2007 CHRYSLER TOWN AND COUNTRY Owners Manual

SLIDING SIDE DOOR
The sliding door may be opened from the inside or the
outside. Pull out on the outside handle to open the
sliding door from the outside. To open the sliding door
from the inside, press the button on the grab handle and
open the door.To keep your door operating properly, observe the fol-
lowing guidelines:
•Always open the door smoothly.
•Avoid high impacts against the door stop when open-
ing the door. This is very important when your vehicle
is parked on an incline as the door will slide faster in
the downhill direction.
•There is a hold-open latch that is activated when the
sliding door is fully opened. This latch will keep your
sliding door open on any incline. To close the sliding
door after the hold-open latch is activated, you must
push the button on the inside grab handle or pull out
on the outside sliding door handle.
•Use the grab handle on the inside of the sliding door to
assist you in closing and securing the door.
Always make sure that the sliding door is fully latched
any time the vehicle is in motion.
Sliding Door Hardware
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33
2

NOTE:The driver’s side sliding door cannot be opened
while the fuel door is open. This feature operates only
when the sliding door is fully closed prior to opening the
fuel door.
Sliding Door Open Flash
When the sliding door(s) are opened, the left and right
exterior hazard lights will flash for 12 seconds to alert
other drivers in the area that passenger(s) could be
entering or exiting the vehicle.
The Sliding Door Open Flash can be enabled or disabled
by performing the following procedure:
1. Place the key in the ignition switch.
2. Cycle the ignition switch ON/OFF four times ending
in the OFF position. (do not start the engine)
3. Within 10 seconds of the final cycle, press the hazard
switch.4. A single chime will sound to signify that you have
successfully completed the programming.
You can turn the feature back on by repeating the above
mentioned procedure or by performing the procedure in
the Electronic Vehicle Information Center (EVIC), Cus-
tomer Programmable Features section on vehicles so
equipped.
Power Sliding Door — If Equipped
NOTE:The power sliding door must be unlocked before
the switches located on the trim panel, just in front of the
power sliding door will operate.
The power sliding door may be opened manually or by
using the buttons on the remote keyless entry transmitter.
Press the buttons on the remote keyless entry transmitter
twice within five seconds, to open a power sliding door.
Once the door is fully open, pressing the button twice
within five seconds a second time will close the door.
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The power sliding door may also be opened by pressing
the switches on the overhead console or the switch
located on the trim panel just in front of the sliding door.
To keep your door operating properly, observe the fol-
lowing guidelines.
•Always open the door smoothly.
•Avoid high impacts against the door stop when open-
ing the door manually. This is very important when
your vehicle is parked on an incline as the door will
slide faster in the downhill direction.
•There is a hold-open latch that is activated when the
sliding door is fully opened. This latch will keep your
sliding door open on any incline. To close the power
sliding door after the hold-open latch is activated, you
must press any one of the power sliding door
switches, push the button on the inside grab handle or
pull out on the outside sliding door handle.There are power sliding door switches located on the
trim panel just in front of the power sliding door for the
rear seat passengers. Pressing the switch once will open
the power sliding door, once the door is fully open
pressing the switch a second time will close the door.
Power Sliding Door Switch
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35
2

If the inside or outside door handles are used while the
power sliding door is activated, the power sliding door
feature will be canceled and the door must be opened or
closed manually.
To avoid unintentional operation of the power sliding
door from the rear seats, press the On /Off button located
in the overhead console to disable the switches for the
rear seat passengers.
NOTE:
•If anything obstructs the power sliding door while it is
closing or opening, the door will automatically reverse
to the closed or open position, provided it meets
sufficient resistance.
•The driver’s side sliding door cannot be opened while
the fuel door is open. This feature operates only when
the sliding door is fully closed prior to opening the
fuel door.
•If the power sliding door is not in the full open or close
position, it will fully open when a power sliding door
switch is pressed. To close the door, wait until it is fully
open and then press the switch again.
•The power sliding door switches will not operate if the
vehicle is in gear or the vehicle speed is above 0 mph
(0 km/h).
•If the power sliding door encounters multiple obstruc-
tions within the same cycle, the system will automati-
cally stop and must be opened or closed manually.
WARNING!
You or others could be injured if caught in the path
of the sliding door. Make sure the door path is clear
before closing the door.
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Child Protection Door Lock
To provide a safer environment for small children riding
in the rear seats, the sliding doors are equipped with a
child protection door lock system.
NOTE:When the child lock system is engaged, the door
can be opened only by using the outside door handle
even though the inside door lock is in the unlocked
position.
To Engage the Child Protection Door Lock
To activate the system:
1. Open the sliding door.
2. Insert the tip of the vehicle’s ignition key (or any alike
item) into the child lock control and slide it sidewards.3. Repeat Steps 1 and 2 on the opposite sliding door.
NOTE:
•After engaging the child protection door lock system,
always test the door from the inside to make certain it
is in the desired position.
Child Lock Control
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37
2

•When the child lock system is engaged the door can be
opened only by using the outside door handle, remote
keyless entry transmitter, switches on the overhead
console or the switches located on the trim panel just
in front of the power sliding door, even though the
inside door lock is in the unlocked position.
•The power sliding door will operate from the switches
located on the trim panel just in front of the power
sliding door, regardless of the child lock lever position.
To avoid unintentional operation of the power slid-
ing door from the rear seats, press the button located
in the overhead console to disable the switches for
the rear seat passengers.
WARNING!
To avoid trapping anyone in the vehicle in a colli-
sion. Remember that the sliding doors can only be
opened from the outside door handle or the switches
located on the trim panel just in front of the power
sliding door when the child protection locks are
engaged.
To Disengage the Child Protection Door Lock
1. Open the sliding door.
2. Insert the tip of the vehicle’s ignition key (or any alike
item) into the child lock control and slide it sidewards.
3. Repeat Steps 1 and 2 on the opposite sliding door (if
equipped).
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NOTE:
•After setting the child protection door lock system,
always test the door from the inside to make certain it
is in the desired position.
•The power sliding door switches will not operate if the
vehicle is in gear or the vehicle speed is above 0 mph
(0 km/h).
•The power sliding door will operate from the remote
keyless entry transmitter, if the vehicle is in Park,
regardless of the child lock lever position.
LIFTGATE
NOTE:The key that is used to start the vehicle is also
used to lock or unlock the doors and open the liftgate.
To open the liftgate, insert the key into the lock and turn
to the right. On vehicles equipped with power locks the
liftgate can also be unlocked using the remote keyless
entry or by activating the power door lock switches
located on the front doors.
Once unlocked, on vehicles equipped with power locks,
the liftgate can be opened or closed without using the
key. To open the liftgate, depress the liftgate release
switch located on the underside of the license plate bar
and pull the liftgate open with one fluid motion.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39
2

If the liftgate is locked and is not equipped with a
powered liftgate, pressing the button on the remote
keyless entry transmitter will result in the liftgate becom-
ing unlocked for 30 seconds allowing you to manually
access the liftgate area.NOTE:On vehicles without power locks, the liftgate can
only be opened using the vehicle keys. The key must be
held in the unlocked position for the liftgate to open.
Power Liftgate — If Equipped
The power liftgate may be opened manually or by using
the button on the remote keyless entry transmitter. Press
the button on the remote keyless entry transmitter twice
within five seconds, to open the power liftgate. Once the
liftgate is fully open, pressing the button twice within
five seconds a second time will close the liftgate.
The power liftgate may also be opened by pressing the
button located on the overhead console.
Liftgate Handle
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
