4. Pull bulb straight out of socket. 5. Reverse Procedure to install bulb and housing. Place
the two raised blocks passed the body.
Pulling Bulb From Socket
Sliding Raised Blocks Past Body
MAINTAINING YOUR VEHICLE 505
7

Center High-Mounted Stoplight (CHMSL) With
Cargo Light
1. Remove the two (2) screws holding the housing/lens
to the body as shown.2. Separate the connector holding the housing and wir-
ing harness to the body.
3. Turn desired bulb socket
14turn and remove socket
and bulb from housing.
506 MAINTAINING YOUR VEHICLE

4. Pull desired bulb straight from the socket.
•Outside Bulbs: Cargo Lamps
•Inside Bulb: Center High Mount Stop Lamp
5. Reverse procedure for installation of bulbs and hous-
ing.
Cab Top Clearance Lights — If Equipped
1. Remove the two screws from the top of the light.
MAINTAINING YOUR VEHICLE 507
7

2. Rotate the socket14turn and pull it from the light
assembly.3. Pull the bulb straight from it’s socket and replace.
508 MAINTAINING YOUR VEHICLE

Tailgate ID Lights (Dual Rear Wheels) — If
Equipped
1. Remove the two screws and housing and access the
bulb sockets from the rear.
MAINTAINING YOUR VEHICLE 509
7

2. Turn socket14turn counterclockwise to access the
bulb.
3. Pull bulb straight out from socket.
4. Reverse procedure for installation of bulbs and hous-
ing.Rear Light Bar ID Marker (Dual Rear Wheel) – If
Equipped
1. Loosen the two screws and the housing to gain access
to the bulb sockets.
2. Turn the socket 1/4 turn counterclockwise to access
the bulb.
510 MAINTAINING YOUR VEHICLE

3. Pull the bulb straight out from the socket.
4. Reverse procedure for installation of bulbs and hous-
ing.
Side Marker Lights (Dual Rear Wheels)
1. Push rearward on the side marker light assembly.
2. Pull the entire assembly from the fender.
3. Turn socket
14turn counterclockwise and remove from
assembly to access the bulb.
4. Pull bulb straight out from socket.
5. Reverse procedure for installation of bulbs and hous-
ing.
MAINTAINING YOUR VEHICLE 511
7

FLUIDS AND CAPACITIES
U.S. Metric
Fuel (Approximate)
3.7L/4.7L
5.7L
1500 Shortbed Models 26 gal. 98L
1500 Longbed Models 35 gal. 132L
1500 Shortbed Models 34 gal. 128L
2500 Shortbed Models 34 gal. 128L
2500 Longbed Models 35 gal. 132L
3500 Shortbed Models 34 gal. 128L
3500 Longbed Models 35 gal. 132L
Engine Oil (with filter)
3.7L Engine V-6 (SAE 5W-30, API Certified) 5.0 qts. 4.7L
4.7L Engine V-8 (SAE 5W-30, API Certified) 6.0 qts. 5.7L
