2007 JEEP WRANGLER Owners Manual

Tire Size
The tire size on the Label represents the actual tire size on
your vehicle. Replacement tires must be equal to the load
capacity of this tire size.
Rim Size
This is the rim size that is appropriate for the tire size
listed.
Inflation Pressure
This is the cold tire inflation pressure for your vehicle for
all loading conditions up to full GAWR.
Curb Weight
The curb weight of a vehicle is defined as the total weight
of the vehicle with all fluids, including vehicle fuel, at full
capacity conditions, and with no occupants or cargo
loaded into the vehicle. The front and rear curb weight
values are determined by weighing your vehicle on a
commercial scale before any occupants or cargo are
added.
Loading
The actual total weight and the weight of the front and
rear of your vehicle at the ground can best be determined
by weighing it when it is loaded and ready for operation.
The entire vehicle should first be weighed on a commer-
cial scale to insure that the GVWR has not been exceeded.
The weight on the front and rear of the vehicle should
then be determined separately to be sure that the load is
properly distributed over front and rear axle. Weighing
the vehicle may show that the GAWR of either the front
or rear axles has been exceeded but the total load is
within the specified GVWR. If so, weight must be shifted
from front to rear or rear to front as appropriate until the
specified weight limitations are met. Store the heavier
items down low and be sure that the weight is distributed
equally. Stow all loose items securely before driving.
STARTING AND OPERATING 329
5

Improper weight distributions can have an adverse effect
on the way your vehicle steers and handles and the way
the brakes operate.
CAUTION!
Do not load your vehicle any heavier than the GVWR
or the maximum front and rear GAWR. If you do,
parts on your vehicle can break, or it can change the
way your vehicle handles. This could cause you to
lose control. Also overloading can shorten the life of
your vehicle.
TRAILER TOWING
In this section you will find safety tips and information
on limits to the type of towing you can reasonably do
with your vehicle. Before towing a trailer carefully re-
view this information to tow your load as efficiently and
safely as possible.
To maintain warranty coverage, follow the requirements
and recommendations in this manual concerning ve-
hicles used for trailer towing.
Common Towing Definitions
The following trailer towing related definitions will assist
you in understanding the following information:
Gross Vehicle Weight Rating (GVWR)
The GVWR is the total allowable weight of your vehicle.
This includes driver, passengers, cargo and tongue
weight. The total load must be limited so that you do not
exceed the GVWR.
330 STARTING AND OPERATING

Gross Trailer Weight (GTW)
The Gross Trailer Weight (GTW) is the weight of the
trailer plus the weight of all cargo, consumables and
equipment (permanent or temporary) loaded in or on the
trailer in itsloaded and ready for operationcondition.
The recommended way to measure GTW is to put your
fully loaded trailer on a vehicle scale. The entire weight
of the trailer must be supported by the scale.
Gross Combination Weight Rating (GCWR)
The Gross Combination Weight Rating (GCWR) is the
total permissible weight of your vehicle and trailer when
weighed in combination. (Note that GCWR ratings in-
clude a 150 lbs (68 kg) allowance for the presence of a
driver).
Gross Axle Weight Rating (GAWR)
The GAWR is the maximum capacity of the front and rear
axles. Distribute the load over the front and rear axles
evenly. Make sure that you do not exceed either front or
rear GAWR.
WARNING!
It is important that you do not exceed the maximum
front or rear GAWR. A dangerous driving condition
can result if either rating is exceeded. You could lose
control of the vehicle and have an accident.
Tongue Weight (TW)
The downward force exerted on the hitch ball by the
trailer. In most cases it should not be less than 10% or
more than 15% of the trailer load. You must consider this
as part of the load on your vehicle.
STARTING AND OPERATING 331
5

Frontal Area
The maximum height and maximum width of the front of
a trailer.
Trailer Sway Control
The trailer sway control is a telescoping link that can be
installed between the hitch receiver and the trailer tongue
that typically provides adjustable friction associated with
the telescoping motion to dampen any unwanted trailer
swaying motions while traveling.
Weight-Carrying Hitch
A weight-carrying hitch supports the trailer tongue
weight, just as if it were luggage located at a hitch ball or
some other connecting point of the vehicle. These kind of
hitches are the most popular on the market today and
they’re commonly used to tow small- and medium-sized
trailers.
Weight-Distributing Hitch
A weight-distributing system works by applying lever-
age through spring (load) bars. They are typically used
for heavier loads, to distribute trailer tongue weight to
the tow vehicle’s front axle and the trailer axle(s). When
used in accordance with the manufacturers’ directions, it
provides for a more level ride, offering more consistent
steering and brake control thereby enhancing towing
safety. The addition of a friction/hydraulic sway control
also dampens sway caused by traffic and crosswinds and
contributes positively to tow vehicle and trailer stability.
Trailer sway control and a weight distributing (load
equalizing) hitch are recommended for heavier Tongue
Weights (TW) and may be required depending on Vehicle
and Trailer configuration/loading to comply with Gross
Axle Weight Rating (GAWR) requirements.
332 STARTING AND OPERATING

WARNING!
An improperly adjusted Weight Distributing Hitch
system may reduce handling, stability, braking per-
formance, and could result in an accident.
Weight Distributing Systems may not be compatible
with Surge Brake Couplers. Consult with your hitch
and trailer manufacturer or a reputable Recreational
Vehicle dealer for additional information.
Weight Distributing Hitch System
STARTING AND OPERATING 333
5

Trailer Hitch Classification
The following chart provides the industry standard for
the maximum trailer weight a given trailer hitch class can
tow and should be used to assist you in selecting the
correct trailer hitch for your intended towing condition.Refer to the Trailer Towing Weights (Maximum Trailer
Weight Ratings) chart for the Max. GTW towable for your
given drivetrain.
Trailer Hitch Classification
Class Max. GTW
(Gross Trailer Wt.)
Class I - Light Duty 2,000 lbs (907 kg)
Class II - Medium
Duty3,500 lbs (1 587 kg)
Class III - Heavy Duty 5,000 lbs (2 268 kg)
Class IV - Extra
Heavy Duty10,000 lbs (4 540 kg)
All trailer hitches should be professionally installed on
your vehicle.
Improper Adjustment of Weight Distributing System
334 STARTING AND OPERATING

Trailer Towing Weights (Maximum Trailer Weight Ratings)
The following chart provides the maximum trailer weight ratings towable for your given drivetrain.
Engine/
Transmis-
sionAxle Model GCWR (Gross
Combined Wt.
Rating)Frontal Area Max. GTW (Gross
Trailer Wt.)Max. Tongue Wt.
(See Note 1)
3.8L/
Manual3.21 2 Door X Model
(4WD)4,932 lbs (2 237 kg) 25 sq. ft. (2.32
square meters)1,000 lbs (453 kg) 100 lbs (45 kg)
3.8L/
Manual4.10 2 Door X Model
(4WD)5,932 lbs (2 691 kg) 25 sq. ft. (2.32
square meters)2,000 lbs (907 kg) 200 lbs (91 kg)
3.8L/
Automatic4.10 2 Door X Model
(4WD)5,955 lbs (2 701 kg) 25 sq. ft. (2.32
square meters)2,000 lbs (907 kg) 200 lbs (91 kg)
3.8L/
Manual3.21 2 Door Sahara
Model (4WD)5,102 lbs (2 314 kg) 25 sq. ft. (2.32
square meters)1,000 lbs (453 kg) 100 lbs (45 kg)
3.8L/
Manual4.10 2 Door Sahara
Model (4WD)6,102 lbs (2 768 kg) 25 sq. ft. (2.32
square meters)2,000 lbs (907 kg) 200 lbs (91 kg)
3.8L/
Automatic4.10 2 Door Sahara
Model (4WD)6,126 lbs (2 779 kg) 25 sq. ft. (2.32
square meters)2,000 lbs (907 kg) 200 lbs (91 kg)
3.8L/
Manual4.10 2 Door Rubicon
Model (4WD)6,219 lbs (2 821 kg) 25 sq. ft. (2.32
square meters)2,000 lbs (907 kg) 200 lbs (91 kg)
STARTING AND OPERATING 335
5

Engine/
Transmis-
sionAxle Model GCWR (Gross
Combined Wt.
Rating)Frontal Area Max. GTW (Gross
Trailer Wt.)Max. Tongue Wt.
(See Note 1)
3.8L/
Automatic4.10 2 Door Rubicon
Model (4WD)6,243 lbs (2 832 kg) 25 sq. ft. (2.32
square meters)2,000 lbs (907 kg) 200 lbs (91 kg)
3.8L/
Manual3.21 4 Door X Model
(2WD)5,126 lbs (2 325 kg) 32 sq. ft. (2.97
square meters)1,000 lbs (453 kg) 100 lbs (45 kg)
3.8L/
Manual4.10 4 Door X Model
(2WD)7,626 lbs (3 459 kg) 32 sq. ft. (2.97
square meters)3,500 lbs (1 587 kg) 350 lbs (159 kg)
3.8L/
Automatic4.10 4 Door X Model
(2WD)7,649 lbs (3 469 kg) 32 sq. ft. (2.97
square meters)3,500 lbs (1 587 kg) 350 lbs (159 kg)
3.8L/
Manual3.21 4 Door Sahara
Model (2WD)5,289 lbs (2 399 kg) 32 sq. ft. (2.97
square meters)1,000 lbs (453 kg) 100 lbs (45 kg)
3.8L/
Manual4.10 4 Door Sahara
Model (2WD)7,789 lbs (3 533 kg) 32 sq. ft. (2.97
square meters)3,500 lbs (1 587 kg) 350 lbs (159 kg)
3.8L/
Automatic4.10 4 Door Sahara
Model (2WD)7,812 lbs (3 543 kg) 32 sq. ft. (2.97
square meters)3,500 lbs (1 587 kg) 350 lbs (159 kg)
3.8L/
Manual3.21 4 Door X Model
(4WD)5,330 lbs (2 418 kg) 32 sq. ft. (2.97
square meters)1,000 lbs (453 kg) 100 lbs (45 kg)
336 STARTING AND OPERATING
