EM-4Revision: 2006 July 2007 FX35/FX45
ROCKER COVER ..................................................
.200
Components ........................................................ .200
Removal and Installation ..................................... .200
REMOVAL ........................................................ .200
INSTALLATION ................................................. .202
TIMING CHAIN ....................................................... .203
Components ........................................................ .203
Removal and Installation ..................................... .204
REMOVAL ........................................................ .204
INSPECTION AFTER REMOVAL ..................... .208
INSTALLATION ................................................. .208
INSPECTION AFTER INSTALLATION ............. .214
CAMSHAFT ............................................................ .215
Components ........................................................ .215
Removal and Installation ..................................... .215
REMOVAL ........................................................ .215
INSPECTION AFTER REMOVAL ..................... .216
INSTALLATION ................................................. .219
INSPECTION AFTER INSTALLATION ............. .221
Valve Clearance ................................................... .222
INSPECTION .................................................... .222
ADJUSTMENT ................................................. .224
OIL SEAL ............................................................... .228
Removal and Installation of Valve Oil Seal .......... .228
REMOVAL ........................................................ .228
INSTALLATION ................................................. .228
Removal and Installation of Front Oil Seal .......... .229
REMOVAL ........................................................ .229
INSTALLATION ................................................. .229
Removal and Installation of Rear Oil Seal ........... .230
REMOVAL ........................................................ .230
INSTALLATION ................................................. .230
CYLINDER HEAD .................................................. .232
On-Vehicle Service .............................................. .232
CHECKING COMPRESSION PRESSURE ...... .232
Components ........................................................ .233
Removal and Installation ..................................... .233
REMOVAL ........................................................ .233
INSPECTION AFTER REMOVAL ..................... .234
INSTALLATION ................................................. .234
Disassembly and Assembly ................................. .236
COMPONENTS ................................................ .236
DISASSEMBLY ................................................ .236
ASSEMBLY ...................................................... .237
Inspection After Disassembly .............................. .238
VALVE DIMENSIONS ....................................... .238
VALVE GUIDE CLEARANCE ........................... .239
VALVE GUIDE REPLACEMENT ...................... .239
VALVE SEAT CONTACT .................................. .241
VALVE SEAT REPLACEMENT ........................ .241
VALVE SPRING SQUARENESS ...................... .242
VALVE SPRING DIMENSIONS AND VALVE
SPRING PRESSURE LOAD ............................ .242 ENGINE ASSEMBLY ..............................................
.243
Components ......................................................... .243
Removal and Installation ...................................... .243
REMOVAL ......................................................... .243
INSTALLATION ................................................. .246
INSPECTION AFTER INSTALLATION ............. .246
CYLINDER BLOCK ................................................ .248
Components ......................................................... .248
Disassembly and Assembly ................................. .249
DISASSEMBLY ................................................. .249
ASSEMBLY ....................................................... .253
How to Select Piston and Bearing ....................... .258
DESCRIPTION ................................................. .258
HOW TO SELECT PISTON .............................. .259
HOW TO SELECT CONNECTING ROD BEAR-
ING .................................................................... .260
HOW TO SELECT MAIN BEARING ................. .261
Inspection After Disassembly ............................... .265
CRANKSHAFT END PLAY ............................... .265
CONNECTING ROD SIDE CLEARANCE ........ .265
PISTON TO PISTON PIN OIL CLEARANCE .... .265
PISTON RING SIDE CLEARANCE .................. .266
PISTON RING END GAP ................................. .266
CONNECTING ROD BEND AND TORSION .... .267
CONNECTING ROD BIG END DIAMETER ..... .267
CONNECTING ROD BUSHING OIL CLEAR-
ANCE ................................................................ .267
CYLINDER BLOCK DISTORTION ................... .268
MAIN BEARING HOUSING INNER DIAMETER .269
PISTON TO CYLINDER BORE CLEARANCE . .269
CRANKSHAFT MAIN JOURNAL DIAMETER .. .270
CRANKSHAFT PIN JOURNAL DIAMETER ..... .271
CRANKSHAFT OUT-OF-ROUND AND TAPER .271
CRANKSHAFT RUNOUT ................................. .271
CONNECTING ROD BEARING OIL CLEAR-
ANCE ................................................................ .272
MAIN BEARING OIL CLEARANCE .................. .273
CRUSH HEIGHT OF MAIN BEARING ............. .274
CRUSH HEIGHT OF CONNECTING ROD
BEARING .......................................................... .274
DRIVE PLATE ................................................... .274
SERVICE DATA AND SPECIFICATIONS (SDS) ... .275
Standard and Limit ............................................... .275
GENERAL SPECIFICATIONS .......................... .275
DRIVE BELTS ................................................... .275
INTAKE MANIFOLD AND EXHAUST MANI-
FOLD ................................................................ .275
SPARK PLUG ................................................... .276
CAMSHAFT AND CAMSHAFT BEARING ........ .276
CYLINDER HEAD ............................................. .278
CYLINDER BLOCK ........................................... .281
PISTON, PISTON RING AND PISTON PIN ..... .282
CONNECTING ROD ......................................... .283
CRANKSHAFT .................................................. .284
MAIN BEARING ................................................ .286
CONNECTING ROD BEARING ........................ .287

PRECAUTIONS EM-5
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 July 2007 FX35/FX45
[VQ35DE]PRECAUTIONSPFP:00001
Precautions Necessary for Steering Wheel Rotation After Battery DisconnectNBS003FN
NOTE:

This Procedure is applied only to models with Intelligent Key system and NVIS/IVIS (NISSAN/INFINITI
VEHICLE IMMOBILIZER SYSTEM - NATS).

Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″ LOCK ″ position.

Always use CONSULT-II to perform self-diagnosis as a part of each function inspection after finishing
work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NVIS/IVIS, an electrically controlled steering lock
mechanism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the ″LOCK ″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-II.
Precautions for Drain Engine Coolant and Engine OilNBS003FO
Drain engine coolant and engine oil when the engine is cooled.
Precautions for Disconnecting Fuel PipingNBS003FP

Before starting work, make sure no fire or spark producing items are in the work area.

Release fuel pressure before disconnecting and disassembly.

After disconnecting pipes, plug openings to stop fuel leakage.
Precautions for Removal and DisassemblyNBS003FQ

When instructed to use SST, use specified tools. Always be careful to work safely, avoid forceful or unin-
structed operations.

Exercise maximum care to avoid damage to mating or sliding surfaces.

Cover openings of engine system with a tape or equivalent, if necessary, to seal out foreign materials.

Mark and arrange disassembly parts in an organized way for easy troubleshooting and re-assembly.

When loosening nuts and bolts, as a basic rule, start with the one furthest outside, then the one diagonally
opposite, and so on. If the order of loosening is specified, do exactly as specified. Power tools may be
used in the step.
Precautions for Inspection, Repair and ReplacementNBS003FR
Before repairing or replacing, thoroughly inspect parts. Inspect new replacement parts in the same way, and
replace if necessary.
Precautions for Assembly and InstallationNBS003FS

Use torque wrench to tighten bolts or nuts to specification.

EM-6
[VQ35DE]
PRECAUTIONS
Revision: 2006 July 2007 FX35/FX45

When tightening nuts and bolts, as a basic rule, equally tighten in several different steps starting with the
ones in center, then ones on inside and outside diagonally in this order. If the order of tightening is speci-
fied, do exactly as specified.

Replace with new gasket, packing, oil seal or O-ring.

Dowel pins are used for several parts alignment. When replacing and reassembling parts with dowel pins,
make sure that dowel pins are installed in the original position.

Thoroughly wash, clean, and air-blow each part. Carefully check engine oil or engine coolant passages for
any restriction and blockage.

Avoid damaging sliding or mating surfaces. Completely remove foreign materials such as cloth lint or dust.
Before assembly, oil sliding surfaces well.

Release air within route when refilling after draining engine coolant.

After repairing, start the engine and increase engine speed to check engine coolant, fuel, engine oil, and
exhaust gases for leakage.
Precautions for Angle TighteningNBS003FT

Use the angle wrench [SST: KV10112100 (BT8653-A)] for the final tightening of the following engine parts:
–Cylinder head bolts
–Main bearing cap bolts
–Connecting rod cap bolts
–Crankshaft pulley bolt (No the angle wrench is required as bolt flange is provided with notches for angle
tightening)

Do not use a torque value for final tightening.

The torque value for these parts are for a preliminary step.

Ensure thread and seat surfaces are clean and coated with engine oil.
Precautions for Liquid GasketNBS003FU
REMOVAL OF LIQUID GASKET SEALING

After removing mounting nuts and bolts, separate the mating
surface using the seal cutter (SST) and remove old liquid gasket
sealing.
CAUTION:
Be careful not to damage the mating surfaces.

Tap the seal cutter to insert it, and then slide it by tapping on the
side as shown in the figure.

In areas where the seal cutter is difficult to use, use a plastic
hammer to lightly tap the parts, to remove it.
CAUTION:
If for some unavoidable reason tool such as a screwdriver
is used, be careful not to damage the mating surfaces.
LIQUID GASKET APPLICATION PROCEDURE
1. Using a scraper, remove old liquid gasket adhering to the gasket application surface and the mating surface.

Remove liquid gasket completely from the groove of the gas-
ket application surface, mounting bolts, and bolt holes.
2. Wipe the liquid gasket application surface and the mating sur- face with white gasoline (lighting and heating use) to remove
adhering moisture, grease and foreign materials.
PBIC0002E
PBIC0003E

EM-10
[VQ35DE]
PREPARATION
Revision: 2006 July 2007 FX35/FX45
Commercial Service ToolsNBS003FW
KV10114400
(J38365)
Heated oxygen sensor wrench Loosening or tightening air fuel ratio sensor 1
a: 22 mm (0.87 in)
KV10117700
(J44716)
Ring gear stopper Removing and installing crankshaft pulley
10006 31U00
(—)
Engine rear slinger Removing and installing oil pan (upper) for on
vehicle service
—
(J-45488)
Quick connector release Removing fuel tube quick connectors in
engine room
Tool number
(Kent-Moore No.)
Tool name Description
NT636
NT822
SBIA0530E
PBIC0198E
(Kent-Moore No.)
Tool name Description
(—)
Power tool Loosening nuts and bolts
(BT3373-F)
Belt tension gauge Checking drive belt tension
PBIC0190E
AMA126

PREPARATION EM-11
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 July 2007 FX35/FX45
(—)
TORX socket Removing and installing flywheel
Size: T55
(—)
Manual lift table caddy Removing and installing engine
(J24239-01)
Cylinder head bolt wrench Loosening and tightening cylinder head bolt,
and used with the angle wrench [SST:
KV10112100 (BT8653-A)]
a: 13 (0.51) dia.
b: 12 (0.47)
c: 10 (0.39)
Unit: mm (in)
(—)
1.Compression tester
2.Adapter Checking compression pressure
(—)
Spark plug wrench Removing and installing spark plug
(—)
Valve seat cutter set Finishing valve seat dimensions
(—)
Piston ring expander Removing and installing piston ring
(Kent-Moore No.)
Tool name Description
PBIC1113E
ZZA1210D
NT583
ZZA0008D
NT047
NT048
NT030

EM-14
[VQ35DE]
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
Revision: 2006 July 2007 FX35/FX45
Use the Chart Below to Help You Find the Cause of the Symptom.NBS003FY
1. Locate the area where noise occurs.
2. Confirm the type of noise.
3. Specify the operating condition of the engine.
4. Check specified noise source.
If necessary, repair or replace these parts.
A: Closely related B: Related C: Sometimes related —: Not related Location
of noise Type of
noise Operating condition of engine
Source of noise Check item Refer-
ence page
Before
warm- up After
warm- up When
start- ing When
idling When
racing While
driving
Top of
engine
Rocker
cover
Cylinder
head Ticking or
clicking CA—AB— Tappet
noise Valve clearance
EM-93
Rattle C A — A B C Camshaft
bearing
noise Camshaft runout
Camshaft journal oil
clearance EM-85EM-86
Crank-
shaft pul-
ley
Cylinder
block
(Side of
engine)
Oil pan Slap or
knock —A—B B— Piston pin
noise Piston to piston pin oil
clearance
Connecting rod bush-
ing oil clearance EM-141
EM-143
Slap or
rap A——B B A Piston
slap noise Piston to cylinder bore
clearance
Piston ring side clear-
ance
Piston ring end gap
Connecting rod bend
and torsion EM-145EM-142
EM-142
EM-143
Knock A B C B B B
Connect-
ing rod
bearing
noise Connecting rod bush-
ing oil clearance
Connecting rod bear-
ing oil clearance EM-143EM-147
Knock A B — A B C
Main
bearing
noise Main bearing oil clear-
ance
Crankshaft runout EM-148
EM-147
Front of
engine
Timing
chain
case Tapping or
ticking AA—BBB Timing
chain and
timing
chain ten-
sioner
noise Timing chain cracks
and wear
Timing chain tensioner
operation EM-72
EM-64
Front of
engine Squeak-
ing or fizz-
ing AB—B—C Drive belts
(Sticking
or slip-
ping) Drive belts deflection
EM-15
CreakingABABAB Drive belts
(Slipping) Idler pulley bearing
operation
Squall
Creak AB—BAB Water
pump
noise Water pump operation CO-22,
"WATER
PUMP"

DRIVE BELTS EM-15
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 July 2007 FX35/FX45
DRIVE BELTSPFP:02117
Checking Drive BeltsNBS003FZ
WARNING:
Be sure to perform when engine is stopped.
1. Inspect belts for cracks, fraying, wear and oil. If necessary, replace.
2. Inspect drive belt deflection or tension at a point on belt midway between pulleys.

Inspection should be done only when engine is cold, or over
30 minutes after engine is stopped.

Measure the belt tension with belt tension gauge (Commercial
service tool: BT3373-F or equivalent) at points marked
shown in the figure.

When measuring the deflection, apply 98 N (10 kg, 22 lb) at
the marked point.

Adjust if the belt deflection exceeds the limit or if the belt ten-
sion is not within specifications.
CAUTION:

When checking the belt deflection or the tension immediately after installation, first adjust it to
the specified value. Then, after turning crankshaft two turns or more, re-adjust to the specified
value to avoid variation in deflection between pulleys.

Tighten idler pulley lock nut by hand and measure the deflection or the tension without loose-
ness.
Belt Deflection and Tension
*: If belt tension gauge cannot be installed at check points shown, check drive belt tension at different location on belt.
Tension AdjustmentNBS003G0
CAUTION:

When belt is replaced with a new one, adjust it to value for “New belt” to accommodate for insuffi-
cient adaptability with pulley grooves.

When deflection or tension of belt being used exceeds “Limit”, adjust it to value for “After adjust-
ment”.

When checking belt deflection or tension immediately after installation, first adjust it to the speci-
fied value. Then, after turning crankshaft two turns or more, re-adjust to the specified value to
avoid variation in deflection between pulleys.

When installing belt, make sure that it is correctly engaged with pulley grooves.

Keep engine oil, working fluid and engine coolant away from belt and pulley grooves.

Do not twist or bend belt excessively.
KBIA1731J
Items Deflection adjustment Unit: mm (in) Tension adjustment* Unit: N (kg, lb)
Used belt New belt Used belt
New belt
Limit After adjustment Limit After adjustment
Alternator and
power steering
oil pump belt 7 (0.28)
4 - 5
(0.16 - 0.20) 3.5 - 4.5
(0.138 - 0.177) 294 (30, 66) 730 - 818
(74.5 - 83.4, 164 - 184) 838 - 926
(85.5 - 94.5, 188 - 208)
A/C compressor
belt 12 (0.47) 9 - 10
(0.35 - 0.39) 8 - 9
(0.31 - 0.35) 196 (20, 44) 348 - 436
(35.5 - 44.5, 78 - 98) 470 - 559
(47.9 - 57.0, 106 - 126)
Applied pushing
force 98 N (10 kg, 22 lb) —
Portion
Belt tightening method for adjustment
Alternator and power steering oil pump belt Adjusting bolt on idler pulley
A/C compressor belt Adjusting bolt on idler pulley

EM-16
[VQ35DE]
DRIVE BELTS
Revision: 2006 July 2007 FX35/FX45
ALTERNATOR AND POWER STEERING OIL PUMP BELT
1. Remove front engine undercover with power tool.
2. Loosen idler pulley lock nut (A) and adjust tension by turning adjusting bolt (B).

For the specified belt tension, refer to EM-15, "Checking Drive
Belts" .
3. Tighten nut (A).
A/C COMPRESSOR BELT
1. Remove front engine undercover with power tool.
2. Loosen idler pulley lock nut (C) and adjust tension by turning adjusting bolt (D).

For the specified belt tension, refer to EM-15, "Checking Drive Belts" .
3. Tighten nut (C).
Removal and InstallationNBS003G1
REMOVAL
1. Remove front engine undercover with power tool.
2. Remove alternator and power steering oil pump belt. Refer to EM-16, "
ALTERNATOR AND POWER
STEERING OIL PUMP BELT" .
3. Remove A/C compressor belt. Refer to EM-16, "
A/C COMPRESSOR BELT" .
CAUTION:
Grease is applied to idler pulley adjusting bolt. Be careful to keep grease away from belt.
INSTALLATION
1. Install belts to pulley in reverse order of removal.
CAUTION:

Make sure drive belt is correctly engaged with pulley groove.

Make sure that for engine oil and engine coolant do not adhere to belt and each pulley grooves.
2. Adjust belt tension. Refer to EM-15, "
Tension Adjustment" .
3. Tighten each adjusting bolt and nut to the specified torque.
4. Make sure that tension of each belt is within the standard. Refer to EM-15, "
Checking Drive Belts" .
: 34.8 N·m (3.5 kg-m, 26 ft-lb)
SBIA0532E
: 34.8 N·m (3.5 kg-m, 26 ft-lb)
