Removing the Flat Tire and
Installing the Spare Tire
Use the following pictures and instructions to
remove the at tire and raise the vehicle.
1. Remove the center cap, if your vehicle has
one, by placing the chisel end of the wheel
wrench in the slot on the wheel and gently pry
the cap out.If the wheel has bolt-on wheel covers, loosen
the plastic nut caps by turning the wheel
wrench counterclockwise. If needed, nish
loosening them by hand. The nut caps will not
come off. Using the at end of the wheel
wrench, pry along the edge of the cover until
it comes off.
2. Use the wheel wrench to loosen all the wheel
nuts. Turn the wheel wrench counterclockwise
to loosen the wheel nuts. Do not remove
the wheel nuts yet.
537

A. Front Position
B. Rear Position
{CAUTION:
Getting under a vehicle when it is jacked
up is dangerous. If the vehicle slips off
the jack you could be badly injured or
killed. Never get under a vehicle when it is
supported only by a jack.
{CAUTION:
Raising your vehicle with the jack
improperly positioned can damage the
vehicle and even make the vehicle fall. To
help avoid personal injury and vehicle
damage, be sure to t the jack lift head
into the proper location before raising the
vehicle.
3. Position the jack under the vehicle as shown.
Jacking Locations (Overall View)
538

Front Tire Flat:If the at tire is on a front tire
of the vehicle, you will need to use the jack
handle and only one jack handle extension.
Attach the wheel wrench to the jack handle
extension. Attach the jack handle to the
jack (A). Position the jack on the frame behind
the at tire where the frame sections overlap.Turn the wheel wrench clockwise to raise the
vehicle. Raise the vehicle far enough off the
ground so there is enough room for the spare
tire to clear the ground.
Front Position
Rear Position – 1500 Models
539

Rear Tire Flat:If the at tire is on a rear
tire of the vehicle, you will need to use
the jack handle (B) and both jack handle
extensions (C). Attach the wheel wrench (D) to
the jack handle extensions (C). Attach the jack
handle (B) to the jack (A). Use the jacking pad
provided on the rear axle. Turn the wheel
wrench (D) clockwise to raise the vehicle.Raise the vehicle far enough off the ground so
there is enough room for the spare tire to clear
the ground.
4. Remove all of the
wheel nuts.
5. Take off the at tire.
Rear Position – All Other Models
540

{CAUTION:
Rust or dirt on the wheel, or on the parts
to which it is fastened, can make the
wheel nuts become loose after time. The
wheel could come off and cause an
accident. When you change a wheel,
remove any rust or dirt from the places
where the wheel attaches to the vehicle. In
an emergency, you can use a cloth or a
paper towel to do this; but be sure to use
a scraper or wire brush later, if needed, to
get all the rust or dirt off.6. Remove any rust or
dirt from the wheel
bolts, mounting
surfaces and spare
wheel.
{CAUTION:
Never use oil or grease on studs or nuts.
If you do, the nuts might come loose.
Your wheel could fall off, causing a
serious accident.
7. Put the wheel nuts back on with the rounded
end of the nuts toward the wheel after
mounting the spare tire.
541

8. Tighten each wheel nut by hand. Then use
the wheel wrench to tighten the nuts until the
wheel is held against the hub.
9. Turn the wheel wrench counterclockwise to
lower the vehicle. Lower the jack completely.
{CAUTION:
Incorrect wheel nuts or improperly
tightened wheel nuts can cause the wheel
to come loose and even come off. This
could lead to an accident. Be sure to use
the correct wheel nuts. If you have to
replace them, be sure to get new GM
original equipment wheel nuts. Stop
somewhere as soon as you can and have
the nuts tightened with a torque wrench to
the proper torque specication. See
Capacities and Specifications on page 572
for wheel nut torque specication.Notice:Improperly tightened wheel nuts can
lead to brake pulsation and rotor damage.
To avoid expensive brake repairs, evenly
tighten the wheel nuts in the proper sequence
and to the proper torque specication. See
Capacities and Specifications on page 572for
the wheel nut torque specication.
10. Tighten the nuts rmly in a crisscross
sequence as shown by turning the wheel
wrench clockwise.
542

When you reinstall the regular wheel and tire, you
must also reinstall the either the center cap, or
bolt-on hub cap, depending on what your vehicle
has. For center caps, place the cap on the
wheel and tap it into place until it seats ush with
the wheel. The cap only goes on one way. Be
sure to line up the tab on the center cap with the
indentation on the wheel. For bolt-on hub caps,
align the plastic nut caps with the wheel nuts and
then tighten by hand. Then use the wheel
wrench to tighten.
Secondary Latch System
Your vehicle has an underbody-mounted tire hoist
assembly which has a secondary latch system.
It is designed to stop the spare tire from suddenly
falling off your vehicle. For the secondary latch
to work, the spare tire must be installed with
the valve stem pointing down. SeeStoring a Flat
or Spare Tire and Tools on page 547.
{CAUTION:
Before beginning this procedure read all
the instructions. Failure to read and follow
the instructions could damage the hoist
assembly and you and others could get
hurt. Read and follow the instructions
listed next.
To release the spare tire from the secondary latch,
do the following:
1. Check under the
vehicle to see if the
cable end is
visible. If the cable
is not visible,
proceed to Step 6.
543

2. If it is visible, rst try to tighten the cable by
turning the wheel wrench clockwise until you
hear two clicks or feel it skip twice. You
cannot overtighten the cable.
3. Loosen the cable by turning the wheel wrench
counterclockwise three or four turns.
4. Repeat this procedure at least two times. If
the spare tire lowers to the ground, continue
with Step 5 ofRemoving the Spare Tire
and Tools on page 533.
5. If the spare tire does not lower, turn the wheel
wrench counterclockwise until approximately
6 inches (15 cm) of cable is exposed.
6. Stand the wheel blocks on their shortest ends,
with the backs facing each other.7. Place the bottom
edge of the jack (A)
on the wheel
blocks (B),
separating them so
that the jack is
balanced securely.
