2007 JEEP WRANGLER Owners Manual

To Open
1. Above the front of the rear door, place finger up into
the cut out in the plastic retainer and pull down rolling
both the front and rear retainers out of the door frame.
Repeat this on the other side.
2. Unclip and move the sun visors to the side.3. Release the header latches from the loops on the
windshield frame.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161
3

4. Grasp the front side bow behind the header, and lift
the top.5. Fold back the front section of the top, and gently rest
the header on top of the rear portion of the deck.
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

6. Fold the top material so that the plastic retainers form
a “W” as shown. Enter the vehicle, and move the material
into two folds. Ensure that the straps are securely stowed.
7. Close the front header latches.8. Secure the top by using the two (2) provided straps.
Each strap will wrap around the side bow and Velcroto
itself, use one strap on each side of the vehicle.
To Close
Perform the above steps in the opposite order.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163
3

SOFT TOP (4 DOOR MODELS)
CAUTION!
•The soft top is not designed to carry any additional
loads such as roof racks, spare tires, building,
hunting, or camping supplies, and/or luggage, etc.
Also, it was not designed as a structural member of
the vehicle, and thus cannot properly carry any
additional loads other than environmental (rain,
snow, etc.).If the temperature is below 72°F (24°C) and/or the top
has been folded down for a period of time, the top will
appear to have shrunk when you raise it, making it
difficult to put up. This is caused by a natural contraction
of the vinyl coating on the fabric top.
Place the vehicle in a warm area. Pull steadily on the top
fabric. The vinyl will stretch back to its original size and
the top can then be snapped into place.If temperature is
41°F (5°C) or below, do not attempt to put the top down
or roll the rear or side curtains.
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
•Do not run a fabric top through an automatic car wash.
Window scratches and wax build up may result.
•Do not lower the top when the temperature is below 41°F
(5°C). Damage to the top may result.
•Do not lower the top when the windows are dirty. Grit
may scratch the window.
•Do not move your vehicle until the top has been either
fully attached to the windshield frame, or fully lowered.
•Do not lower the top with the windows installed. Win-
dow and top damage may occur.
•Refer to “Appearance Care for Fabric Top Models” in
Section 7 of this manual. It contains important informa-
tion on cleaning and caring for your vehicle’s fabric top.
•Do not use any tools (screwdrivers, etc.) to pry or force
any of the clamps, clips, or retainers securing the soft top.
Do not force or pry the soft top frame work when
opening or closing. Damage to the top may result.
WARNING!
•Do not drive vehicle with rear window curtain up
unless side curtains are also open. Dangerous
exhaust gases which can kill could enter the ve-
hicle.
•The fabric upper doors and fabric top are designed
only for protection against the elements. Do not
rely on them to contain occupants within the
vehicle or to protect against injury during an
accident. Remember, always wear seat belts.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165
3

Folding Down The Soft Top
1 — Header Bow 6 — Body Side Retainer 11 — Plastic Retainer
2 — 2 Bow 7 — Quarter Window
3 — 3 Bow 8 — Check Strap
4 — 4 Bow 9 — Front Retainer — Quarter Window
5 — Sail Panel 10 — Bottom Retainer — Quarter Window 166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

1 — Zipper Start
2 — Zipper Finish
3 — Swing Gate Bar
4 — Swing Gate Brackets
5 — Sail PanelsUNDERSTANDING THE FEATURES OF YOUR VEHICLE 167
3

NOTE:Clean side and rear windows before removal to
assist in preventing scratching during removal of the soft
top. If zippers are difficult to operate due to road dust,
etc., clean them with a mild soap solution and a small
brush. Cleaning products are available through your
authorized dealer.
1. If your vehicle has half doors, remove each half door
window by opening the door and lifting the half door
window out.
NOTE:Stow half doors carefully outside of the vehicle,
never inside to avoid scratches.
2. Above the front of the rear door, place finger up into
the cut out in the plastic retainer and pull down rolling
both the front and rear retainers out of the door frame.
Repeat this on the other side.3. Unclip and move the sun visors to the side.
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
