2007 HUMMER H2 tow

Seats and Restraint Systems
....................... 7
Front Seats
.............................................. 8
Rear Seats
............................................. 15
Safety Belts
............................................ 24
Child Restraints
...................................... 46
Airbag System
........................................ 77
Restraint System Check
......................... 90
Features and Controls
................................ 93
Keys
....................................................... 95
Doors and Locks
.................................. 100
Windows
............................................... 111
Theft-Deterrent Systems
....................... 115
Starting and Operating Your Vehicle
....... 119
Mirrors
.................................................. 139
OnStar
®System
................................... 144
Universal Home Remote System
.......... 148
Storage Areas
...................................... 160
Sunroof
................................................ 168Instrument Panel
....................................... 171
Instrument Panel Overview
................... 174
Climate Controls
................................... 197
Warning Lights, Gages, and
Indicators
.......................................... 204
Driver Information Center (DIC)
............ 222
Audio System(s)
................................... 241
Driving Your Vehicle
................................. 301
Your Driving, the Road, and
Your Vehicle
..................................... 302
Towing
................................................. 369
Service and Appearance Care
.................. 389
Service
................................................. 392
Fuel
...................................................... 394
Checking Things Under the Hood
......... 400
Rear Axle
............................................. 437
Four-Wheel Drive
.................................. 438
Front Axle
............................................ 440
2007 HUMMER H2 Owner ManualM
1

To use the seat exit position, do one of the
following:
Press the exit button on the memory control,
or
If this feature is activated in the DIC, removing
the key from the ignition will move the seat to
the exit position.
See “Easy Exit Seat” underDIC Vehicle
Customization on page 234for more information
on activating this feature in the DIC.
Power Reclining Seatbacks
The front seats have power reclining seatbacks.
The control used to operate the seatbacks
are located on the outboard side of the seats.
To recline the seatback, press the control
toward the rear of the vehicle.
To raise the seatback, press the control
toward the front of the vehicle.
12

Notice:Folding a rear seat with the safety
belts still fastened may cause damage to the
seat or the safety belts. Always unbuckle
the safety belts and return them to their normal
stowed position before folding a rear seat.
3. Pull the seatback forward and fold it down until
it is at.
If the seatback cannot fold at because it
interferes with the cushion, try moving the front
seat forward and/or bringing the front
seatback more upright.
4. Repeat the steps for the other half of the
60/40 split bench seat.Returning the Seats to an Upright
Position
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on the
seatback to be sure it is locked.
{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted will not
provide the protection needed in a crash.
The person wearing the belt could be
seriously injured. After raising the rear
seatback, always check to be sure that the
safety belts are properly routed and
attached, and are not twisted.
16

To return the seat(s) to the upright position, do the
following:
1. Lift the seatback up and push it rearward all
the way.
2. Lower the seat cushion until it latches into
position.
3. Pull forward on the seatback and up on
the seat cushion to make sure the seat is
securely in place.
4. Return the head restraints (SUV only) to the
upright position.
Third Row Seat (SUV)
Entering or Exiting the Third Row Seat
If your vehicle has a third row seat, you must
fold the second row seat down before entering or
exiting the third row. See “Folding the Seatbacks”
under60/40 Split Bench Seat on page 15
earlier in this section for instructions.
The third row seatback can be folded and the
entire seat can be tilted or removed from
the vehicle.
Folding the Seatback
To fold the seatback, do the following:
Notice:Folding a rear seat with the safety
belts still fastened may cause damage to the
seat or the safety belts. Always unbuckle
the safety belts and return them to their normal
stowed position before folding a rear seat.
1. Pull up on the
release lever
labeled 1, located on
the rear of the
seatback, and push
the seatback
forward.
17

Returning the Seat from a Tilted to an
Upright Position
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on the
seatback to be sure it is locked.To return the seatback to an upright position, do
the following:
1. Pull the lever labeled 3 toward you.
2. While still holding lever 3 toward you, grasp
the top of the seat and pull it toward you
slightly.
19

3. Let go of lever 3 and pull the seat
completely down.
4. Push down on the seat rmly. Try pulling it up
to be sure it is locked into place.
5. Pull up on the
release lever
labeled 1 and then
pull up on the
seatback until the
seatback locks into
the upright position.Removing the Seat
To remove the seat, do the following:
1. Open the liftgate.
Notice:Folding a rear seat with the safety
belts still fastened may cause damage to the
seat or the safety belts. Always unbuckle
the safety belts and return them to their normal
stowed position before folding a rear seat.
2. Fold the seatback
forward onto the
seat cushion
by using the lever
labeled 1. The
seat cannot
be removed unless
the seatback is
folded.
20

{CAUTION:
Never do this.
Here two children are wearing the same
belt. The belt cannot properly spread the
impact forces. In a crash, the two children
can be crushed together and seriously
injured. A belt must be used by only
one person at a time.
Q:What if a child is wearing a lap-shoulder
belt, but the child is so small that the
shoulder belt is very close to the child’s
face or neck?
A:If the child is sitting in a seat next to a
window, move the child toward the center of
the vehicle. Also seeRear Safety Belt
Comfort Guides on page 42. If the child is
sitting in the center rear seat passenger
position, move the child toward the safety belt
buckle. In either case, be sure that the
shoulder belt still is on the child’s shoulder, so
that in a crash the child’s upper body would
have the restraint that belts provide.
47

{CAUTION:
The body structure of a young child is
quite unlike that of an adult or older child,
for whom the safety belts are designed. A
young child’s hip bones are still so small
that the vehicle’s regular safety belt may
not remain low on the hip bones, as it
should. Instead, it may settle up around
the child’s abdomen. In a crash, the belt
would apply force on a body area that is
unprotected by any bony structure. This
alone could cause serious or fatal injuries.
Young children always should be secured
in appropriate child restraints.
Child Restraint Systems
An infant car bed (A), a special bed made for use
in a motor vehicle, is an infant restraint system
designed to restrain or position a child on a
continuous at surface. Make sure that the infant’s
head rests toward the center of the vehicle.
53
