2006 SAAB 9-7X Owners Manual

Seats and Restraint Systems........................... 1-1
Front Seats
............................................... 1-2
Rear Seats
............................................... 1-6
Safety Belts
.............................................. 1-8
Child Restraints
.......................................1-27
Airbag System
.........................................1-51
Restraint System Check
............................1-67
Features and Controls..................................... 2-1
Keys
........................................................ 2-3
Doors and Locks
....................................... 2-8
Windows
.................................................2-14
Theft-Deterrent Systems
............................2-16
Starting and Operating Your Vehicle
...........2-20
Mirrors
....................................................2-31
OnStar
®System
......................................2-43
Universal Home Remote System
................2-46
Storage Areas
.........................................2-50
Moonroof
................................................2-55
Vehicle Personalization
.............................2-55
Instrument Panel............................................. 3-1
Instrument Panel Overview
.......................... 3-4
Climate Controls
......................................3-19
Warning Lights, Gages, and Indicators
........3-25
Driver Information Center (DIC)
..................3-43
Audio System(s)
.......................................3-58Driving Your Vehicle....................................... 4-1
Your Driving, the Road, and Your Vehicle
..... 4-2
Towing
...................................................4-39
Service and Appearance Care.......................... 5-1
Service
..................................................... 5-3
Fuel
......................................................... 5-5
Checking Things Under the Hood
.................5-10
All-Wheel Drive
........................................5-46
Rear Axle
...............................................5-47
Front Axle
...............................................5-48
Headlamp Aiming
.....................................5-49
Bulb Replacement
....................................5-49
Windshield Replacement
...........................5-53
Windshield Wiper Blade Replacement
.........5-53
Tires
......................................................5-56
Appearance Care
.....................................5-89
Vehicle Identication
.................................5-97
Electrical System
......................................5-98
Capacities and Specications
...................5-108
Maintenance Schedule..................................... 6-1
Maintenance Schedule
................................ 6-2
Customer Assistance and Information.............. 7-1
Customer Assistance and Information
........... 7-2
Reporting Safety Defects
...........................7-10
Index................................................................ 1
2006 Saab 9-7X Owner ManualM
ProCarManuals.com

Saab Automobile, Saab Cars USA, SAAB, Saab 9-7X,
9-7X and the Saab Emblem are registered trademarks
of Saab Automobile, AB.
This manual includes the latest information at the time it
was printed. We reserve the right to make changes after
that time without further notice. For vehicles rst sold in
Canada, substitute the name “General Motors of Canada
Limited” for Saab Automobile, AB whenever it appears in
this manual.
Keep this manual in the vehicle, so it will be there if it is
needed while you are on the road. If the vehicle is sold,
leave this manual in the vehicle.
Canadian Owners
A French language copy of this manual can be obtained
from your dealer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
How to Use This Manual
Many people read the owner manual from beginning to
end when they rst receive their new vehicle. If this is
done, it can help you learn about the features and
controls for the vehicle. Pictures and words work
together in the owner manual to explain things.
Index
A good place to quickly locate information about the
vehicle is the Index in the back of the manual. It is an
alphabetical list of what is in the manual and the page
number where it can be found.
Litho in U.S.A. © 2005 General Motors Corporation. All Rights Reserved.
Part No. 0697X A First Printing
ii
ProCarManuals.com

Safety Warnings and Symbols
There are a number of safety cautions in this book. We
use a box and the word CAUTION to tell about things
that could hurt you if you were to ignore the warning.
{CAUTION:
These mean there is something that could hurt
you or other people.
In the caution area, we tell you what the hazard is. Then
we tell you what to do to help avoid or reduce the hazard.
Please read these cautions. If you do not, you or others
could be hurt.You will also nd a circle
with a slash through it in
this book. This safety
symbol means “Do Not,”
“Do Not do this” or
“Do Not let this happen.”
iii
ProCarManuals.com

Vehicle Damage Warnings
Also, in this manual you will nd these notices:
Notice:These mean there is something that could
damage your vehicle.
A notice tells about something that can damage the
vehicle. Many times, this damage would not be covered
by your vehicle’s warranty, and it could be costly. But
the notice will tell what to do to help avoid the damage.
When you read other manuals, you might see CAUTION
and NOTICE warnings in different colors or in different
words.
There are also warning labels on the vehicle. They use
the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use symbols
instead of text. Symbols are shown along with the text
describing the operation or information relating to a
specic component, control, message, gage, or indicator.
If you need help guring out a specic name of a
component, gage, or indicator, reference the following
topics:
Seats and Restraint Systems in Section 1
Features and Controls in Section 2
Instrument Panel Overview in Section 3
Climate Controls in Section 3
Warning Lights, Gages, and Indicators in Section 3
Audio System(s) in Section 3
Engine Compartment Overview in Section 5
iv
ProCarManuals.com

These are some examples of symbols that may be found on the vehicle:
v
ProCarManuals.com

✍NOTES
vi
ProCarManuals.com

Front Seats......................................................1-2
Power Seats..................................................1-2
Power Lumbar...............................................1-2
Heated Seats.................................................1-3
Power Reclining Seatbacks..............................1-4
Head Restraints.............................................1-5
Rear Seats.......................................................1-6
Rear Seat Operation.......................................1-6
Safety Belts.....................................................1-8
Safety Belts: They Are for Everyone.................1-8
Questions and Answers About Safety Belts......1-12
How to Wear Safety Belts Properly.................1-13
Driver Position..............................................1-14
Safety Belt Use During Pregnancy..................1-20
Right Front Passenger Position.......................1-21
Rear Seat Passengers..................................1-21
Rear Safety Belt Comfort Guides....................1-24
Safety Belt Pretensioners...............................1-26
Safety Belt Extender.....................................1-26
Child Restraints.............................................1-27
Older Children..............................................1-27
Infants and Young Children............................1-29
Child Restraint Systems.................................1-33Where to Put the Restraint.............................1-38
Lower Anchors and Tethers for
Children (LATCH)......................................1-39
Securing a Child Restraint in a
Rear Outside Seat Position.........................1-44
Securing a Child Restraint in the
Center Rear Seat Position..........................1-47
Securing a Child Restraint in the
Right Front Seat Position............................1-47
Airbag System...............................................1-51
Where Are the Airbags?................................1-54
When Should an Airbag Inate?.....................1-57
What Makes an Airbag Inate?.......................1-59
How Does an Airbag Restrain?.......................1-59
What Will You See After an Airbag Inates?.....1-60
Passenger Sensing System............................1-61
Servicing Your Airbag-Equipped Vehicle...........1-65
Adding Equipment to Your Airbag-Equipped
Vehicle....................................................1-66
Restraint System Check..................................1-67
Checking the Restraint Systems......................1-67
Replacing Restraint System Parts After a Crash . . .1-68
Section 1 Seats and Restraint Systems
1-1
ProCarManuals.com

Front Seats
Power Seats
The power seat controls
are located on the outboard
side of the front seat
cushions. The horizontal
control adjusts the seat
cushion and the vertical
control adjusts the
seatback.
Move the front of the horizontal seat control up or
down to adjust the front portion of the cushion.
Move the rear of the horizontal seat control up or
down to adjust the rear portion of the cushion.
Lift up or push down on the center of the horizontal
seat control to move the entire seat up or down.
To move the seat forward or rearward, slide the
horizontal seat control forward or rearward.
To recline the seatback, press the vertical control
rearward. To raise the seatback, press the vertical
control forward. SeePower Reclining Seatbacks on
page 1-4for more information.
Power Lumbar
Your vehicle has power lumbar on the driver’s and front
passenger’s seats.
The seatback lumbar
support can be adjusted
by moving the control
located on the outboard
side of the seat cushions.
To increase or decrease support, hold the control
forward or rearward.
Keep in mind that as your seating position changes,
as it may during long trips, so should the position of
your lumbar support. Adjust the seat as needed.
1-2
