2007 MERCEDES-BENZ CL-CLASS Owners Manual

638 Practical hints
Opening/closing in an emergency
Power tilt/sliding sunroof
You can open or close the tilt/sliding sun-
roof manually should an electrical malfunc-
tion occur.
The drive mechanism is behind the left sun
visor.
1Cover
Remove cover1.2Crank
Take crank2 from the Operator’s
Manual pouch.
Switch on the ignition (page 336).
Insert crank2 through the hole.
Turn crank2 clockwise to:

slide roof panel closed

raise roof panel at the rear
Turn crank2 counterclockwise to:

slide roof panel open

lower roof panel at the rear
iTurn crank2 slowly and smoothly.
The tilt/sliding sunroof (
page 468) must be
synchronized after being operated manually.
ProCarManuals.com

639 Practical hints
Replacing SmartKey batteries
Replacing SmartKey batteries
If the batteries in the SmartKey/SmartKey
with KEYLESS-GO* are discharged, the ve-
hicle can no longer be locked or unlocked.
It is recommended to have the batteries re-
placed at an authorized Mercedes-Benz
Center.Batteries contain materials that can harm
the environment if disposed of improperly.
Recycling of batteries is the preferred
method of disposal. Many states require
sellers of batteries to accept old batteries
for recycling.SmartKey/SmartKey with
KEYLESS-GO*
Replacement batteries: Lithium, type
CR 2025 or equivalent.
Remove the mechanical key out of the
SmartKey/SmartKey with
KEYLESS-GO* (
page 635).
1Mechanical key
2Battery compartment
Insert mechanical key 1 into opening.
Press mechanical key 1 in direction of
arrow.
The battery compartment is unlatched.
Warning!G
Batteries contain poisonous and corrosive
substances. Therefore keep the batteries
out of reach of children.
If a battery is swallowed, seek medical help
immediately.
iWhen inserting the batteries, make sure
they are clean and free of lint.
iWhen changing batteries, always replace
both batteries.
The required replacement batteries are available
at any authorized Mercedes-Benz Center.

ProCarManuals.com

640 Practical hints
Replacing SmartKey batteries
Pull battery compartment 2 out of the
housing.
3Batteries
4Contact springs
Pull out batteries3.
Using a line-free cloth, insert new bat-
teries 3 under contact springs 4 with
the positive terminal (+) side facing up.
Return battery compartment 2
(
page 639) into housing until it locks
into place.
Slide the mechanical key back into the
SmartKey/SmartKey with
KEYLESS-GO*.
Check the operation of the SmartKey/
SmartKey with KEYLESS-GO*.

ProCarManuals.com

641 Practical hints
Replacing bulbs
Replacing bulbs
Safe vehicle operation depends on proper
exterior lighting and signaling. It is there-
fore essential that all bulbs and lamp as-
semblies are in good working order at all
times.
Correct headlamp adjustment is extremely
important. Have headlamps checked and
readjusted at regular intervals and when a
bulb has been replaced. See an authorized
Mercedes-Benz Center for headlamp ad-
justment.iIf the headlamps or front fog lamps are
fogged up on the inside as a result of high humid-
ity, driving the vehicle a distance with the lights
on should clear up the fogging.iSubstitute bulbs will be brought into use
when the following lamps malfunction:

Brake lamps

Rear fog lamps

Front parking lamps

Tail lamps

Turn signal lamps
Read and observe messages in the multifunction
display (
page 580).
ProCarManuals.com

642 Practical hints
Replacing bulbs
Bulbs Front lamps Rear lamps
LampType
1Low and high beam
lamp1
1Bi-Xenon headlamps: Low beam and high beam
use the same D1S-35W lamp. Do not replace the
Bi-Xenon bulbs yourself. Contact an authorized
Mercedes-Benz Center.
D1S-35 W
2Additional turn signal
lampLED
3Parking and standing
lampW5W
4Side marker lampW5W
5High beam flasher lampH7-55 W
IR emitter* (for Night
View Assist*)H11-55 W
6Corner-illuminating
lampH7-55 W
7Fog lampH11-55 W
8Turn signal lampPY 24 W
LampType
9High mounted brake
lampLED
aTurn signal lampHiP 16 W
bBrake lamp/tail lamp
and standing lampLED
cLicense plate lampW5W
dBackup lampHiP 16 W
eSide marker lampLED
fRear fog lamp (driver’s
side only)HiP 19 W
ProCarManuals.com

643 Practical hints
Replacing bulbs
Notes on bulb replacement
Only use 12-volt-bulbs of the same
type and with the specified watt rating.

Switch lights off before changing a bulb
to prevent short circuits.

Always use a clean lint-free cloth when
handling bulbs.

Your hands should be dry and free of oil
and grease.

If the newly installed bulb does not
come on, contact an authorized
Mercedes-Benz Center.
Have the LEDs and bulbs for the following
lamps replaced by an authorized
Mercedes-Benz Center:

the Bi-Xenon lamps

the front turn signal lamps

the front fog lamps

the additional turn signal lamps in the
exterior rear view mirrors

the parking and standing lamps

the front side marker lamps

the high mounted brake lamps

the brake, tail and rear standing lamps

the rear side marker lamps

the rear fog lamp

the rear turn signal lamps

the rear side marker lamps

the license plate lamps
Warning!G
Bulbs and bulb sockets can be very hot. Al-
low the lamp to cool down before changing
a bulb.
Keep bulbs out of reach of children.
Halogen lamps contain pressurized gas. A
bulb can explode if you:

touch or move it when hot

drop the bulb

scratch the bulb
Wear eye and hand protection.
Because of high voltage in Xenon lamps, it is
dangerous to replace the bulb or repair the
lamp and its components. We recommend
that you have such work done by a qualified
technician.
!Do not replace the LEDs yourself. You could
otherwise damage the LEDs or parts of the vehi-
cle. Only have the LEDs replaced by an autho-
rized Mercedes-Benz Center.
iHave the headlamp adjustment checked
regularly.
ProCarManuals.com

644 Practical hints
Replacing bulbs
Replacing bulbs for front lamps
You can only change the halogen bulbs for,
high-beam flasher lamp, corner-illuminat-
ing lamp, and IR emitter* lamp.
Before you start to replace a bulb for a
front lamp, do the following first:
Turn the exterior lamp switch to M
(
page 363).
Open the hood (page 512) (except
for side marker lamps).
Headlamp, left
1Cover
2Tab
Removing cover: Pull cover1 on
tab2 in direction of arrow and re-
move cover1.
Bi-Xenon headlampsHigh beam flasher lamp
Headlamp, left
1Installation device
Pull installation device1 up (left
headlamp) or down (right headlamp)
and remove the bulb together with
installation device1 from the head-
lamp.
Warning!G
Do not remove the cover for the Bi-Xenon
headlamp. Because of high voltage in Xenon
lamps, it is dangerous to replace the bulb or
repair the lamp and its components. We rec-
o mme nd th at y ou ha ve s uc h w o rk do n e b y a
qualified technician.
ProCarManuals.com

645 Practical hints
Replacing bulbs
1Installation device
2Bulb
Pull bulb2 out of the socket.
Insert new bulb2 into the socket.
Insert installation device1 into the
headlamp so that the handle of the in-
stallation device points up (left head-
lamp) or down (right headlamp).
Pull installation device1 down (left
headlamp) or up (right headlamp) until
it engages.
Attach cover (page 644) and let it au-
dibly engage to close.
Corner-illuminating lamp
1Bulb holder
2Wire position
Turn bulb holder1 counterclockwise
until it disengages.
Take out bulb holder1.
Take bulb out of holder.
Insert new bulb into holder and press it
all the way down.
Insert bulb holder1 into guide in
headlamp.
The tab of the bulb holder must be po-
sitioned on the upper left-hand side
and wire2 must point downward and
to the left for the left headlamp, up-
ward and to the right for the right head-
lamp.
Turn bulb holder1 clockwise until it
engages.
iMake sure to insert the bulb in the right di-
rection. The bulb must fit plane on the socket.
