2007 CADILLAC SRX Owners Manual

Front Seats
Manual Seats
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on
the seatback to be sure it is locked.
Your vehicle may have manual seats. To adjust the
seat, lift the bar under the front of the seat to unlock
it. Slide the seat to where you want it and release
the bar. Try to move the seat back and forth with
your body to be sure the seat is locked in place.
9

Power Seats
If the vehicle has power seats, the controls used
to operate them are located on the outboard
side of the seats.
Move the seat forward or rearward by sliding
the horizontal control forward or rearward.
Raise or lower the front part of the seat
cushion by moving the front of the horizontal
control up or down.
Raise or lower the rear part of the seat
cushion by moving the rear of the horizontal
control up or down.
Raise or lower the entire seat by moving the
entire horizontal control up or down.
The vertical control is used for reclining your
seatback. See “Power Reclining Seatbacks” under
Reclining Seatbacks on page 14for more
information.
Power Lumbar
Your vehicle may have
this feature. The driver’s
and passenger’s
seatback lumbar support
can be adjusted by
moving the control
located on the outboard
side of the seat
cushions.
10

To increase or decrease support, hold the control
forward or rearward. Keep in mind that as your
seating position changes, as it may during
long trips, so should the position of your lumbar
support. Adjust the seat as needed.
Heated Seats
Your vehicle may have
heated front seats. The
controls are located
on the driver’s and
passenger’s doors,
near the door handle.
I(Heated Seatback):Press this button to turn
on the heated seatback.The light on the button will come on to indicate
that the feature is working. Press the button
to cycle through the temperature settings of high,
medium, and low and to turn the heat to the
seatback off. Indicator lights next to the button
show the level of heat selected: three for high,
two for medium, and one for low.
J(Heated Seat and Seatback):Press this
button to turn on the heated seat and seatback.
The light on the button will come on to indicate that
the feature is working. Press the button to cycle
through the temperature settings of high, medium,
and low and to turn the heat to the seat off.
Indicator lights next to the button will show the
level of heat selected: three for high, two for
medium, and one for low.
The heated seats will be canceled ten seconds
after the ignition is turned off. If you want to
use the heated seat feature after you restart your
vehicle, you will need to press the appropriate
heated seat or seatback button again.
11

Memory Seat and Mirrors
If your vehicle has the memory feature, you can
program and recall memory settings for the driver’s
seating and outside rearview mirror driving
positions for up to two drivers. If your vehicle has
the adjustable throttle and brake pedal feature,
you can also program and recall memory settings
for the throttle and brake pedal driving positions.
The buttons for this feature are located on the
driver’s door armrest.
Use the following steps to program the buttons:
1. Adjust the driver’s seat including the seatback
recliner, both outside mirrors, and the throttle
and brake pedals. SeeOutside Power
Heated Mirrors on page 137andAdjustable
Throttle and Brake Pedal on page 120
for more information.2. Press and hold button 1 for at least
three seconds.
Two beeps will sound to conrm that the seat
and mirror positions have been saved.
3. Repeat the procedure for a second driver
using button 2.
The vehicle must be in PARK (P) to recall the
stored driving positions.
Press one of the numbered memory buttons to
recall the stored setting. Each time a memory
button is pressed, a single beep will sound.
A chime will sound and the setting will not be
recalled if you press button 1 or 2 when the vehicle
is not in PARK (P).
If you would like the stored driving positions to be
recalled when unlocking your vehicle with the
remote keyless entry transmitter or when you place
the key in the ignition, seeDIC Vehicle
Customization on page 231.
To stop recall movement of the memory feature at
any time, press one of the power seat or mirror
controls.
12

Two personalized exit positions can also be
programmed. Use the following steps to program
exit positions:
1. Press memory seat button 1 or the button with
the unlock symbol on the remote keyless
entry transmitter with the number 1 on
the back to recall the driving position.
2. Adjust the driver’s seat to the desired exit
position.
3. Press and hold the exit button located above
buttons 1 and 2 on the driver’s door armrest
for at least three seconds.
Two beeps will sound to conrm that the exit
position has been saved.
4. Repeat the procedure for a second driver
using memory seat button 2 or the remote
keyless entry transmitter with the number 2 on
the back.To recall the stored exit positions, press and
release the exit button. One beep will sound, and
the seat will move to the previously stored exit
position for the currently identied driver. If an exit
position has not been stored for this driver, the
seat will move all the way back. The position of the
outside mirrors is not stored or recalled for the
exit position.
The vehicle must be in PARK (P) to recall the exit
positions.
A chime will sound and the exit setting will not be
recalled if you press the exit button when the
vehicle is not in PARK (P).
If you would like your stored exit position to be
recalled when unlocking the vehicle with the
remote keyless entry transmitter or when the
ignition is turned off and the driver’s door is
opened, seeDIC Vehicle Customization on
page 231.
13

Reclining Seatbacks
Manual Reclining Seatbacks
{CAUTION:
You can lose control of the vehicle if you
try to adjust a manual driver’s seat while
the vehicle is moving. The sudden
movement could startle and confuse you,
or make you push a pedal when you do
not want to. Adjust the driver’s seat only
when the vehicle is not moving.
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on
the seatback to be sure it is locked.If your front passenger’s seat has a manual
reclining seatback, the lever used to operate it is
located on the outboard side of the seat.
To recline the seatback, do the following:
1. Lift the recline lever.
2. Move the seatback to the desired position,
then release the lever to lock the seatback
in place.
3. Push and pull on the seatback to make sure it
is locked.
14

To return the seatback to an upright position, do
the following:
1. Lift the lever fully without applying pressure to
the seatback and the seatback will return to
the upright position.
2. Push and pull on the seatback to make sure it
is locked.Power Reclining Seatbacks
If your seats have power reclining seatbacks, use
the vertical power seat control located on the
outboard side of each seat.
To recline the seatback, press the control
toward the rear of the vehicle.
To raise the seatback, press the control
toward the front of the vehicle.
15

{CAUTION:
Sitting in a reclined position when your
vehicle is in motion can be dangerous.
Even if you buckle up, your safety belts
cannot do their job when you are reclined
like this.
The shoulder belt cannot do its job. In a
crash, you could go into it, receiving neck
or other injuries.
The lap belt cannot do its job either. In a
crash the belt could go up over your
abdomen. The belt forces would be there,
not at your pelvic bones. This could cause
serious internal injuries.
For proper protection when the vehicle is
in motion, have the seatback upright.
Then sit well back in the seat and wear
your safety belt properly.
Do not have a seatback reclined if your vehicle is
moving.
16
