2007 CHEVROLET EQUINOX Owners Manual

Driver Seat Height Adjuster
If your vehicle has a manual driver seat height
adjuster, it is located on the outboard side of
the seat near the front of the seat cushion.
To raise the seat, move the lever upward
repeatedly until the seat is at the desired height.
To lower the seat, move the lever downward
repeatedly until the seat is at the desired height.
Power Seat
If the vehicle has a power seat, the control used
to operate it is located on the outboard side of the
driver’s seat. To adjust the seat do any of the
following:
Move the seat forward or rearward by sliding
the control forward or rearward.
Raise or lower the front part of the seat cushion
by moving the front of the control up or down.
Raise or lower the rear part of the seat cushion
by moving the rear of the control up or down.
9

Manual Lumbar
If your vehicle has this
feature, the knob is
located on the front of
the driver seat lower
cushion on the
inboard side.
Turn the knob clockwise or counterclockwise to
increase or decrease the lumbar support.
Heated Seats
If your vehicle has
heated seats, the
switches are located on
the center console of the
instrument panel above
the shift lever.
The ignition must be on for the heated seats
to operate.
Press the switch, nearest to the seat, once to turn
the heated seat on to the high setting. Both
indicator lights will be lit. Press the switch a
second time to turn the heated seat to the low
setting. One indicator light will be lit. Press
the switch a third time to turn the heated seat off.
10

Manual Reclining Seatbacks
{CAUTION:
You can lose control of the vehicle if
you try to adjust a manual driver’s seat
while the vehicle is moving. The sudden
movement could startle and confuse you,
or make you push a pedal when you do
not want to. Adjust the driver’s seat only
when the vehicle is not moving.
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on
the seatback to be sure it is locked.To adjust the seatback on the driver’s seat, lift the
lever on the rear outboard side of the seat and
move the seatback to the desired position. Then
release the lever to lock the seatback in place.
Driver’s Seat with Manual Recline and
Manual Height Adjuster shown
11

To adjust the seatback on the front passenger’s
seat, lift the lever on the outboard side of the seat
and move the seatback to the desired position.
Then release the lever to lock the seatback
in place. If your front passenger’s seat is a at
folding seat, you must fully raise the lever to
disengage the seatback.
Passenger Seat with Folding Seatback
Option shown
12

{CAUTION:
Sitting in a reclined position when your
vehicle is in motion can be dangerous.
Even if you buckle up, your safety belts
cannot do their job when you are reclined
like this.
The shoulder belt cannot do its job
because it will not be against your body.
Instead, it will be in front of you. In a
crash, you could go into it, receiving neck
or other injuries.
The lap belt cannot do its job either. In a
crash, the belt could go up over your
abdomen. The belt forces would be there,
not at your pelvic bones. This could cause
serious internal injuries.
For proper protection when the vehicle is
in motion, have the seatback upright.
Then sit well back in the seat and wear
your safety belt properly.
Do not have a seatback reclined if your vehicle is
moving.
Head Restraints
Adjust the head restraint so that the top of the
restraint is at the same height as the top of
the occupant’s head. This position reduces the
chance of a neck injury in a crash.
13

Pull the head restraint up
to raise it. To lower the
head restraint, press the
button, located on the
top of the seatback, and
push the restraint down.Passenger Folding Seatback
The front passenger’s seatback may fold at.
{CAUTION:
If you fold the seatback forward to carry
longer objects, such as skis, be sure any
such cargo is not near an airbag. In a
crash, an inating airbag might force that
object toward a person. This could cause
severe injury or even death. Secure objects
away from the area in which an airbag
would inate. For more information, see
Where Are the Airbags? on page 75and
Loading Your Vehicle on page 315.
14

{CAUTION:
Things you put on this seatback can
strike and injure people in a sudden stop
or turn, or in a crash. Remove or secure
all items before driving.
To fold the seatback, do the following:
1. Lower the head restraint all the way.
2. Lift the bar under the front of the seat to
unlock it. Slide the seat as far back as it
will go and release the bar. Try to move the
seat back and forth to make sure it is
locked into place.3. Lift the recliner lever, located on the outboard
side of the seat, up fully and fold the seatback
forward until it disengages.
15

4. Continue to fold the seat forward until it locks
in the folded position.
5. Pull up on the seatback to be sure it is
locked.
To raise the seatback, do the following:
1. Lift the recliner lever, located on the outboard
side of the seat, up fully and push up on the
seatback.
2. Continue raising the seatback until the
seatback re-engages.
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on the
seatback to be sure it is locked.
3. Push and pull on the seatback to make sure it
is locked in place.
The recliner lever is also used to recline the
seatback while a passenger is seated. SeeManual
Reclining Seatbacks on page 11.
16
