3. Pull up on the seatback recliner lever located on the
outboard side of the seat, to return the seatback to its full
upright position.
4. Close the storage bin cover and adjust the head
restraint to the desired position.To Fold Third Row Seats
1. Lower the head restraint to its full down position.
2. Pull release strap marked “1” located on the rear of the
seat to lower the seatback.
Second Row Seatback Release Lever
Third Row Seatback Release Strap 1
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129
3

3. Pull release strap marked “2” to release the anchors. 4. Pull release strap marked “3” and tumble the seat
rearward into the storage bin.
Third Row Seatback Release Strap 2
Third Row Seat Release Strap 3
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To Unfold Third Row Seats
1. Pull up on the assist strap to lift the seat out of the
storage bin and push the seat forward until the anchors
latch.2. Pull release strap marked “1” to unlock the recliner.
3. Pull release strap marked “3” to return the seatback to
its full upright position.
4. Adjust the head restraint to the desired position.
Third Row Seatback Lift Assist Strap
Third Row Seat Release Strap 3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131
3

WARNING!
In a collision, you or others in your vehicle could be
injured if seats are not properly latched to their floor
attachments. Always be sure the seats are fully
latched.
Tailgate Mode
1. Pull release strap “2”, then pull release strap “3” to
rotate the entire seat rearward.
2. To restore the seat to its upright position, lift up on the
seatback and push forward until the anchors latch.
Tailgate Positioning Release Straps 2 & 3
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
To avoid serious injury or death, never operate the
vehicle with occupants in the third row seat, while in
the tailgate mode.
Easy Access Seating
The passenger’s and driver’s side second row seats can
be tilted forward for easy access to the third row seat or
rear cargo area.
To tilt the seat on vehicles equipped with quad seats, pull
up on the release handle located on the outboard side of
the seat and tilt the seat fully forward. To return the seat,
lower the seat and ensure that it is fully latched.
Tilting Second Row Quad Seat
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133
3

To tilt the seat on vehicles equipped with Stow ’n Go
seating, pull forward on the release strap located on the
front of the seat between the seat back and seat cushion
and tilt the seat fully forward. To return the seat, lower
the seat and ensure that it is fully latched.WARNING!
In the event of a collision you could be injured if the
seat is not fully latched.
Middle Quad Fold & Tumble Seat Removal
1. Remove any obstructions from the floor in front of the
seat.
2. Lower the head restraint to its full downward position
and ensure that the cupholder is closed.
Tilting Second Row Stow ’n Go Seat
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Pull up on the seatback release lever located on the
outboard side of the seat and fold the seatback down. If
the head restraint contacts the rear of the front seat, move
the front seat forward on its tracks.4. Pull up on the release handle and tumble the seat fully
forward.
Seatback Release Lever
Seat Release Handle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135
3

5. Pull the release bar located at the bottom front edge of
the seat to disengage the front attachments.
6. The seat assembly can now be removed from the
vehicle and moved on its Easy OutRollers.To reinstall the seat, remove any obstructions from the
floor in front of the seat and ensure the head restraint is
in its full downward position. Align the seat in the floor
tracks and tilt the seat forward to engage the front floor
attachments, then tilt the seat rearward and push down
to engage the rear attachments. Pull the seatback release
lever to return the seatback to its full upright position.
Ensure that the seatback is fully latched in the upright
position.
WARNING!
In a collision, you or others in your vehicle could be
injured if seats are not properly latched to their floor
attachments. Always be sure the seats are fully
latched.
Release Bar Location
