2007 CHRYSLER 300 SRT Owners Manual

STARTING AND OPERATING
CONTENTS

Starting Procedures....................196
▫Automatic Transmission................197
▫Normal Starting......................197
▫Extremely Cold Weather
(Below
20°F Or
29°C)................197
▫If Engine Fails To Start.................197
▫After Starting........................198

Engine Block Heater — If Equipped........199

Automatic Transmission.................199
▫Automatic Transmission —
General Information...................200
▫Brake/Transmission Shift Interlock System . . . 202▫5 Speed Automatic Transmission..........203

AutoStick...........................207
▫AutoStickOperation..................207
▫AutoStickGeneral Information...........208

Driving On Slippery Surfaces.............209
▫Acceleration.........................209
▫Traction............................209

Parking Brake.........................210

Brake System.........................211
▫Anti-Lock Brake System................211

Power Steering........................213
5

Electronic Brake Control System...........214
▫ABS (Anti-Lock Brake System)............214
▫TCS (Traction Control System)............215
▫BAS (Brake Assist System)...............215
▫ESP (Electronic Stability Program).........216
▫Synchronizing ESP....................219
▫ESP/BAS Malfunction Indicator Light And
ESP/TCS Indicator Light................219

Tire Safety Information..................220
▫Tire Markings........................220
▫Tire Identification Number (TIN)..........224
▫Tire Loading And Tire Pressure...........225

Tires — General Information..............229
▫Tire Pressure.........................229
▫Tire Inflation Pressures.................230
▫Radial-Ply Tires......................232▫Tire Spinning........................232
▫Tread Wear Indicators..................233
▫LifeOfTire .........................233
▫Replacement Tires.....................234
▫Alignment And Balance.................235

Tire Chains...........................235

Snow Tires...........................236

Tire Rotation Recommendations...........237
▫Tire Rotation — Standard Tires............238
▫Tire Rotation — All Season Tires..........238

Tire Pressure Monitor System (TPMS) — If
Equipped
............................239
▫Base System — If Equipped..............241
▫Premium System — If Equipped..........242
▫General Information...................245

Fuel Requirements.....................246
194 STARTING AND OPERATING

▫6.1L Engine.........................246
▫Reformulated Gasoline.................246
▫Gasoline/Oxygenate Blends..............247
▫MMT In Gasoline.....................247
▫Materials Added To Fuel................247
▫Fuel System Cautions..................248
▫Carbon Monoxide Warnings..............248

Adding Fuel..........................249
▫Fuel Filler Cap (Gas Cap)...............249
▫Loose Fuel Filler Cap Message............251

Vehicle Loading.......................252▫Vehicle Certification Label...............252
▫Gross Vehicle Weight Rating (GVWR).......252
▫Gross Axle Weight Rating (GAWR).........252
▫Overloading.........................253
▫Loading............................253

Trailer Towing........................254

Recreational Towing
(Behind Motorhome, Etc.)
................254
▫Towing This Vehicle Behind Another Vehicle
(Flat Towing With All Four Wheels On The
Ground)............................254

Ground Clearance.....................254
STARTING AND OPERATING 195
5

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust the
inside and outside mirrors, fasten your seat belt, and if
present, instruct all other occupants to buckle their seat
belts.WARNING!
•Never leave children alone in a vehicle. Leaving
children in a vehicle unattended is dangerous for
a number of reasons. A child or others could be
seriously or fatally injured. Don’t leave the keys
in the ignition. A child could operate power
windows, other controls, or move the vehicle.
•Do not leave animals or children inside parked
vehicles in hot weather; interior heat build up
may cause serious injury or death.
•Be sure to turn off the engine if you want to rest or
sleep in your car. Accidents can be caused by
inadvertently moving the gear selection lever or
by pressing the accelerator pedal. This may cause
excessive heat in the exhaust system, resulting in
overheating and vehicle fire, which may cause
serious or fatal injuries.
196 STARTING AND OPERATING

Automatic Transmission
The gear selector must be in the NEUTRAL or PARK
position before you can start the engine. Apply the brakes
before shifting into any driving gear.
Normal Starting
Normal Starting of either a cold or a warm engine is
obtained without pumping or depressing the accelerator
pedal. Turn the key to the “START” position and release
when the engine starts. If the engine has not started
within 3 seconds, slightly depress the accelerator pedal
while continuing to crank. If the engine fails to start
within 15 seconds, turn the key to the “LOCK” position,
wait 10 to 15 seconds, then repeat the normal starting
procedure.
Extremely Cold Weather (below
20°F or
29°C)
To insure reliable starting at these temperatures, use of an
externally powered electric engine block heater (available
from your dealer) is recommended.
If Engine Fails To Start
If the engine fails to start after you have followed the
“NORMAL STARTING” procedure, it may be flooded.
Push the accelerator pedal all the way to the floor and
hold it there while cranking the engine. This should clear
any excess fuel in case the engine is flooded.
CAUTION!
To prevent damage to the starter, do not crank the
engine for more than 15 seconds at a time. Wait 10 to
15 seconds before trying again.
STARTING AND OPERATING 197
5

WARNING!
•Never pour fuel or other flammable liquid into
the throttle body air inlet opening in an attempt to
start the vehicle. This could result in flash fire
causing serious personal injury.
•Do not attempt to push or tow your vehicle to get
it started. Vehicles equipped with an automatic
transmission cannot be started this way. Un-
burned fuel could enter the catalytic converter and
once the engine has started, ignite and damage the
converter and vehicle. If the vehicle has a dis-
charged battery, booster cables may be used to
obtain a start from a booster battery or the battery
in another vehicle. This type of start can be
dangerous if done improperly. See section 6 of
this manual for the proper jump-starting proce-
dures and follow them carefully.
If the engine is flooded, it may start to run, but not have
enough power to continue running when the key is
released. If this occurs, continue cranking up to 15
seconds with the accelerator pedal pushed all the way to
the floor. Release the accelerator pedal and the key once
the engine is running smoothly. Do not overspeed the
engine.
If the engine shows no sign of starting after two 15-
second periods of cranking with the accelerator pedal
held to the floor, the “NORMAL STARTING” procedure
should be repeated.
After Starting
The idle speed is controlled automatically and it will
decrease as the engine warms up.
198 STARTING AND OPERATING

ENGINE BLOCK HEATER — IF EQUIPPED
The engine block heater warms engine coolant and
permits quicker starts in cold weather. Connect the cord
to a standard 110-115 volt AC electrical outlet with a
grounded, three-wire extension cord.
The engine block heater cord is routed under the hood on
the driver side of the vehicle. It has a removable cap that
is located on the driver side of the Integrated Power
Module.
WARNING!
Remember to disconnect the cord before driving.
Damage to the 110-115 volt electrical cord could
cause electrocution.
AUTOMATIC TRANSMISSION
CAUTION!
Damage to the transmission may occur if the follow-
ing precautions are not observed:
•Shift into PARK only after the vehicle has come to
a complete stop.
•Shift into or out of REVERSE only after the
vehicle has come to a complete stop and the
engine is at idle speed.
•Do not shift from REVERSE, PARK, or NEUTRAL
into any forward gear when the engine is above
idle speed.
•Before shifting into any gear, make sure your foot
is firmly on the brake pedal.
STARTING AND OPERATING 199
5

WARNING!
It is dangerous to shift the selector lever out of “P” or
“N” if the engine speed is higher than idle speed. If
your foot is not firmly on the brake pedal, the
vehicle could accelerate quickly forward or in re-
verse. You could lose control of the vehicle and hit
someone or something. Only shift into gear when
the engine is idling normally and when your right
foot is firmly on the brake pedal.
Automatic Transmission — General Information
The automatic transmission selects individual gears au-
tomatically, dependent upon:
•Altitude
•Vehicle Loading
•Driving Style
•Selector lever position
•Accelerator position
•Vehicle speedThe gear shifting process is continuously adapted, de-
pendent on the driving style, the driving situation and
the road characteristics.
NOTE:
•
After selecting any driving position, wait a moment to
allow the gear to engage fully before accelerating,
especially when the engine is cold.
•If there is a need to restart the engine, be sure to cycle
the key to the LOCK position before restarting. Trans-
mission engagement may be delayed up to 10 seconds
after restart if the key is not cycled to the LOCK
position first.
•The electronically controlled transmission provides a
precise shift schedule. The transmission electronics are
self-calibrating. Therefore, the first few shifts on a new
vehicle may be somewhat abrupt or soft until after the
break-in period. This is a normal condition, and pre-
cision shifts will develop within a few shift cycles.
200 STARTING AND OPERATING
