2007 CHEVROLET UPLANDER Owners Manual

Read the instructions completely before attempting
to program the Universal Home Remote.
Because of the steps involved, it may be helpful to
have another person available to assist you in
the programming steps.
Keep the original hand-held transmitter for use in
other vehicles as well as for future Universal
Home Remote programming. It is also
recommended that upon the sale of the vehicle,
the programmed Universal Home Remote buttons
should be erased for security purposes. See
“Erasing Universal Home Remote Buttons” later in
this section or, for assistance, seeCustomer
Assistance Offices on page 560.
Be sure that people and objects are clear of the
garage door or gate operator you are
programming. When programming a garage door,
it is advised to park outside of the garage.
It is recommended that a new battery be installed
in your hand-held transmitter for quicker and
more accurate transmission of the radio-frequency
signal.Programming Universal Home Remote
Follow these steps to program up to three
channels:
1. Press and hold down the two outside
Universal Home Remote buttons, releasing
only when the Universal Home Remote
indicator light begins to ash, after
20 seconds. Do not hold down the buttons for
longer than 30 seconds and do not repeat
this step to program a second and/or
third hand-held transmitter to the remaining
two Universal Home Remote buttons.
2. Position the end of your hand-held transmitter
about 1 to 3 inches (3 to 8 cm) away from the
Universal Home Remote buttons while
keeping the indicator light in view.
3. Simultaneously press and hold both the
desired Universal Home Remote button
and the hand-held transmitter button. Do not
release the buttons until Step 4 has been
completed.
Some entry gates and garage door openers
may require you to substitute Step 3 with
the procedure noted in “Gate Operator and
Canadian Programming” later in this section.
177

4. The indicator light will ash slowly at rst and
then rapidly after Universal Home Remote
successfully receives the frequency signal
from the hand-held transmitter. Release both
buttons.
5. Press and hold the newly-trained Universal
Home Remote button and observe the
indicator light.
If the indicator light stays on continuously,
programming is complete and your device
should activate when the Universal Home
Remote button is pressed and released.
To program the remaining two Universal Home
Remote buttons, begin with Step 2 under
“Programming Universal Home Remote.” Do
not repeat Step 1 as this will erase all of
the programmed channels.
If the indicator light blinks rapidly for
two seconds and then turns to a constant light,
continue with Steps 6 through 8 following to
complete the programming of a rolling-code
device, most commonly, a garage door opener.6. Locate in the garage, the garage door opener
receiver (motor-head unit). Locate the “Learn”
or “Smart” button. This can usually be
found where the hanging antenna wire is
attached to the motor-head unit.
7. Firmly press and release the “Learn” or
“Smart” button. The name and color of
the button may vary by manufacturer.
You will have 30 seconds to start Step 8.
8. Return to the vehicle. Firmly press and hold
the programmed Universal Home Remote
button for two seconds, then release. Repeat
the press/hold/release sequence a second
time, and depending on the brand of the
garage door opener or other rolling code
device, repeat this sequence a third time to
complete the programming.
The Universal Home Remote should now
activate the rolling-code device.
To program the remaining two Universal Home
Remote buttons, begin with Step 2 of
“Programming Universal Home Remote.” Do not
repeat Step 1, as this will erase all previous
programming from the Universal Home Remote
buttons.
178

Gate Operator and Canadian
Programming
Canadian radio-frequency laws require transmitter
signals to time out or quit after several seconds
of transmission. This may not be long enough
for Universal Home Remote to pick up the signal
during programming. Similarly, some U.S. gate
operators are manufactured to time out in
the same manner.
If you live in Canada, or you are having difficulty
programming a gate operator or garage door
opener by using the “Programming Universal
Home Remote” procedures, regardless of where
you live, replace Step 3 under “Programming
Universal Home Remote” with the following:
Continue to press and hold the Universal Home
Remote button while you press and release every
two seconds (cycle) the hand-held transmitter
button until the frequency signal has been
successfully accepted by the Universal Home
Remote. The Universal Home Remote indicator
light will ash slowly at rst and then rapidly.
Proceed with Step 4 under “Programming
Universal Home Remote” to complete.
Using Universal Home Remote
Press and hold the appropriate Universal Home
Remote button for at least half of a second.
The indicator light will come on while the signal is
being transmitted.
Erasing Universal Home Remote
Buttons
To erase programming from the three Universal
Home Remote buttons do the following:
1. Press and hold down the two outside buttons
until the indicator light begins to ash, after
20 seconds. Do not hold the two outside
buttons for longer than 30 seconds.
2. Release both buttons.
The Universal Home Remote is now in the training
(learning) mode and can be programmed at any
time beginning with Step 2 under “Programming
Universal Home Remote” shown earlier in
this section.
Individual buttons cannot be erased, but they can
be reprogrammed. See “Reprogramming a
Single Universal Home Remote Button” following
this section.
179

Reprogramming a Single Universal
Home Remote Button
To program a device to Universal Home Remote
using a Universal Home Remote button
previously trained, follow these steps:
1. Press and hold the desired Universal Home
Remote button. Do not release the button.
2. The indicator light will begin to ash after
20 seconds. While still holding the Universal
Home Remote button, proceed with Step
2 under “Programming Universal Home
Remote” shown earlier in this section.
For additional information on Universal Home
Remote, seeCustomer Assistance Offices
on page 560.
Storage Areas
Your vehicle’s large carrying capacity can store
many items. If the vehicle has an extended
wheelbase, it can carry even larger items. The
oor pins that are used to attach the seats, can be
used to secure larger loads.
Glove Box
If the glove box has a lock, put your key into the
lock and turn the key counterclockwise. To
open the glove box, pull the latch release.
The glove box door has a detent to prevent the
door from lowering too far. Open the glove
box until the door is partway open, then pull the
door down if you need it fully opened.
To close the glove box, the door must be pushed
up past the detent. To lock the glove box, put
your key into the lock and turn the key clockwise.
Cupholder(s)
There are cupholders located below the center
instrument panel switchbank. The cupholders have
a rubber liner that can be removed, so that
larger cups can t into the cupholders. You can
also remove the liner to clean it.
To use the cupholders, pull the tray out. Push the
tray back when not in use.
Your vehicle may be equipped with cupholders in
the second row.
180

Overhead Console (Without Rail)
If your vehicle has an overhead console without the
rail system, it has two reading lights, a courtesy
light, and a switchbank. SeeOverhead Console
Switchbank on page 211for more information.
Overhead Console (With Rail)
If your vehicle is equipped with an overhead
console, it may contain the following:
Reading lamps. SeeFront Reading Lamps on
page 209orRear Reading Lamps on
page 209.
Switchbank. SeeOverhead Console
Switchbank on page 211.
OnStar®System buttons. SeeOnStar®
System on page 167.
Universal Home Remote buttons. See
Universal Home Remote System (With Three
Round LED) on page 169orUniversal Home
Remote System (With One Triangular LED) on
page 170.
See your dealer to purchase additional items for
the rail system.
Storage Bin
Your vehicle may have a storage bin located on
the overhead rail that you can use for storage.
If your bin is equipped with the nger size latches
do the following:
1. Place the storage bin on to the rails in the
desired location.
2. Push rmly upward on the bin while supporting
it with one hand.
3. Push in on the latch and then rotate it
90 degrees.
181

4. Firmly press down making sure the latch is
at with the ribs (A) on the storage bin.
5. Switch hands and repeat Steps 2 through 4
for the latch on the opposite side of the
storage bin.
6. Reverse these steps in order to remove the
storage bin.If your bin is equipped with the hand size latches
do the following:
1. Place the storage bin on to the rails in the
desired location.
2. Push rmly upward on the bin while supporting
it with one hand.
3. The bin will snap into place.
4. To remove the bin, support the bin with one
hand while pulling each latch up and away
from the bin.
182

The contents of the bin should never weigh more
than 1.5 lbs (0.7 kg).
Always make sure to close and latch the bin
before driving.
Floor Console Storage Area
If your vehicle has a storage compartment located
on the front console below the front cupholders.
Pull up and then forward on the handle to open the
storage compartment.
Folding Tray
Your vehicle may be
equipped with folding
convenience trays
located between seats.
To use each tray lift up
on the handle located on
its front end, while
pulling up on the tray to
lock it into place. There
are four cupholders on
each tray.
Second Row Center Console
If your vehicle has the second row center console,
use the following procedure to remove or install
the console.
Removing the Center Console
1. Locate the attachment lever in an opening on
the rear of the console
2. Pull the attachment lever upward to release
the attachment hook.
3. Lift the console up to remove it from the
vehicle.
183

Replacing the Center Console
{CAUTION:
A second row center console that is not
locked into place properly can move
around in a crash or sudden stop. People
in the vehicle could be injured. Be sure to
lock the console into place properly when
installing it.
1. Position the second row center console above
the forward oor attachments between the
second row bucket seats.
For information on installing the seats, see
Rear Seat Operation on page 13.
2. Place the console’s front hooks onto the
forward oor attachments.
3. Locate the attachment lever at the rear of the
console and pull up.
4. Rock the rear attachment bracket onto the
oor attachment and release the lever.
5. Pull up on the console to ensure the rear
attachment hook is latched.
Luggage Carrier
{CAUTION:
If you try to carry something on top of
your vehicle that is longer or wider than
the luggage carrier — like paneling,
plywood, a mattress and so forth — the
wind can catch it as you drive along. This
can cause you to lose control. What you
are carrying could be violently torn off,
and this could cause you or other drivers
to have a collision, and of course damage
your vehicle. You may be able to carry
something like this inside. But, never
carry something longer or wider than the
luggage carrier on top of your vehicle.
If you have the luggage carrier, you can load
things on top of your vehicle. Crossrails are not
standard on this vehicle and must be purchased at
your dealer.
184
