2007 CHRYSLER 300 SRT Owners Manual

LOAD LEVELING SYSTEM
The automatic load leveling system will provide a level-
riding vehicle under most passenger and cargo loading
conditions.
A hydraulic pump contained within the shock absorbers
raises the rear of the vehicle to the correct height. It takes
approximately 1 mile (1.6 km) of driving for the leveling
to complete depending on road surface conditions.If the leveled vehicle is not moved for approximately 15
hours, the leveling system will bleed itself down. The
vehicle must be driven to reset the system.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129
3

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instrument Panel And Controls............134

Premium Instrument Cluster..............135

Instrument Cluster Descriptions...........136

Electronic Vehicle Information Center
(EVIC)
..............................144
▫Electronic Vehicle Information Center (EVIC)
Displays............................145
▫Trip Functions.......................147
▫Compass Display.....................149
▫Telephone — If Equipped...............150
▫Navigation — If Equipped...............152▫System Warnings
(Customer Information Features)..........153
▫Personal Settings
(Customer Programmable Features)........153
Setting The Analog Clock................157

Radio General Information...............158
▫Radio Broadcast Signals.................158
▫Two Types Of Signals..................158
▫Electrical Disturbances..................158
▫AM Reception.......................158
▫FM Reception........................158
4

Sales Code RAK – AM/FM/Cassette/CD (6-Disc)
Radio With Optional Satellite Radio, Hands Free
Phone, Video, MP3, And WMA Capabilities
. . 159
▫Operating Instructions - Radio Mode.......159
▫Operating Instructions — Tape Player.......162
▫Seek Button.........................163
▫Fast Forward (FF).....................163
▫Rewind (RW)........................163
▫TapeEject...........................163
▫Scan Button.........................163
▫Changing Tape Direction................163
▫Metal Tape Selection...................163
▫Pinch Roller Release...................163
▫Noise Reduction......................164
▫Operation Instructions - (CD Mode For CD
Audio Play).........................164▫Load/Eject Button (CD Mode For CD
Audio Play).........................165
▫NotesOnPlayingMP3Files .............166
▫Operation Instructions - (CD Mode For MP3
And WMA Audio Play).................168
▫Load/Eject Button (CD Mode For MP3 And
WMAPlay) .........................168

Sales Code REC — AM/FM/CD (6–Disc)
Radio With Navigation System
............170
▫Operating Instructions — Satellite Radio (If
Equipped)..........................171
▫REC Setting The Clock.................171
▫Audio Clock Display...................173

Video Entertainment System (Sales Code XRV) —
If Equipped
..........................174
▫Kicker Mobile Surround (Kms1)...........175

Satellite Radio — If Equipped.............176
▫System Activation.....................176
132 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Electronic Serial Number/Sirius Identification
Number (ESN/SID)....................176
▫Selecting Satellite Mode In REF, RAQ, And
RAK Radios.........................177
▫Selecting a Channel....................177
▫Storing And Selecting Pre-Set Channels......178
▫Using The PTY (Program Type) Button (If
Equipped)..........................178
▫PTY ButtonScan.....................178
▫PTY ButtonSeek.....................178
▫Satellite Antenna......................179
▫Reception Quality.....................179

Remote Sound System Controls...........179▫Radio Operation......................180
▫Tape Player Operation..................181
▫CD Player Operation...................181
▫Satellite Radio Operation................181

Cassette Tape And Player Maintenance......181

CD/DVD Disc Maintenance..............182

Radio Operation And Cellular Phones.......183

Climate Controls......................183
▫Automatic Temperature Control...........183
▫Operating Tips.......................188

Rear Window Features..................191
▫Electric Rear Window Defroster...........191
UNDERSTANDING YOUR INSTRUMENT PANEL 133
4

INSTRUMENT PANEL AND CONTROLS
1 — Air Outlet 7 — Radio 13 — Ignition Switch
2 — Instrument Cluster 8 — Climate Control 14 — Hood Release
3 — Hazard Switch 9 — Heated Seat Switch* 15 — Trunk Release Switch
4 — Analog Clock 10 — Power Outlet 16 — Headlight Switch
5—
Electronic Stability Program Off Button* /
Traction Control System Off Button*11 — Ash Tray* * If Equipped
6 — Glove Box 12 — Storage Compartment* 134 UNDERSTANDING YOUR INSTRUMENT PANEL

PREMIUM INSTRUMENT CLUSTER
UNDERSTANDING YOUR INSTRUMENT PANEL 135
4

INSTRUMENT CLUSTER DESCRIPTIONS
1. Electronic Speed Control Indicator Light — If
Equipped
This light will turn on when the electronic
speed control is ON. (See page 109 for more
information.)
2. Low Fuel Indicator Light
This light will turn on and a single chime will
sound when the fuel level drops to 1/8 tank. (See
page 249 for more information.)
3. Front Fog Light Indicator
This light will turn on when the front fog lights
are ON. (See page 98 for more information.)
4. Turn Signal Indicators
The arrow will flash with the exterior turn signal
when the turn signal lever is operated.
NOTE:
A continuous chime will sound if the vehicle is
driven more than 1 mile (1.6 km) with either turn signal
on.
NOTE:Check for a defective outside light bulb if either
indicator flashes at a rapid rate. (See page 98 for more
information.)
5. Speedometer
Indicates vehicle speed.
6. Electronic Vehicle Information Center Display
This display shows the Electronic Vehicle Information
Center (EVIC) messages when the appropriate conditions
exist. (See page 144 for more information.)
Loose Fuel Filler Cap
If the vehicle diagnostic system determines that the fuel
filler cap is loose, improperly installed, or damaged, a
“Check Gascap” message will display in the Electronic
Vehicle Information Center (EVIC). Tighten the fuel filler
cap properly and press the odometer reset button to turn
off the message. If the problem continues, the message
will appear the next time the vehicle is started.
A loose, improperly installed, or damaged fuel filler cap
may also turn on the Malfunction Indicator Light (MIL).
(See page 272 for more information.)
136 UNDERSTANDING YOUR INSTRUMENT PANEL
