2007 INFINITI FX35 P0717

DTC P0717 TURBINE REVOLUTION SENSOR AT-117
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 July 2007 FX35/FX45
Diagnostic ProcedureNCS001E6
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Start engine.
2. Select “ECU INPUT SIGNALS” in “DATA MONITOR” mode for “A/T” with CONSULT-II.
3. Vehicle start and read out the value of “TURBINE REV”.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2. CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to AT- 1 7 9 , "
MAIN POWER SUPPLY AND GROUND CIR-
CUIT" .
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3. DETECT MALFUNCTIONING ITEM
Check A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to AT- 2 3 9 , "Control Valve with TCM and A/T Fluid Tem-
perature Sensor 2" .
NG >> Repair or replace damaged parts.
4. CHECK DTC
Perform AT- 11 6 , "
DTC Confirmation Procedure" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 2.
Item name Condition Display value (rpm)
TURBINE REV During driving (lock-up ON) Approximately matches
the engine speed.
PCIA0041E

INDEX FOR DTC EC-17
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 July 2007 FX35/FX45P0456 0456 EVAP VERY SML LEAK EC-449
P0460 0460 FUEL LEV SEN SLOSHEC-459
P0461 0461 FUEL LEVEL SENSOREC-461
P0462 0462 FUEL LEVL SEN/CIRCEC-463
P0463 0463 FUEL LEVL SEN/CIRCEC-463
P0500 0500
VEH SPEED SEN/CIRC*5EC-465
P0506 0506 ISC SYSTEM EC-467
P0507 0507 ISC SYSTEMEC-469
P0550 0550 PW ST P SEN/CIRCEC-471
P0603 0603 ECM BACK UP/CIRCUITEC-476
P0605 0605 ECMEC-480
P0643 0643 SENSOR POWER/CIRCEC-483
P0700 0700 TCM AT- 111
P0705 0705 PNP SW/CIRCAT- 11 2
P0710 0710 ATF TEMP SEN/CIRCAT- 1 3 4
P0717 0717 TURBINE SENSOR AT- 11 6
P0720 0720
VEH SPD SEN/CIR AT*5AT- 11 8
P0740 0740 TCC SOLENOID/CIRC AT- 1 2 5
P0744 0744 A/T TCC S/V FNCTNAT- 1 2 7
P0745 0745 L/PRESS SOL/CIRCAT- 1 2 9
P0850 0850 P-N POS SW/CIRCUITEC-488
P1148 1148 CLOSED LOOP-B1EC-493
P1168 1168 CLOSED LOOP-B2EC-493
P1211 1211 TCS C/U FUNCTNEC-494
P1212 1212 TCS/CIRC EC-495
P1217 1217 ENG OVER TEMPEC-496
P1225 1225 CTP LEARNINGEC-509
P1226 1226 CTP LEARNING EC-511
P1421 1421 COLD START CONTROLEC-513
P1564 1564 ASCD SW EC-515 (Models with ICC),
EC-522
(Models with ASCD)
P1568 1568 ICC COMMAND VALUE*
6EC-529
P1572 1572 ASCD BRAKE SW EC-530 (Models with ICC),
EC-539
(Models with ASCD)
P1574 1574 ASCD VHL SPD SEN EC-547
(Models with ICC),
EC-549
(Models with ASCD)
P1610 - P1615 1610 - 1615 NATS MALFUNCTION EC-551
P1715 1715 IN PULY SPEEDEC-551
P1730 1730 A/T INTERLOCK AT- 1 4 1
P1752 1752 I/C SOLENOID/CIRCAT- 1 4 6
P1754 1754 I/C SOLENOID FNCTNAT- 1 4 8
P1757 1757 FR/B SOLENOID/CIRCAT- 1 5 0
P1759 1759 FR/B SOLENOID FNCTAT- 1 5 2
DTC*1
Items
(CONSULT-II screen terms) Reference page
CONSULT-II
GST*
2ECM*3

EC-22
[VQ35DE]
INDEX FOR DTC
Revision: 2006 July 2007 FX35/FX45
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-II.
*5: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.
*6: For models with ICC system. SENSOR POWER/CIRC P0643 0643
EC-483
TCC SOLENOID/CIRC P0740 0740 AT-125
TCM P0700 0700 AT- 111
TCS C/U FUNCTN P1211 1211EC-494
TCS/CIRC P1212 1212EC-495
THERMSTAT FNCTN P0128 0128EC-227
TP SEN 1/CIRC P0222 0222EC-338
TP SEN 1/CIRC P0223 0223EC-338
TP SEN 2/CIRC P0122 0122EC-214
TP SEN 2/CIRC P0123 0123EC-214
TP SENSOR P2135 2135EC-590
TURBINE SENSOR P0717 0717 AT- 11 6
TW CATALYST SYS-B1 P0420 0420EC-376
TW CATALYST SYS-B2 P0430 0430EC-376
VEH SPD SEN/CIR AT*5P0720 0720AT- 11 8
VEH SPEED SEN/CIRC*5P0500 0500EC-465
VENT CONTROL VALVE P0447 0447 EC-411
VENT CONTROL VALVE P0448 0448EC-418
Items
(CONSULT-II screen terms) DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3

EC-56
[VQ35DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 July 2007 FX35/FX45
VENT CONTROL VALVE P0448 0448 — — 2 ×EC-418
EVAP SYS PRES SEN P0451 0451 — — 2 ×EC-424
EVAP SYS PRES SEN P0452 0452 — — 2 ×EC-427
EVAP SYS PRES SEN P0453 0453 — — 2 ×EC-433
EVAP GROSS LEAK P0455 0455 — — 2 ×EC-441
EVAP VERY SML LEAK P0456 0456
× *4× 2 ×EC-449
FUEL LEV SEN SLOSH P0460 0460 — — 2 ×EC-459
FUEL LEVEL SENSOR P0461 0461 — — 2 ×EC-461
FUEL LEVL SEN/CIRC P0462 0462 — — 2 ×EC-463
FUEL LEVL SEN/CIRC P0463 0463 — — 2 ×EC-463
VEH SPEED SEN/CIRC*6P0500 0500 — — 2 ×EC-465
ISC SYSTEM P0506 0506 — — 2 ×EC-467
ISC SYSTEM P0507 0507 — — 2 ×EC-469
PW ST P SEN/CIRC P0550 0550 — — 2 — EC-471
ECM BACK UP/CIRCUIT P0603 0603 — — 2×EC-476
ECM P0605 0605 — — 1 or 2 × or — EC-480
SENSOR POWER/CIRC P0643 0643 — — 1 ×EC-483
TCM P0700 0700 — — 1 ×AT- 111
PNP SW/CIRC P0705 0705 — — 2 ×AT- 11 2
ATF TEMP SEN/CIRC P0710 0710 — — 2 ×AT-134
TURBINE SENSOR P0717 0717 — — 2 ×AT- 11 6
VEH SPD SEN/CIR AT*6P0720 0720 — — 2 ×AT- 11 8
TCC SOLENOID/CIRC P0740 0740 — — 2 ×AT-125
A/T TCC S/V FNCTN P0744 0744 — — 2 ×AT-127
L/PRESS SOL/CIRC P0745 0745 — — 2 ×AT-129
P-N POS SW/CIRCUIT P0850 0850 — — 2 ×EC-488
CLOSED LOOP-B1 P1148 1148 — — 1 ×EC-493
CLOSED LOOP-B2 P1168 1168 — — 1 ×EC-493
TCS C/U FUNCTN P1211 1211 — — 2 — EC-494
TCS/CIRC P1212 1212 — — 2 —EC-495
ENG OVER TEMP P1217 1217 — — 1×EC-496
CTP LEARNING P1225 1225 — — 2 — EC-509
CTP LEARNING P1226 1226 — — 2 — EC-511
COLD START CONTROL P1421 1421 — — 2×EC-513
ASCD SW P1564 1564 — — 1 — EC-515

(Models
with ICC) EC-522

(Models
with ASCD)
ICC COMMAND VALUE*
7P1568 1568 — — 1 — EC-529
Items
(CONSULT-II screen terms) DTC*
1
SRT code
Test value/
Test limit
(GST only) Trip MIL
Reference
page
CONSULT-II
GST*
2ECM*3

EC-94
[VQ35DE]
TROUBLE DIAGNOSIS
Revision: 2006 July 2007 FX35/FX45
*: Models with ICC. 2

P0031 P0032 P0051 P0052 Air fuel ratio (A/F) sensor 1 heater

P0037 P0038 P0057 P0058 Heated oxygen sensor 2 heater

P0075 P0081 Intake valve timing control solenoid valve

P0130 P0131 P0132 P0133 P0150 P0151 P0152 P0153 P2A00 P2A03 Air fuel ratio (A/F) sensor 1

P0137 P0138 P0139 P0157 P0158 P0159 Heated oxygen sensor 2

P0441 EVAP control system purge flow monitoring

P0443 P0444 P0445 EVAP canister purge volume control solenoid valve

P0447 P0448 EVAP canister vent control valve

P0451 P0452 P0453 EVAP control system pressure sensor

P0550 Power steering pressure sensor

P0603 ECM power supply

P0710 P0717 P0720 P0740 P0744 P0745 P1730 P1752 P1754 P1757 P1759 P1762 P1764 P1767 P1769 P1772
P1774 A/T related sensors, solenoid valves and switches

P1217 Engine over temperature (OVERHEAT)

P1805 Brake switch

P2100 P2103 P2118 Electric throttle control actuator

P2101 Electric throttle control function
3

P0011 P0021 Intake valve timing control

P0171 P0172 P0174 P0175 Fuel injection system function

P0300 - P0306 Misfire

P0420 P0430 Three way catalyst function

P0442 EVAP control system (SMALL LEAK)

P0455 EVAP control system (GROSS LEAK)

P0456 EVAP control system (VERY SMALL LEAK)

P0506 P0507 Idle speed control system

P1148 P1168 Closed loop control

P1211 TCS control unit

P1212 TCS communication line

P1421 COLD START CONTROL

P1564 ICC steering switch/ASCD steering switch

P1568 ICC command valve*

P1572 ICC brake switch/ASCD brake switch

P1574 ICC vehicle speed sensor/ASCD vehicle speed sensor

P1715 Turbine revolution sensor

P2119 Electric throttle control actuator
Priority Detected items (DTC)

INDEX FOR DTC EC-679
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 July 2007 FX35/FX45P0452 0452 EVAP SYS PRES SEN EC-1096
P0453 0453 EVAP SYS PRES SEN EC-1102
P0455 0455 EVAP GROSS LEAK E C - 111 0
P0456 0456 EVAP VERY SML LEAKE C - 111 8
P0460 0460 FUEL LEV SEN SLOSHEC-1127
P0461 0461 FUEL LEVEL SENSOREC-1129
P0462 0462 FUEL LEVL SEN/CIRCEC-1131
P0463 0463 FUEL LEVL SEN/CIRCEC-1131
P0500 0500
VEH SPEED SEN/CIRC*5EC-1133
P0506 0506 ISC SYSTEM EC-1135
P0507 0507 ISC SYSTEMEC-1137
P0550 0550 PW ST P SEN/CIRCEC-1139
P0603 0603 ECM BACK UP/CIRCUITEC-1144
P0605 0605 ECMEC-1148
P0643 0643 SENSOR POWER/CIRCEC-1151
P0700 0700 TCM AT- 111
P0705 0705 PNP SW/CIRCAT- 11 2
P0710 0710 ATF TEMP SEN/CIRCAT-134
P0717 0717 TURBINE SENSOR AT- 11 6
P0720 0720
VEH SPD SEN/CIR AT*5AT- 11 8
P0740 0740 TCC SOLENOID/CIRC AT-125
P0744 0744 A/T TCC S/V FNCTNAT-127
P0745 0745 L/PRESS SOL/CIRCAT-129
P0850 0850 P-N POS SW/CIRCUITEC-1156
P1140 1140 INTK TIM S/CIRC-B1EC-1161
P1145 1145 INTK TIM S/CIRC-B2EC-1161
P1148 1148 CLOSED LOOP-B1EC-1170
P1168 1168 CLOSED LOOP-B2EC-1170
P1211 1211 TCS C/U FUNCTNEC-1171
P1212 1212 TCS/CIRC EC-1172
P1217 1217 ENG OVER TEMPEC-1173
P1225 1225 CTP LEARNINGEC-1185
P1226 1226 CTP LEARNINGEC-1187
P1421 1421 COLD START CONTROLEC-1189
P1564 1564 ASCD SW EC-1191 (Models with ICC)
EC-1198
(Models with ASCD)
P1568 1568 ICC COMMAND VALUE*
6EC-1205
P1572 1572 ASCD BRAKE SW EC-1206 (Models with ICC)
EC-1215
(Models with ASCD)
P1574 1574 ASCD VHL SPD SEN EC-1223
(Models with ICC)
EC-1225
(Models with ASCD)
P1610 - P1615 1610 - 1615 NATS MALFUNCTION EC-714
P1715 1715 IN PULY SPEEDEC-1227
DTC*1
Items
(CONSULT-II screen terms) Reference page
CONSULT-II
GST*
2ECM*3

EC-684
[VK45DE]
INDEX FOR DTC
Revision: 2006 July 2007 FX35/FX45
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-II.
*5: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.
*6: Models with ICC. PNP SW/CIRC P0705 0705
AT- 11 2
PURG VOLUME CONT/V P0443 0443EC-1065
PURG VOLUME CONT/V P0444 0444EC-1073
PURG VOLUME CONT/V P0445 0445EC-1073
PW ST P SEN/CIRC P0550 0550 EC-1139
SENSOR POWER/CIRC P0643 0643EC-1151
TCC SOLENOID/CIRC P0740 0740 AT- 1 2 5
TCM P0700 0700 AT- 111
TCS C/U FUNCTN P1211 1211EC-1171
TCS/CIRC P1212 1212EC-1172
THERMSTAT FNCTN P0128 0128 EC-899
TP SEN 1/CIRC P0222 0222EC-1009
TP SEN 1/CIRC P0223 0223EC-1009
TP SEN 2/CIRC P0122 0122 EC-886
TP SEN 2/CIRC P0123 0123EC-886
TP SENSOR P2135 2135EC-1272
TURBINE SENSOR P0717 0717 AT- 11 6
TW CATALYST SYS-B1 P0420 0420EC-1045
TW CATALYST SYS-B2 P0430 0430EC-1045
VEH SPD SEN/CIR AT*5P0720 0720AT- 11 8
VEH SPEED SEN/CIRC*5P0500 0500EC-1133
VENT CONTROL VALVE P0447 0447 EC-1080
VENT CONTROL VALVE P0448 0448EC-1087
VIAS S/V CIRC P1800 1800EC-1228
Items
(CONSULT-II screen terms) DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3

EC-718
[VK45DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 July 2007 FX35/FX45
EVAP SYS PRES SEN P0451 0451 — — 2 ×EC-1093
EVAP SYS PRES SEN P0452 0452 — — 2 ×EC-1096
EVAP SYS PRES SEN P0453 0453 — — 2 ×EC-1102
EVAP GROSS LEAK P0455 0455 — — 2 ×E C - 111 0
EVAP VERY SML LEAK P0456 0456
× *7× 2 ×E C - 111 8
FUEL LEV SEN SLOSH P0460 0460 — — 2 ×EC-1127
FUEL LEVEL SENSOR P0461 0461 — — 2 ×EC-1129
FUEL LEVL SEN/CIRC P0462 0462 — — 2 ×EC-1131
FUEL LEVL SEN/CIRC P0463 0463 — — 2 ×EC-1131
VEH SPEED SEN/CIRC*5P0500 0500 — — 2 ×EC-1133
ISC SYSTEM P0506 0506 — — 2 ×EC-1135
ISC SYSTEM P0507 0507 — — 2 ×EC-1137
PW ST P SEN/CIRC P0550 0550 — — 2 — EC-1139
ECM BACK UP/CIRCUIT P0603 0603 — — 2×EC-1144
ECM P0605 0605 — — 1 or 2 × or — EC-1148
SENSOR POWER/CIRC P0643 0643 — — 1 ×EC-1151
TCM P0700 0700 — — 1 ×AT- 111
PNP SW/CIRC P0705 0705 — — 2 ×AT- 11 2
ATF TEMP SEN/CIRC P0710 0710 — — 2 ×AT- 1 3 4
TURBINE SENSOR P0717 0717 — — 2 ×AT- 11 6
VEH SPD SEN/CIR AT*5P0720 0720 — — 2 ×AT- 11 8
TCC SOLENOID/CIRC P0740 0740 — — 2 ×AT- 1 2 5
A/T TCC S/V FNCTN P0744 0744 — — 2 ×AT- 1 2 7
L/PRESS SOL/CIRC P0745 0745 — — 2 ×AT- 1 2 9
P-N POS SW/CIRCUIT P0850 0850 — — 2 ×EC-1156
INTK TIM S/CIRC-B1 P1140 1140 — — 2 ×EC-1161
INTK TIM S/CIRC-B2 P1145 1145 — — 2 ×EC-1161
CLOSED LOOP-B1 P1148 1148 — — 1 ×EC-1170
CLOSED LOOP-B2 P1168 1168 — — 1 ×EC-1170
TCS C/U FUNCTN P1211 1211 — — 2 — EC-1171
TCS/CIRC P1212 1212 — — 2 —EC-1172
ENG OVER TEMP P1217 1217 — — 1×EC-1173
CTP LEARNING P1225 1225 — — 2 — EC-1185
CTP LEARNING P1226 1226 — — 2 —EC-1187
COLD START CONTROL P1421 1421 — — 2×EC-1189
ASCD SW P1564 1564 — — 1 — EC-1191

(Models
with ICC) EC-1198

(Models
with ASCD)
ACC COMMAND VALUE*
6P1568 1568 — — 1 — EC-1205
Items
(CONSULT-II screen terms) DTC*
1
SRT code
Test value/
Te s t l i m i t
(GST only) Trip MIL
Reference
page
CONSULT-II
GST*
2ECM*3
