2007 Acura RDX reset

ÛÝ
ÛÝ Press
the SEL/RESET button. The
screen changes as shown above.
Se lect ON or OFF by pressing the
INFO ( / ) button, then press the
SEL/RESET button to enter your
selection.
While
DOOR SETUP is shown in the
CUSTOMIZE GROUP of the multi-
info rmation display, press the SEL/
RESET button. The screen changes
to CUSTOMIZE MENU. Press the
INFO ( / ) button until you see
the above display.
When
you press the UNLOCK
button on the remote transmitter to
unlock the doors and the tailgate, the
exterior lights blink twice to veri fy
that the doors and the tailgate are
unlocked and the security system is
turned off.
When you push the LOCK button on
the remote transmitter, some
exterior lights flash, and a beeper
sounds when you push the LOCK
button again within 5 seconds to
verify that the doors and the tailgate
arelockedandthesecuritysystem
has set (see page ). You can
customize the exterior lights not to
f lash and the beeper not to sound. 140
Multi-Inf ormation Display
K eyless L ock A cknowledgment
112
——
y
y
() y

y

ÛÝ
CONT INUED
When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE MENU.If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE MENU. If this
happens, you need to repeat the
same procedure.To exit KEYLESS LOCK
ACKNOWLEDGMENT without
changing the current setting, select
EXIT by pressing the INFO ( / )
button, then press the SEL/RESET
button. The screen goes back to
CUSTOMIZE MENU.
Multi-Inf ormation Display
Inst rument s and Cont rols
113
——
yy
() y

y

ÛÝ
ÛÝ
If you unlock the doors and the
tailgate with the remote transmitter,
but do not open any of the doors or
thetailgatewithin30seconds,the
doors and the tailgate automatically
relock and the security system sets.
You can change this relock time
f rom 30 seconds to 60 or 90 seconds.
Press the SEL/RESET button. The
screen changes as shown above.
Select the relock time you want (30,
60, or 90 seconds) by pressing the
INFO ( / ) button, then press the
SEL/RESET button to enter your
selection.
While DOOR SETUP is shown in the
CUSTOMIZE GROUP of the multi-
inf ormation display, press the SEL/
RESET button. The screen changes
to CUSTOMIZE MENU. Press the
INFO ( / ) button until you see
the above display.
Multi-Inf ormation Display
Securit y Relock T imer
114
——
y
y
() y

y

ÛÝ
To exit SECURITY RELOCK
TIMER without changing the
current setting, select EXIT by
pressing the INFO ( / ) button,
then press the SEL/RESET button.
The screen goes back to
CUSTOMIZE MENU.
When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE MENU.
If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE MENU. If this
happens, you need to repeat the
same procedure.
Multi-Inf ormation Display
Inst rument s and Cont rols
115
——
yy
() y
y

ÛÝ
µ
µ
ÛÝ
µ
There are three settings you can
choose f rom:
Press the SEL/RESET button. The
screen changes as shown above.
Select the desired setting by
pressing the INFO ( / ) button,
then press the SEL/RESET button
to enter your selection.
SHIFT TO P The driver’s door or
all the doors unlock when you move
the shift lever to Park.
IGN OFF The driver’s door or all
the doors unlock when you turn the
ignition switch to the LOCK (0)
position.
While DOOR SETUP is shown in the
CUSTOMIZE GROUP of the multi-
inf ormation display, press the SEL/
RESET button. The screen changes
to CUSTOMIZE MENU. Press the
INFO ( / ) button until you see
the above display.
OFF The auto door unlock is
deactivated all the time.
Multi-Inf ormation Display
A ut o Door Unlock
116
——
y

y
() y

y

ÛÝ
To exit AUTO DOOR UNLOCK
without changing the current setting,
select EXIT by pressing the INFO
( / ) button, then press the SEL/
RESET button. The screen goes
back to CUSTOMIZE MENU.
When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE MENU.
If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE MENU. If this
happens, you need to repeat the
same procedure.
Multi-Inf ormation Display
Inst rument s and Cont rols
117
——
yy
() y
y

The courtesy lights in the ceiling
console come on when the light
switch is in the or the
position. You can adjust their
brightness by turning the Select/
Reset knob on the instrument panel. The
cargo area light has a two
position switch. In the OFF (right)
position, the light does not come on.
In the ON (left) position, the light
comesonwhenyou openthetailgate.
Your
vehicle also has a courtesy light
in the ignition switch. This light
comesonwhenyou;
Unlock the driver’s door.
Remove the key from the ignition
switch. Open any door.
The
courtesy light in each front door
comes on when the door is opened,
and goes out when the door is closed.
After all doors are closed tightly, the
light fades out in about 30 seconds.
You can change the ‘‘INTERIOR
LIGHT DIMMING TIME’’ setting in
the multi-information display (see
page ). 103
On RDX with Technology Package
model
Interior Lights
Courtesy Lights Cargo Area Light
160
COURTESY LIGHTS ON OFF
——
y

y
() y
y

XM satellite radio information is
available on page .
The band and f requency that the
radio was last tuned to is displayed.
To change bands, press the AM or
FM button. On the FM band, ‘‘ST’’
will be shown on the center display if
the station is broadcasting in stereo.
Stereo reproduction on AM is not
available. The ignition switch must be in the
ACCESSORY (I) or the ON (II)
position. Turn the system on by
pushing the PWR/VOL knob, or the
AM or FM button. Adjust the volume
by turning the PWR/VOL knob.
193
On U.S. models
On RDX model
Audio System
To Play the AM/FM Radio
180
STEREO
INDICATOR
FM BUTTON
SCAN BUTTON
TUNE/FOLDER BAR AM BUTTONSCAN
INDICATOR
A.SEL
INDICATOR
A.SEL/RDM BUTTON VOLUME
LEVEL
PWR/VOL KNOB
PRESET BARS
SEEK/SKIP BAR
U.S. model is shown.
——
