501
6-1. Specifications
6
Vehicle specifications
Lubrication system
*: 5W-30 is an oil that provides optimal levels of fuel efficiency.
Oil viscosity:
● The 5W por
tion of the oil viscosity rating indicates the characteristic of
the oil which allows cold startability . Oils with a lower value before the W
allow for easier starting of the engine in cold weather.
● The 30 in 5W-30 indicates the oil viscosity when the oil is as its operating
temperature. An oil with a higher viscosity may be better suited if the
vehicle is operated at high speeds, or under extreme load condition.
GS430GS350 (2WD)GS350 (4 WD)
Oil capacity 
(drain and refill)
with filter
without filter5.4 qt. (5.1 L, 4.5
lmp.qt.)
4.8 qt. (4.5 L,
4.0 lmp.qt.)6.6 qt. (6.3 L, 5.5
lmp.qt.)
6.2 qt. (5.9 L, 5.2
lmp.qt.)6.7 qt. (6.4 L, 5.6
lmp.qt.)
6.3 qt. (6.0 L,
5.3 lmp.qt.)
Oil gradeILSAC multigrade engine oil
Recommended oil 
viscosity
Use Lexus approved “Toyota Genuine Motor Oil” or
equivalent to satisfy the above grade and viscosity.
Outside temperature

502
6-1. Specifications
Cooling system
Ignition system
GS430GS350
Capacity10.7 qt. 
(10.1 L, 8.9 lmp.qt.)9.6 q t . 
(9.1 L, 8.0 lmp.qt.)
Coolant type
Use either of the following: • “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-sili-cate, non-amine, non-nitrite, and non-borate cool-
ant with long-life hybrid organic acid technology
Do not use plain water alone.
GS430GS350
Spark plug
Make DENSO 
NGK
SK20R11
IFR6A11FK20HBR11 
ILFR6D11T
Gap0.043 in. (1.1 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine.

503
6-1. Specifications
6
Vehicle specifications
Electrical system
Differential
Battery
Open voltage at
68F (20 C):12.6  12.8V Fully charged 
12.2  12.4V Half charged 
11.8  12.0V Discharged 
(Voltage is checked 20 minutes after
the engine and all lights are turned off.)
Charging rates5A max.
GS430GS350 (2WD)GS350 (4WD)
Oil capacity1.42 qt. 
(1.35 L, 1.19 lmp.qt.)1.42 qt. 
(1.35 L, 1.19 lmp.qt.)
Front: 0.73 qt. 
(0.70 L, 0.61 lmp.qt.)
Rear: 1.42 qt. 
(1.35 L, 1.19 lmp.qt.)
Oil type and
viscosityToyota Genuine Synthetic Differential Gear Oil
API GL-5 SAE 75W-85

504
6-1. Specifications
Transmission
Brakes
*1: Minimum pedal clearance when depressed with a force of 200 N (20.4 kgf, 45 lbf) while the engine is running.
*2: Minimum pedal clearance when depressed with a force of 490 N (50.0 kgf, 110 lbf) while the engine is running.
*3: Parking brake pedal travel when depressed with a force of 300 N (30.6 kgf, 67.4 lbf).
GS430GS350 (2WD)GS350 (4 WD)
Fluid capacity
Drain and refill1.8 qt. 
(1.7 L, 1.5 lmp.qt.)1.9 qt. 
(1.8 L, 1.5 lmp.qt.)2.9 qt. 
(2.8 L, 2.4 lmp.qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
■Transmission fluid type
Using transmission fluid other than “T oyota Genuine ATF WS” may cause deterio-
ration in shift quality, locking up of your transmission accompanied by vibration, and
ultimately damage the transmission of your vehicle.
Pe d a l c l e a r a n c e
GS430
*1
GS350 *2
2.9 in. (74 mm) Min.
2.6 in. (65 mm) Min.
Pedal free playLess than 0.04 0.04  0.08 in. (1.0  2.0 mm)
Brake pad wear limit0.04 in. (1.0 mm)
Parking brake pedal travel *35  7 clicks
Parking brake lining wear limit0.04 in. (1.0 mm)
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3

505
6-1. Specifications
6
Vehicle specifications
Steering
Tires and wheels
Type A
Free playLess than 1.2 in. (30 mm)
Ti r e s i z e245/40R18 93Y, P245/40R18 93V, T155/
70D17 110M (spare)
Front and rear tire inflation 
pressure
(Recommended cold tire inflation
pressure)
Driving under normal conditions33 psi (230 kPa, 2.3 kgf/cm2 or bar)
Driving at high speeds above 100 mph
(160km/h) (in countries where such speeds
are permitted by law) Add 9 psi (60 kPa, 0.6 kgf/cm
2 or bar) to
the front tires and rear tires. Never exceed
the maximum cold tire inflation pressure
indicated on the tire sidewall.
Spare tire inflation pressure 
(Recommended cold tire inflation
pressure)
60 psi (420 kPa, 4.2 kgf/cm2 or bar)
Wheel size18  8 JJ, 17  4T (spare)
Wheel nut torque76 ft•lbf (103 N•m, 10.5 kgf•m)

506
6-1. Specifications
Ty p e B
Ti r e s i z e225/50R17 94W, P225/50R17 93V, T155/
70D17 110M (spare)
Front and rear tire inflation 
pressure
(Recommended cold tire inflation
pressure)
Driving under normal conditions 33 psi (230 kPa, 2.3 kgf/cm2 or bar)
Driving at high speeds above 100 mph
(160km/h) (in countries where such speeds
are permitted by law) Add 7 psi (50 kPa, 0.5 kgf/cm
2 or bar) to
the front tires and rear tires. Never exceed
the maximum cold tire inflation pressure
indicated on the tire sidewall.
Spare tire inflation pressure 
(Recommended cold tire inflation
pressure)
60 psi (420 kPa, 4.2 kgf/cm2 or bar,)
Wheel size17  7 1 /2 JJ, 17  4T (spare)
Wheel nut torque76 ft•lbf (103 N•m, 10.5 kgf•m)

507
6-1. Specifications
6
Vehicle specifications
Light bulbs
A: D4S high-intensity discharge bulbs
B: HB3 halogen bulbs 
C: Wedge base bulbs (amber) 
D: Wedge base bulbs (clear) 
E: HB4 halogen bulbs 
F: Double end bulbs
Light BulbsBulb No.WTy p e
Exterior
Headlights (low beam)D4S35A
Headlights (high beam)HB360B
Front turn signal lights21C
Parking lights5D
Fog lightsHB451E
Front side marker light1945D
Rear turn signal lights21C
Back-up lights92116D
Trunk light5F
InteriorVanity lights8D

508
6-1. Specifications
Fuel information
■Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your Lexus has a fuel tank opening that only
ac
commodates the special nozzle on unleaded fuel pumps.
■If premium gasoline is not available
If 91 Octane cannot be obtained, you ma y use unleaded gasolin
e with an Octane
Rating as low as 87 (Research Octane Number 91). 
However, use of unleaded fuel with an Octane Rating lower than 91 may result in
engine knocking (G
S350 only: or drasticall y reduce output to protect itself while
driving with heavy load). Persistent kn ocking can lead to engine damage and
should be corrected by refueling with higher octane unleaded gasoline.
■If your engine knocks
●Consult your Lexus dealer.
●You may occasionally notice light knocking for a short time while accelerating
or driving uphill. This is normal and there is no need for concern.
■Gasoline quality
In very few cases, driveability problems may be caused by the brand of gasoline you
ar
e using. If driveability problems persist, try changing the brand of gasoline. If this
does not correct the problem, consult your Lexus dealer.
Your vehicle must use only unleaded gasoline.
Premium unleaded gasoline with an Octane Rating 91 (Research Octane
Number 9
6) or higher required for optimum engine performance.
At minimum, the gasoline you use should meet the specifications of
ASTM D4814 in the U.S.A. an d CGSB3.5-M93 in Canada.
