h
KEYLESS-GO*
If you lose your SmartKey, SmartKey with
KEYLESS-GO or mechanical key, you
should do the following:
Have the SmartKey or SmartKey with
KEYLESS-GO deactivated by an autho-
rized Mercedes-Benz Center.

Report the loss of the SmartKey,
SmartKey with KEYLESS-GO or the me-
chanical key immediately to your car
insurance company.

Have the mechanical lock replaced if
necessary.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
i
To prevent a possible inadvertent lockout,
the trunk will open automatically if a SmartKey
with KEYLESS-GO is recognized inside the vehi-
cle or in the trunk.
i
You can also lock the vehicle using the lock
button on an outside door handle (
page 62) or,
vehicles with trunk opening/closing system*,
KEYLESS-GO locking/ closing switch
(
page 116).
!
If the battery check lamp does not come on
briefly during check, the SmartKey or SmartKey
with KEYLESS-GO batteries are discharged.
Replace the batteries (
page 402).
You can obtain the required batteries at any au-
thorized Mercedes-Benz Center.
i
If the batteries are checked within signal
range of the vehicle, pressing button‹ or
Πwill lock or unlock the vehicle accordingly.

111 Controls in detail
Locking and unlocking
Opening the doors from the inside
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
1Locking knob
2Inside door handleFront doors

Pull on door handle2 on the respec-
tive front door to open door.
If door was locked, locking knob1 will
move up.
Rear doors

Pull up locking knob1 on the
respective rear door to unlock door.

Pull on door handle2 on the
respective rear door to open door.
i
If the vehicle has previously been locked
with the SmartKey or KEYLESS-GO*, opening a
door from the inside will trigger the anti-theft
alarm system.
To cancel the alarm, do one of the following:


Press button Œ or ‹ on the SmartKey
or SmartKey with KEYLESS-GO*.


Insert the SmartKey or SmartKey with
KEYLESS-GO* in the starter switch.
In vehicles with KEYLESS-GO*


Press the KEYLESS-GO* start/stop button
(page 39).
The SmartKey with KEYLESS-GO* must be
inside the vehicle.


Pull an outside door handle.
The SmartKey with KEYLESS-GO* must be
within 3 ft (1 m) of the vehicle.
i
When you open a door, the side window on
that side lowers slightly. Once you close the
door, the window moves up again.
i
If you hear a warning signal you have forgot-
ten to switch off the headlamps before opening
the driver’s door.
In addition the message
Switch off lights
appears in the multifunction display.
Switch off the headlamps.
