VEHICLE STORAGE
If you are storing your vehicle for more than 21 days, we
recommend that you take the following steps to mini-
mize the drain on your vehicle’s battery:
•Disconnect the Ignition-Off Draw fuse (I.O.D.) fuse
located in the Integrated Power Module, located in the
engine compartment. The I.O.D. cavity includes a
snap-in retainer that allows the fuse to be discon-
nected, without removing it from the fuse block.
•The electronic shift transfer case should be placed in
the 4HI mode and kept in this position to minimize the
battery drain.
•As an alternative to the above steps you may, discon-
nect the negative cables from both batteries.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
NOTE:When reinstalling the IOD fuse push firmly until
fully seated, the gages in the Instrument Cluster will do
a full sweep, when the ignition key is cycled to RUN. This
is a normal condition.
MAINTAINING YOUR VEHICLE 497
7

REPLACEMENT LIGHT BULBS
LIGHT BULBS — Interior Bulb No.
Overhead Console Lights............... TS212-2
Dome Light............................7679
NOTE:For lighted switches, see your dealer for replace-
ment instructions.
All of the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved.LIGHT BULBS — Exterior Bulb No.
Back-Up..............................3057
Center High Mounted Stop Lamp............. 912
Fog Lamp...........................9006LL
Headlamp (Halogen)..................... H13
Side Marker, Park & Turn Signal.........3157NAK
Rear License Plate Lamp................... 168
Rear Cargo Light......................... 912
Tail & Stop............................3057
Cab Clearance Lights...................... 168
Dual Rear Wheel Sidemarker Light............ 168
Dual Rear Wheel Tailgate ID Lights (3)......... 168
498 MAINTAINING YOUR VEHICLE

BULB REPLACEMENT
Headlight (Halogen)/Front Park and Turn Lights
CAUTION!
This is a halogen bulb. Avoid touching the glass
with your fingers. Reduced bulb life will result.
1. Open the hood
2. Remove the two (2) bolts from the front of the head-
light housing.
Front Headlight Housing Bolts
MAINTAINING YOUR VEHICLE 499
7

3. Remove the plug from the inner fender well and
remove the nut through the access hole.
4. Pull the housing out from the fender to allow room to
disconnect the electrical connectors.
Inner Fender Plug
Rear Headlight Housing Nut Access
500 MAINTAINING YOUR VEHICLE

NOTE:For easier removal, pull the headlight assembly
straight forward, applying the greatest amount of force to
the outer edge of the headlight assembly.
5. Unlock and pull connector straight from the base of
the headlight halogen bulb.
6. Twist connector on the side marker/turn signal/park
light bulb
14turn and remove connector and bulb from
housing.
Headlight Removal
Bulb Removal
MAINTAINING YOUR VEHICLE 501
7

7. Remove housing from vehicle with headlight halogen
bulb in housing.
8. Twist the headlight halogen bulb
14turn and remove
headlight bulb from the housing.
9. Replace headlight or side marker/turn signal/park
light bulb. Do not touch the headlight halogen bulb.
10. Reverse procedure for installation of bulbs and hous-
ing.
Fog Lights
1. Reach under the vehicle, unlock and twist connector
counterclockwise14turn and remove connector and bulb
from housing.
502 MAINTAINING YOUR VEHICLE

2. Pull bulb straight from the connector.
3. Reverse procedure for installation of bulbs and hous-
ing.Tail, Stop, Turn and Backup Lights
1. Remove the two (2) screws that pass through the bed
sheetmetal.
Removing the Two (2) Screws
MAINTAINING YOUR VEHICLE 503
7

2. Pull the housing straight out from the body, with a
quick motion, to separate the housing from the body. If
not pulled straight, locators may be damaged.3. Rotate the bulb socket counterclockwise to remove
from the housing.
Pulling Housing From Body
Rotating Bulb Socket From Housing
