2007 HONDA ACCORD HYBRID Owners Manual

µµ Avoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperature.
Do not immerse the transmitter in
any liquid.
If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer.
Af ter the doors automatically relock,
the security system will be active.
Pressthisbuttonfor
about 1 second to attract attention;
thehornwillsoundandtheexterior
lights will f lash f or about 30 seconds.
To cancel panic mode, press any
other button on the remote
transmitter, or turn the ignition
switch to the ON (II) position.
Press this
button f or about 1 second to open
the trunk. You cannot open the trunk
if the key is in the ignition switch. If you unlock the doors with the
remote transmitter, but do not open
any of the doors within 30 seconds,
the doors automatically relock.
If it takes several pushes on the
button to lock or unlock the doors,
replace the battery as soon as
possible.
Battery type: CR1616To replace the battery:
Remove the screw at the base of
the transmitter with a small
Phillips-head screwdriver.
Separate the transmitter by prying
its middle seam with your
f ingernail.
1.
2.
PA NIC
T RUNK REL EA SE
Replacing the Transmitter
Battery
Remote Transmitter Care
Remote Transmitter
86
SCREW
06/08/08 14:30:41 31SDR620_091

´
As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Inside the transmitter, separate
the inner cover f rom the keypad
by releasing the two tabs on the
cover. Remove the old battery from the
back of the inner cover, and note
the polarity. Make sure the
polarity of the new battery is the
same ( side f acing down), then
insert it into the back of the cover.
An improperly disposed of battery
can hurt the environment.
Always conf irm local regulations
for battery disposal.
Install the parts in reverse order.
3. 4.
5.
Remote Transmitter
Inst rument s and Cont rols
87
BATTERY
TAB
06/08/08 14:30:50 31SDR620_092

Pull up on the trunk release lever
located to the lef t of the driver’s
seat.
You can open the trunk in either of
the following ways:
Press and hold the trunk release
button on the remote transmitter. To close the trunk, press down on
the trunk lid.
See page f or cargo loading and
weight limit inf ormation. Keep the
trunk lid closed at all times while
driving to avoid damaging the lid,
and to prevent exhaust gas from
getting into the interior. See
on page .
Lock the trunk release lever with
your master key to prevent someone
f rom opening the trunk. If they need
to lock/unlock the doors or drive
your vehicle, give them your valet
key.
165
54Carbon
Monoxide Hazard
Trunk
88
Pull
TRUNK RELEASE LEVER MASTER KEY
06/08/08 14:30:59 31SDR620_093

As a saf ety f eature, your vehicle has
a release lever on the trunk latch so
the trunk can be opened f rom the
inside.To open the trunk, push the release
lever to the lef t.
To use the console lid as an armrest,
slide it to the desired position.
Make sure your passenger’s hands
orfingersareawayfromthearmrest
bef ore moving it.
For more inf ormation about child
saf ety, see page . Parents should decide if their
children should be shown how to use
this feature.
40
Emergency T runk Opener A rmrest
Trunk, Armrest
Inst rument s and Cont rols
89
RELEASE LEVER
06/08/08 14:31:09 31SDR620_094

µ
See pages f or important saf ety
inf ormation and warnings about how toproperly position seats and seat-backs. 13
15
The controls f or the adjustable
driver’s power seat are on the
outside edge of the seat bottom. You
can adjust the power seat with the
ignition switch in any position. Make
all seat adjustments bef ore you start
driving.
Moving the long horizontal switch
adjusts the seat bottom in several
directions. The seat bottom adjusts
in the direction you move the switch.
The short vertical switch adjusts the
seat back angle.
Both f ront seats are equipped with
seat heaters. The driver’s seat has
heaters in both the seat-back and
seat cushion, but because of the
sensors f or the side airbag system,
there is no heater in the passenger’s
seat-back. The ignition switch must
be in the ON (II) position to use the
heaters.
If the engine is lef t idling f or an
extended period, do not use the
seat heaters even on the LO
setting. It can weaken the battery,
causing hard starting. Use the HI setting only to heat the
seats quickly, because it draws
large amounts of current f rom the
battery.
Follow these precautions whenever
you use the seat heaters: In the LO setting, the heater runs
continuously. It does not cycle with
temperature changes. In the HI setting, the heater turns off
when the seat gets warm, and turns
back on after the seat’s temperature
drops. After the seat reaches a comfortable
temperature, select LO by pushing
the back of the switch. This will keep
the seat warm.
Adjusting the Driver’s Seat
Seat Heaters
Seat Heaters, Seats
90
06/08/08 14:31:22 31SDR620_095

Moves the seat
f orward and backward.
Moves the f ront of the
seat up or down and
the rear of the seat up
or down.
Raises or lowers the
seat.
Adjusts the seat-back
angle f orward or
backward.To change the lumbar support, move
the lever on the right side of the
seat-back forward or backward.
Keep moving the lever f orward or
backward until you f ind a suitable
position.
To adjust the seat f orward or
backward, pull up on the bar under
the seat cushion’s f ront edge. Move
the seat to the desired position, and
releasethebar.Trytomovetheseat
to make sure it is locked in position.
CONT INUED
Adjusting the Passenger’s Seat
Driver’s L umbar Support
Seats
Inst rument s and Cont rols
91
06/08/08 14:31:34 31SDR620_096

To change the seat-back angle, pull
up on the lever on the outside of the
seat bottom.They are most ef f ective when you
adjust them so the back of the
occupant’s head rests against the
center of the restraint.
The f ront and rear head restraints
adjust f or height. You need both
hands to adjust the restraint. Do not
attempt to adjust it while driving. To
raise it, pull upward. To lower the
restraint, push the release button
and push the restraint down.
Your vehicle has adjustable head
restraints on the f ront seats and on
the outside positions of the rear seat.See page f or important saf ety inf ormation and a warning about how toproperly position the head restraints. 15
Head Restraints
Seats
92
RELEASE BUTTON
06/08/08 14:31:42 31SDR620_097

Turn the ignition switch to the ON
(II) position.Push or pull the adjustment knob
right, left, up, or down to move the
mirror.
Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.
The inside mirror has day and night
positions. The night position reduces
glare f rom headlights behind you.
Flip the tab on the bottom edge of
the mirror to select the day or night
position. Turn the adjustment knob to L
(driver’s side) or R (passenger’s
side).When you f inish, turn the
adjustment knob to the center
(of f ) position. This turns of f the
adjustment knob to keep your
setting.
1.
2. 3.
4.
Adjusting the Power Mirrors
Mirrors
Inst rument s and Cont rols
93
TAB
ADJUSTMENT KNOB
06/08/08 14:31:53 31SDR620_098
