LAN-84
[CAN]
TROUBLE DIAGNOSIS
Revision: 2006 July 2007 FX35/FX45
Data Link Connector Branch Line CircuitNKS004O7
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the data link connector for damage, bend and loose connection (connector side and harness side).
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
Check the resistance between the data link connector terminals.
OK or NG
OK >>
Present error: Check the following items again.
–Decision of CAN system type.
–Not received CONSULT-II data (SELECT SYSTEM, SELF-DIAG RESULTS, CAN DIAG SUP-
PORT MNTR).
–Not copied from on-board diagnosis.
–Procedure for detecting root cause.

Past error: Error was detected in the data link connector branch line circuit.
NG >> Repair the data link connector branch line.
Intelligent Key Unit Branch Line CircuitNKS004O8
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the Intelligent Key unit for damage, bend and loose connection (unit side and connector side).
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of Intelligent Key unit.
2. Check the resistance between the Intelligent Key unit harness connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Repair the Intelligent Key unit branch line.
Data link connector Resistance ( Ω)
Connector No. Terminal No.
M5 6 14 Approx. 54 – 66
Intelligent Key unit harness connector Resistance ( Ω)
Connector No. Terminal No.
M34 2 3 Approx. 54 – 66

TROUBLE DIAGNOSIS LAN-85
[CAN]
C
D E
F
G H
I
J
L
M A
B
LAN
Revision: 2006 July 2007 FX35/FX45
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the Intelligent Key unit. Refer to BL-96, "
Schematic" .
OK or NG
OK >>
Present error: Replace the Intelligent Key unit. Refer to BL-146, "Removal and Installation of
Intelligent Key Unit" .

Past error: Error was detected in the Intelligent Key unit branch line.
NG >> Repair the power supply and the ground circuit.
LDW Camera Unit Branch Line CircuitNKS004OL
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors for damage, bend, and loose connection (unit side and con- nector side).
–LDW camera unit connector
–Harness connector R1
–Harness connector M31
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of LDW camera unit.
2. Check the resistance between the LDW camera unit harness connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Repair the LDW camera unit branch line.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the LDW camera unit. Refer to DI-96, "
Power Supply and
Ground Circuit Inspection" .
OK or NG
OK >>
Present error: Replace the LDW camera unit. Refer to DI-104, "Removal and Installation for
LDW Camera Unit" .

Past error: Error was detected in the LDW camera unit branch line.
NG >> Repair the power supply and the ground circuit.
LDW camera unit harness connector Resistance ( Ω)
Connector No. Terminal No.
R9 10 5 Approx. 54 – 66

LT-3
C
D E
F
G H
I
J
L
M A
B
LT
Revision: 2006 July 2007 FX35/FX45
