ENGINE - 2AZ-FE ENGINE
DR011EG25
Camshaft Position Sensor
Engine Coolant
Temperature Sensor
Crankshaft
Position Sensor
Camshaft Timing
Oil Control Valve
Throttle Position
Sensor
ECM
Mass Air Flow Meter Vehicle Speed Signal
221EG16
Crankshaft Position Sensor
Mass Air Flow Meter
Throttle Position Sensor
Engine Coolant Temp. Sensor
Camshaft Position Sensor
Vehicle Speed SignalECM
Target Valve Timing
Feedback
Correction
Actual Valve Timing
Duty-cycle
Control
Camshaft Timing
Oil Control Valve
EG-48
7. VVT-i (Variable Valve Timing-intelligent) System
General
The VVT-i system is designed to control the intake camshaft within a range of 40 (of Crankshaft Angle)
to provide valve timing that is optimally suited to the engine condition. This realizes proper torque in
all the speed ranges as well as realizing excellent fuel economy, and reducing exhaust emissions.
Using the engine speed signal, vehicle speed signal, and the signals from mass air flow meter, throttle
position sensor and engine coolant temperature sensor, the ECM can calculate optimal valve timing for
each driving condition and controls the camshaft timing oil control valve. In addition, the ECM uses
signals from the camshaft position sensor and crankshaft position sensor to detect the actual valve timing,
thus providing feedback control to achieve the target valve timing.

ENGINE - 2AZ-FE ENGINE
01NEG13Y
Generator
RegulatorB
DF
RLOECM
Various Electrical
Loads
Battery Current Sensor
Battery Temperature Sensor
Battery Voltage
Battery
Various Sensors and Switches
Throttle Position Sensor
Crankshaft Position Sensor
Accelerator Pedal Position
SensorEG-65
11. Charging Control
General
This system lowers the generated voltage when the vehicle is idling or is being driven at a constant speed,
and raises the generated voltage when the vehicle is decelerating. This reduces the load on the engine as
a result of the electric generation of the generator, thus contributing to the fuel economy of the engine.
During acceleration, this system regulates the generated voltage in order to place the amperage estimation
value close to the target value.
This control consists of the ECM, battery current sensor with a built-in battery temperature sensor,
generator, and various sensors and switches.
The ECM detects driving condition based on signals from various sensors and switches, and detects
charging condition based on signals from the generator, battery current sensor and battery temperature
sensor. Then the ECM outputs signals to the IC regulator to control the genetated voltage of the generator.
The ECM stops the charging control and the generator switches to normal power generation mode under
the following conditions:
Low battery capacity
Low or high battery temparature
Wipers operating or blower motor operating with tail lamp relay ON
System Diagram

ENGINE - 2GR-FE ENGINE
01MEG13Y
Air Cleaner Hose with
Resonator
Air Cleaner Cap
Charcoal Filter
Air Cleaner Element
(Nonwoven Fabric)
Air Cleaner Case
Actuator
(For Air Intake Control)
Air Cleaner Inlet
Resonator
285EG32
Throttle Position Sensor
Throttle Control MotorEG-91
2. Air Cleaner
A nonwoven, full-fabric type air cleaner
element is used.
A charcoal filter, which adsorbs the HC that
accumulates in the intake system when the
engine is stopped, is used in the air cleaner case
in order to reduce evaporative emissions. This
filter is maintenance-free.
Along with the use of the air intake control
system, an air intake control valve is provided
on the air cleaner case. For details, see page
EG-128.
Resonators have been provided to reduce the
amount of intake air sound.
3. Throttle Body
A linkless-type throttle body in which the throttle position sensor and the throttle control motor are integrated
is used. It realizes excellent throttle valve control. For details, see page EG-118.
In the throttle control motor, a DC motor with excellent response and minimal power consumption is used.
The ECM performs the duty ratio control of the direction and the amperage of the current that flows to
the throttle control motor in order to regulate the throttle valve angle.

ENGINE - 2GR-FE ENGINE
238EG68
VVT Sensors
Crankshaft
Position
Sensor
Va r i o u s
SensorsVV1
VV2
NE
ECMIGT1
IGT2
IGT3
IGT4
IGT5
IGT6
IGF+B Ignition Coil (with Igniter)
No. 1 Cylinder
No. 2 Cylinder
No. 3 Cylinder
No. 4 Cylinder
No. 5 Cylinder
No. 6 Cylinder
285EG39
Igniter
Iron Core
Secondary
Coil
Primary Coil
Plug Cap EG-96
IGNITION SYSTEM
1. General
A DIS (Direct Ignition System) is used. The DIS improves the ignition timing accuracy, reduces high-voltage
loss, and enhances the overall reliability of the ignition system by eliminating the distributor.
The DIS is an independent ignition system which has one ignition coil (with igniter) for each cylinder.
2. Ignition Coil
The DIS provides 6 ignition coils, one for each
cylinder. The spark plug cap, which provides
contact to the spark plug, are integrated with an
ignition coil. Also, an igniter is enclosed to
simplify the system.

ENGINE - 2GR-FE ENGINE
01MEG07Y
SENSORSACTUATORS
MASS AIR FLOW METER
INTAKE AIR TEMPERATURE
SENSOR
CRANKSHAFT POSITION
SENSOR
ENGINE COOLANT
TEMPERATURE SENSOR
ACCELERATOR PEDAL
POSITION SENSOR
THROTTLE POSITION
SENSOR
KNOCK SENSOR (Bank 1)
KNOCK SENSOR (Bank 2)
INTAKE VVT SENSOR (Bank 1)
INTAKE VVT SENSOR (Bank 2)
EXHAUST VVT SENSOR
(Bank 1)
EXHAUST VVT SENSOR
(Bank 2)
IGNITION SWITCHVG
THA
NE
THW
VPA
VPA2
VTA1
VTA2
KNK1
KNK2
VV1
VV2
EV1
EV2
IGSWECM#10
#20
#30
#40
#50
#60
IGT1 -
IGT6
IGF1
M
OC1
OC2
OE1
OE2SFI
NO. 1 INJECTOR
NO. 2 INJECTOR
NO. 3 INJECTOR
NO. 4 INJECTOR
NO. 5 INJECTOR
NO. 6 INJECTOR
ESA
IGNITION COIL with
IGNITER
SPARK PLUG
ETCS-i
THROTTLE CONTROL
MOTOR
VVT-i (INTAKE SIDE)
CAMSHAFT TIMING OIL
CONTROL VALVE (Bank 1)
CAMSHAFT TIMING OIL
CONTROL VALVE (Bank 2)
VVT-i (EXHAUST SIDE)
CAMSHAFT TIMING OIL
CONTROL VALVE (Bank 1)
CAMSHAFT TIMING OIL
CONTROL VALVE (Bank 2)EG-103
2. Construction
The configuration of the engine control system is as shown in the following chart.
(Continued)

ENGINE - 2GR-FE ENGINE
01MEG06Y
COMBINATION METER
Vehicle Speed Signal
AIR-FUEL RATIO SENSOR
Bank 1, Sensor 1
Bank 2, Sensor 1
HEATED OXYGEN SENSOR
Bank 1, Sensor 2
Bank 2, Sensor 2
CANISTER PUMP MODULE
CANISTER PRESSURE
SENSOR
PARK / NEUTRAL POSITION
SWITCH
TRANSMISSION CONTROL
SWITCH
TRANSPONDER KEY ECU
GENERATOR
BATTERY CURRENT SENSOR
(BUILT-IN BATTERY
TEMPERATURE SENSOR)
WIPER CONTROL SWITCHSPD
A1A
A2A
OX1B
OX2B
PPMP
STA
P, R, N, D
4, L
IMI
IMO
DF
THB VCIB
INHECMACIS
AICV
FC
FPR
HA1A
HA2A
HT1B
HT2B
RLOACIS
ACIS ACTUATOR
AIR INTAKE CONTROL
SYSTEM
VSV
FUEL PUMP CONTROL
CIRCUIT OPENING RELAY
FUEL PUMP RELAY
AIR-FUEL RATIO SENSOR
HEATER CONTROL
AIR-FUEL RATIO SENSOR
HEATER
Bank 1, Sensor 1
Bank 2, Sensor 1
HEATED OXYGEN SENSOR
HEATER CONTROL
HEATED OXYGEN SENSOR
HEATER
Bank 1, Sensor 2
Bank 2, Sensor 2
CHARGING CONTROL
GENERATOR EG-104
(Continued)

ENGINE - 2GR-FE ENGINE
01MEG29Y
Ignition SwitchCombination Meter
Vehicle Speed Signal
MIL
Battery Current Sensor
(Built-in Battery
Temperature Sensor)
Park / Neutral
Position Switch
Battery
Generator
Fuel Pump Relay
Fuel Pump
Vent Valve
Circuit Opening
RelayDLC3*1*2*3
CAN
ECM
Cruise Control Switch
Accelerator Pedal
Position Sensor
Stop Light Switch
Canister
Pressure
SensorLeak
Detection
Pump
Intake Air
Temp. Sensor
VSV (For
Air Intake
Control)Mass Air
Flow Meter
AirThrottle Position
Sensor
Purge VSV
Throttle
Control
Motor
*4*5
Fan
Motor No. 1Fan
Motor
No. 2
Cooling
Fan
ECUCooling
Fan
ECU
No. 1Cooling
Fan
ECU
No. 2
Fan Motor No. 1
Fan Motor No. 2
ACIS Actuator
Intake Camshaft Timing
Oil Control Valve (Bank 2)Injector Injector
Intake Camshaft Timing
Oil Control Valve (Bank 1)
Intake VVT Sensor (Bank 1)
Ignition Coil With Igniter
Exhaust VVT Sensor (Bank 1)
Exhaust Camshaft Timing
Oil Control Valve (Bank 1)
Air-fuel Ratio Sensor
(Bank1, Sensor1)
TWC
Knock
Sensor
Intake VVT
Sensor (Bank 2)
Exhaust VVT
Sensor (Bank 2)
Air-fuel Ratio Sensor
(Bank2, Sensor1)Exhaust Camshaft
Timing Oil Control
Valve (Bank 2)
Crankshaft Position
Sensor
Engine Coolant
Temperature Sensor Heated Oxygen Sensor
(Bank1, Sensor2)Heated Oxygen Sensor
(Bank2, Sensor2)TWCTWC
EG-106
3. Engine Control System Diagram
*1: Air Conditioning ECU
*
2: Airbag Sensor Assembly
*
3: Skid Control ECU
*
4: Except Towing Package Models
*
5: Towing Package Models

ENGINE - 2GR-FE ENGINE
01MEG24Y
01MEG25Y
01MEG26Y
Heated Oxygen Sensor
(Bank 2, Sensor2)
Battery Current Sensor
(Built-in Battery Temperature Sensor)ECMHeated Oxygen Sensor
(Bank 1, Sensor 2)Canister Pump Module
Ve n t Va l v e
Leak Detection Pump
Canister Pressure SensorFuel Pump
VSV (for Air Intake Control)
Mass Air Flow Meter
Intake Air Temperature Sensor
Air Cleaner Cap
Vacuum Tank
Actuator (For Air Intake Control)
Combination Meter
Malfunction Indicator Lamp
DLC3
Accelerator Pedal
Position SensorEG-107
4. Layout of Main Components
