2007 DODGE RAM 1500 GAS Owners Manual

WARNING!
To avoid inhaling carbon monoxide, which is deadly,
the exhaust system on vehicles equipped with “Cap
or Slide-In Campers” should extend beyond the
overhanging camper compartment and be free of
leaks.
SAFETY TIPS
Transporting Passengers
This vehicle is designed to carry passengers in the cab
only. For safety reasons, NEVER TRANSPORT PASSEN-
GERS IN THE CARGO AREA.
WARNING!
It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed.
Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
Lock Your Vehicle
Always remove the keys from the ignition and lock all
doors when leaving the vehicle unattended, even in your
own driveway or garage. Try to park your vehicle in a
well-lighted area and never invite theft by leaving ar-
ticles of value exposed.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 217
3

Exhaust Gas
WARNING!
Exhaust gases contain carbon monoxide, a poten-
tially toxic gas that by itself is colorless and odorless.
To avoid inhaling these gases, the following precau-
tions should be observed:
•Do not run the engine in a closed garage or in confined
areas any longer than needed to move your vehicle in
or out of the area.
•If it is necessary to sit in a parked vehicle with the
engine running for more than a short period, adjust
your climate control system to force outside air into
the vehicle. Set the blower at high speed and the
controls in any position except OFF or MAX A/C.
•The best protection against carbon monoxide entry
into the vehicle body is a properly maintained engine
exhaust system.
Be aware of changes in the sound of the exhaust system;
exhaust fumes detected inside the vehicle; or damage to
the underside or rear of the vehicle. Have a competent
mechanic inspect the complete exhaust system and adja-
cent body areas for broken, damaged, deteriorated or
mispositioned parts. Open seams or loose connections
could permit exhaust fumes to seep into the passenger
compartment. In addition, inspect the exhaust system
each time the vehicle is raised for lubrication or oil
change. Replace or adjust as required.
218 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Safety Checks You Should Make Inside The
Vehicle
Heater Defroster Ducts
Inspect the heater defroster ducts for proper operation.
Check for proper air flow through all defroster ducts. If
there are any question regarding the operation of your
heater defroster ducts, have the system checked by an
authorized dealer
Seat Belts
Inspect the belt system periodically, checking for cuts,
frays and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.
Seat belt assemblies must be replaced after an accident if
they have been damaged (bent retractor, torn webbing,
etc.) or if the front airbags have deployed. If there is any
question regarding belt or retractor condition, replace the
belt.
Airbag Light
The light should come on and remain on for 6 to 8
seconds as a bulb check when the ignition switch is first
turned ON. If the light is not lit during starting, see your
authorized dealer. If the light stays on, flickers or comes
on while driving, have the system checked by an autho-
rized dealer. If there is a problem with the airbag light the
seatbelt light will flash.
Safety Checks You Should Make Outside The
Vehicle
Tires
Examine tires for tread wear or uneven wear patterns.
Check for stones, nails, glass or other objects lodged in
the tread.
Inspect for tread cuts or sidewall cracks. Check wheel
nuts for tightness and tires for proper pressure.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 219
3

Lights
Check the operation of all exterior lights. Check turn
signal and high beam indicator lights on the instrument
panel.
Door Latches
Check for positive closing, latching and locking.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
water, oil, or other fluid leaks. Also, if fuel fumes are
detected the cause should be located and corrected.
220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instruments And Controls.................225

Instrument Cluster......................226

Instrument Cluster Description.............227

Electronic Digital Clock..................236
▫Clock Setting Procedure.................236

Radio General Information................237
▫Radio Broadcast Signals.................237
▫Two Types Of Signals..................237
▫Electrical Disturbances..................237▫AM Reception.......................237
▫FM Reception........................237

Sales Code REF — AM/FM/CD (Single Disc)
Radio With Optional Satellite Radio And Hands
Free Phone Capability...................238
▫Operating Instructions - Radio Mode.......238
▫Operation Instructions - CD Mode.........242
▫Operation Instructions - Auxiliary Mode.....244
▫Operating Instructions - Hands Free Phone —
If Equipped.........................2454

▫Operating Instructions - Satellite Radio — If
Equipped...........................246

Sales Code RAQ – AM/FM/CD (6-Disc) Radio
With Optional Satellite Radio, Hands Free Phone,
And Vehicle Entertainment Systems (VES)
Capabilities...........................246
▫Operating Instructions - Radio Mode.......246
▫Operation Instructions -
(CD Mode For CD Audio Play)...........252
▫Load/Eject Button
(CD Mode For CD Audio Play)...........253
▫Notes On Playing MP3 Files.............255
▫Operation Instructions -
(CD Mode For MP3 Audio Play)..........258
▫Load/Eject Button (CD Mode For MP3 Play) . . 258
Sales Code RAK – AM/FM/Cassette/CD (6-Disc)
Radio With Optional Satellite Radio, Hands Free
Phone, Video, MP3, And WMA Capabilities....260
▫Operating Instructions - Radio Mode.......260
▫Operating Instructions — Tape Player.......265
▫Seek Button.........................265
▫Fast Forward (FF).....................265
▫Rewind (RW)........................265
▫Tape Eject...........................265
▫Scan Button.........................266
▫Changing Tape Direction................266
▫Metal Tape Selection...................266
▫Pinch Roller Release...................266
▫Noise Reduction......................266
222 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Operation Instructions -
(CD Mode For CD Audio Play)...........266
▫Load/Eject Button
(CD Mode For CD Audio Play)...........267
▫Notes On Playing MP3 Files.............269
▫Operation Instructions -
(CD Mode For MP3 And WMA Audio Play) . . 272
▫Load/Eject Button
(CD Mode For MP3 And WMA Play).......272

Sales Code REC — AM/FM/CD
(6–Disc) Radio With Navigation System.......274
▫Operating Instructions — Satellite Radio
(If Equipped)........................275
▫Clock Setting Procedure.................275
Video Entertainment System (Sales Code XRV) —
If Equipped...........................275

Satellite Radio — If Equipped..............275
▫System Activation.....................276
▫Electronic Serial Number/Sirius Identification
Number (ESN/SID)....................276
▫Selecting Satellite Mode In REF, RAQ,
And RAK Radios.....................277
▫Selecting a Channel....................278
▫Storing And Selecting Pre-Set Channels......278
▫Using The PTY (Program Type) Button
(If Equipped)........................278
▫PTY ButtonScan.....................278
▫PTY ButtonSeek.....................279
UNDERSTANDING YOUR INSTRUMENT PANEL 223
4

▫Satellite Antenna......................279
▫Reception Quality.....................279

Remote Sound System Controls — If Equipped . . 280
▫Radio Operation......................280
▫Tape Player.........................281
▫CD Player..........................281

Cassette Tape And Player Maintenance.......281

Compact Disc Maintenance................282

Radio Operation And Cellular Phones........283
Climate Controls.......................283
▫Heater Only — If Equipped..............284
▫Air Conditioning And Heating —
If Equipped.........................286
▫Air Conditioning With Dual Zone Temperature
Control — If Equipped.................289
▫Operating Tips.......................293
▫Operating Tips Chart...................296
224 UNDERSTANDING YOUR INSTRUMENT PANEL
