Cavity Cartridge
FuseDescription
F28 40 Amp
GreenPower Windows
F30 40 Amp
GreenHeadlight Washers (Export
Only)
F31 40 Amp
GreenPower Sliding Door
F32 40 Amp
GreenPower Liftgate
Cavity Mini Fuse Description
F1 20 Amp Yel-
lowFog Lights
F2 15 Amp Blue Left Park/Tail Light
F3 15 Amp Blue Right Park/Tail Light
F5 20 Amp Yel-
lowRDO/IP Ignition
Cavity Mini Fuse Description
F6 20 Amp Yel-
low12 Volt Out Ignition or
Battery
F8 20 Amp Yel-
lowHorn
F11 20 Amp Yel-
lowEWD/ Rear Wiper
F12 25 Amp
NaturalRear Blower
F14 20 Amp Yel-
lowIgnition Off Draw (IOD)
F15 20 Amp Yel-
lowElectronic Automatic
Transaxle (EATX) Battery
F15 25 Amp
NaturalASD
F17 20 Amp Yel-
lowFuel Pump
F18 15 Amp Blue A/C Clutch
MAINTAINING YOUR VEHICLE 449
7

Cavity Mini Fuse Description
F21 25 Amp
NaturalAnti-Lock Brake System
(ABS) Module
F23 10 Amp Red Ignition Switch
F24 20 Amp Yel-
lowHazard
F26 20 Amp Yel-
lowStop Lamp
F33 15 Amp Blue Front/Rear Washer
20 Amp Yel-
lowSpare (IOD)CAUTION!
•When installing the Integrated Power Module
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Integrated Power
Module, and possibly result in a electrical system
failure.
•When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse contin-
ues to blow, it indicates a problem in the circuit
that must be corrected.
The Heated Mirrors, Lower Instrument Panel Power
Outlet and Removable Floor Console, when in the front
450 MAINTAINING YOUR VEHICLE

position are fused with self resetting fuses that are only
serviceable by an authorized dealer. The power seats are
fused by a 30 Amp circuit breaker located under the
driver’s seat. The Power Windows are fused by a 25 Amp
circuit breaker located under the instrument panel near
the steering column. If you experience temporary or
permanent loss of these systems see your authorized
dealer for service.
VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
•Remove the 20 Amp mini fuse in the Integrated Power
Module labeled Ignition-Off Draw (IOD).
•Or, disconnect the negative cable from the battery.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run theair conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
REPLACEMENT LIGHT BULBS
LIGHT BULBS — Interior Bulb Number
Center & Rear Dome Light.................. 578
Center & Rear Reading Lights............... 578
Front Door Courtesy Light.................. 578
Front Header Reading Lights — If Equipped..... 578
Instrument Cluster Lights.................PC74
Liftgate Light(s).......................... 578
Overhead Console Reading Lights..........PC579
Removable Console Light — If Equipped....... 194
Visor Vanity Lights....................6501966
MAINTAINING YOUR VEHICLE 451
7

NOTE:For lighted switches, see your dealer for replace-
ment instructions.
All of the interior bulbs are glass wedge base or glass
cartridge types. Aluminum base bulbs are not approved
and should not be used for replacement.
LIGHT BULBS — Exterior Bulb Number
Back-up, Tail, Stop, Turn Signal, & Sidemarker. . . 3057
Center High-Mounted Stop Light............. 921
Fog Light — If Equipped..................9145
Front Side marker, Park/Turn Signal........3457AK
Headlight.............................9007
Headlight (Long Wheel Base)............... H13
License................................ 168BULB REPLACEMENT
Headlights
1. Remove the three screws securing the headlight mod-
ule.
452 MAINTAINING YOUR VEHICLE

2. Turn the bulb socket retaining ring or the bulb assem-
bly counterclockwise.
3. Disconnect the electrical connector and replace the
bulb.NOTE:On some vehicles it may be necessary to slide
the red release lock rearward and push forward on the
connector while depressing the release tab.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
MAINTAINING YOUR VEHICLE 453
7

Front Park/Turn Signal and Sidemarker Lights
1. Remove the three screws securing the headlight mod-
ule.2. Twist the turn signal socket to remove from the
headlight module and pull bulb from socket.
3. Replace bulb, reinstall socket and then reinstall the
headlight module.
454 MAINTAINING YOUR VEHICLE

Fog Lights
1. Reach behind the front fascia from under the vehicle.
2. Twist the front fog light bulb to remove from the fog
light housing.
3. Disconnect the electrical connector and replace the
bulb.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Rear Tail, Stop, Turn Signal, Side Marker and
Back-up Lights
1. Raise the liftgate.
2. Remove the two tail light assembly push-in type
fasteners, by prying under the fastener head with a large
flat screwdriver.
MAINTAINING YOUR VEHICLE 455
7

3. Squeeze the socket assembly tabs to remove it from the
housing.
4. Pull the bulb to remove it from the socket.
5. Replace the bulb, reinstall the socket, and reattach the
light assembly.Center High Mounted Stop Light (CHMSL)
1. Remove the two screws securing the CHMSL.
2. Twist the bulb socket to remove from the CHMSL
housing.
3. Pull the bulb out of the socket.
4. Replace the bulb, reinstall the socket and reattach the
CHMSL.
